Frigidaire FRT21KS5A Factory Parts Catalog
Top mount refrigerator
Hide thumbs
Also See for FRT21KS5A:
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
PRODUCT NO.
BASE MODEL NO.
FRT21KS5AQ2
FRT21KS5A
FRT21KS5AQ3
FRT21KS5A
FRT21KS5AW2
FRT21KS5A
FRT21KS5AW3
FRT21KS5A
MARKET
North America
WIRING DIAGRAM - 240379007
OWNER'S GUIDE - 2 = 240400104 & 3 = 240400105
SERVICE DATA SHEET - 240379005
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
bisque
R134a
white
R134a
white
Publication No.
5995362174
011212
-EN/SERVICE/KHB
357
FACTORY
PARTS CATALO
VOLTS
115
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21KS5A
©2001 White Consolidated Industries, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT21KS5A
Summary of Contents for Frigidaire FRT21KS5A
- Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21KS5AQ2 FRT21KS5A R134a bisque FRT21KS5AQ3 FRT21KS5A R134a bisque FRT21KS5AW2 FRT21KS5A R134a white FRT21KS5AW3 FRT21KS5A R134a white MARKET North America WIRING DIAGRAM - 240379007 OWNER’S GUIDE - 2 = 240400104 & 3 = 240400105 SERVICE DATA SHEET - 240379005 TOP MOUNT REFRIGERATOR...
- Page 2 Publication No. FRT21KS5A 5995362174 DOOR 12/01...
- Page 3 FRT21KS5A Publication No. 5995362174 DOOR A = FRT21KS5A (FRT21KS5AQ2) B = FRT21KS5A (FRT21KS5AQ3) C = FRT21KS5A (FRT21KS5AW2) D = FRT21KS5A (FRT21KS5AW3) POS. NO PART NO DESCRIPTION 240514607 A B C D Gasket-frzr door,white ,magnetic 240514608 A B C D Gasket-refr door,white ,magnetic 240337703 A B C D Door-dairy,w/o graphics ,clear...
- Page 4 Publication No. FRT21KS5A 5995362174 CABINET 12/01...
- Page 5 FRT21KS5A Publication No. 5995362174 CABINET A = FRT21KS5A (FRT21KS5AQ2) B = FRT21KS5A (FRT21KS5AQ3) C = FRT21KS5A (FRT21KS5AW2) D = FRT21KS5A (FRT21KS5AW3) POS. NO PART NO DESCRIPTION 240355402 A B C D Cover-fan 240367001 A B C D Knob-damper control 5303001028 A B C D Nut,push-on 240367401...
- Page 6 Publication No. FRT21KS5A 5995362174 SHELVES 12/01...
- Page 7 FRT21KS5A Publication No. 5995362174 SHELVES A = FRT21KS5A (FRT21KS5AQ2) B = FRT21KS5A (FRT21KS5AQ3) C = FRT21KS5A (FRT21KS5AW2) D = FRT21KS5A (FRT21KS5AW3) POS. NO PART NO DESCRIPTION 215667501 A B C D Tray-ice,plastic 240358003 A B C D Shelf-freezer 5303299664 A B C D Spacer-shelf 240380202 A B C D...
- Page 8 Publication No. FRT21KS5A 5995362174 SYSTEM 12/01...
- Page 9 FRT21KS5A Publication No. 5995362174 SYSTEM A = FRT21KS5A (FRT21KS5AQ2) B = FRT21KS5A (FRT21KS5AQ3) C = FRT21KS5A (FRT21KS5AW2) D = FRT21KS5A (FRT21KS5AW3) POS. NO PART NO DESCRIPTION 240444401 A B C D Condenser,dynamic 218944001 A B C D Drier-filter,R134a System 240496101 A B C D Harness-wiring,machine compt 6* #...
-
Page 10: Wiring Schematic
Publication No. FRT21KS5A 5995362174 WIRING SCHEMATIC 12/01... -
Page 11: Wiring Diagram
FRT21KS5A Publication No. 5995362174 WIRING DIAGRAM # = Fast-moving Parts 12/01 * = Non-Illustrated Parts...
