Frigidaire FRT21KD3A Factory Parts Catalog
Top mount r134a series
Hide thumbs
Also See for FRT21KD3A:
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
PRODUCT NO.
BASE MODEL NO.
FRT21KD3AQ5
FRT21KD3A
FRT21KD3AT5
FRT21KD3A
FRT21KD3AW5
FRT21KD3A
FRT21KD3AZ5
FRT21KD3A
MARKET
North America
WIRING DIAGRAM - # 240379009
OWNER'S GUIDE - # 240400105
SERVICE DATA SHEET - # 240379009
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque (right)
R134a
bisque (left)
R134a
white (right)
R134a
bisque (left)
Publication No.
5995379509
021009
-EN/SERVICE/KHB
357
FACTORY
PARTS CATALO
VOLTS
115
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21KD3A
©2002 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT21KD3A
Summary of Contents for Frigidaire FRT21KD3A
- Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21KD3AQ5 FRT21KD3A R134a bisque (right) FRT21KD3AT5 FRT21KD3A R134a bisque (left) FRT21KD3AW5 FRT21KD3A R134a white (right) FRT21KD3AZ5 FRT21KD3A R134a bisque (left) MARKET North America WIRING DIAGRAM - # 240379009 OWNER’S GUIDE - # 240400105 SERVICE DATA SHEET - # 240379009 TOP MOUNT REFRIGERATOR...
- Page 2 Publication No. FRT21KD3A 5995379509 DOOR 10/02...
- Page 3 FRT21KD3A Publication No. 5995379509 DOOR A = FRT21KD3A (FRT21KD3AQ5) B = FRT21KD3A (FRT21KD3AT5) C = FRT21KD3A (FRT21KD3AW5) D = FRT21KD3A (FRT21KD3AZ5) POS. NO PART NO DESCRIPTION 240514607 A B C D Gasket,seal ,white ,frzr door ,magnetic 240514608 A B C D Gasket,seal ,white ,refr door ,magnetic 240534901 A B C D...
- Page 4 Publication No. FRT21KD3A 5995379509 CABINET 10/02...
- Page 5 FRT21KD3A Publication No. 5995379509 CABINET A = FRT21KD3A (FRT21KD3AQ5) B = FRT21KD3A (FRT21KD3AT5) C = FRT21KD3A (FRT21KD3AW5) D = FRT21KD3A (FRT21KD3AZ5) POS. NO PART NO DESCRIPTION 240355402 A B C D Cover-fan 240367001 A B C D Knob-damper control 5303001028 A B C D Nut,push-on 240367401...
- Page 6 Publication No. FRT21KD3A 5995379509 SHELVES 10/02...
- Page 7 FRT21KD3A Publication No. 5995379509 SHELVES A = FRT21KD3A (FRT21KD3AQ5) B = FRT21KD3A (FRT21KD3AT5) C = FRT21KD3A (FRT21KD3AW5) D = FRT21KD3A (FRT21KD3AZ5) POS. NO PART NO DESCRIPTION 215667501 A B C D Tray,ice cube ,plastic 240358003 A B C D Shelf,freezer ,full-width ,wire 5303299664 A B C D Spacer,shelf...
- Page 8 Publication No. FRT21KD3A 5995379509 SYSTEM 10/02...
- Page 9 FRT21KD3A Publication No. 5995379509 SYSTEM A = FRT21KD3A (FRT21KD3AQ5) B = FRT21KD3A (FRT21KD3AT5) C = FRT21KD3A (FRT21KD3AW5) D = FRT21KD3A (FRT21KD3AZ5) POS. NO PART NO DESCRIPTION 240444401 A B C D Condenser,dynamic 240409301 A B C D Spacer-cond tube,black 218944001 A B C D Drier-filter,R134a System 240496101...
-
Page 10: Wiring Schematic
Publication No. FRT21KD3A 5995379509 WIRING SCHEMATIC 10/02... -
Page 11: Wiring Diagram
FRT21KD3A Publication No. 5995379509 WIRING DIAGRAM # = Fast-moving Parts 10/02 * = Non-Illustrated Parts...
