Frigidaire FRT21KR6A Factory Parts Catalog
Top mount refrigerator
Hide thumbs
Also See for FRT21KR6A:
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
PRODUCT NO.
BASE MODEL NO.
FRT21KR6AB4
FRT21KR6A
FRT21KR6AB5
FRT21KR6A
FRT21KR6AQ5
FRT21KR6A
FRT21KR6AW5
FRT21KR6A
MARKET
North America
WIRING DIAGRAM - 240379009
OWNER'S GUIDE - 240400105
SERVICE DATA SHEET - 240379009
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
black
R134a
black
R134a
bisque
R134a
white
Publication No.
5995372637
020522
-EN/SERVICE /MLR
924 / 05
FACTORY
PARTS CATALO
VOLTS
115
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21KR6A
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT21KR6A
Summary of Contents for Frigidaire FRT21KR6A
- Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21KR6AB4 FRT21KR6A R134a black FRT21KR6AB5 FRT21KR6A R134a black FRT21KR6AQ5 FRT21KR6A R134a bisque FRT21KR6AW5 FRT21KR6A R134a white MARKET North America WIRING DIAGRAM - 240379009 OWNER’S GUIDE - 240400105 TOP MOUNT SERVICE DATA SHEET - 240379009 REFRIGERATOR Model No.
- Page 2 Publication No. FRT21KR6A 5995372637 DOOR 05/02...
- Page 3 FRT21KR6A Publication No. 5995372637 DOOR A = FRT21KR6A (FRT21KR6AB4) B = FRT21KR6A (FRT21KR6AB5) C = FRT21KR6A (FRT21KR6AQ5) D = FRT21KR6A (FRT21KR6AW5) POS. NO PART NO DESCRIPTION 240514611 A B - - Gasket,frzr door seal ,black ,magnetic 240514607 - - C D Gasket,frzr door seal ,white ,magnetic 240514612 A B - -...
- Page 4 Publication No. FRT21KR6A 5995372637 CABINET 05/02...
- Page 5 FRT21KR6A Publication No. 5995372637 CABINET A = FRT21KR6A (FRT21KR6AB4) B = FRT21KR6A (FRT21KR6AB5) C = FRT21KR6A (FRT21KR6AQ5) D = FRT21KR6A (FRT21KR6AW5) POS. NO PART NO DESCRIPTION 240355402 A B C D Cover-fan 240367001 A B C D Knob-damper control 5303001028 A B C D Nut,push-on 240367401...
- Page 6 Publication No. FRT21KR6A 5995372637 SHELVES 05/02...
- Page 7 FRT21KR6A Publication No. 5995372637 SHELVES A = FRT21KR6A (FRT21KR6AB4) B = FRT21KR6A (FRT21KR6AB5) C = FRT21KR6A (FRT21KR6AQ5) D = FRT21KR6A (FRT21KR6AW5) POS. NO PART NO DESCRIPTION 215667501 A B C D Tray,ice cube ,plastic 240358003 A B C D Shelf,freezer ,full-width ,wire 5303299664 A B C D Spacer,shelf...
- Page 8 Publication No. FRT21KR6A 5995372637 SYSTEM 05/02...
- Page 9 FRT21KR6A Publication No. 5995372637 SYSTEM A = FRT21KR6A (FRT21KR6AB4) B = FRT21KR6A (FRT21KR6AB5) C = FRT21KR6A (FRT21KR6AQ5) D = FRT21KR6A (FRT21KR6AW5) POS. NO PART NO DESCRIPTION 240444401 A B C D Condenser,dynamic 218944001 A B C D Drier-filter,R134a System 240496101 A B C D Wiring Harness,machine compt ,w/electric cord 240385402...
-
Page 10: Wiring Schematic
Publication No. FRT21KR6A 5995372637 WIRING SCHEMATIC 05/02... -
Page 11: Wiring Diagram
FRT21KR6A Publication No. 5995372637 WIRING DIAGRAM # = Fast-moving Parts 05/02 * = Non-Illustrated Parts...
