Frigidaire FRT21KD3A Factory Parts Catalog
Top mount refrigerator r134a series
Hide thumbs
Also See for FRT21KD3A:
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
PRODUCT NO.
BASE MODEL NO.
FRT21KD3AQ3
FRT21KD3A
FRT21KD3AQ4
FRT21KD3A
FRT21KD3AT3
FRT21KD3A
FRT21KD3AT4
FRT21KD3A
FRT21KD3AW3
FRT21KD3A
FRT21KD3AW4
FRT21KD3A
FRT21KD3AZ3
FRT21KD3A
FRT21KD3AZ4
FRT21KD3A
MARKET
North America
WIRING DIAGRAM - # 240379009
OWNER'S GUIDE - # 240400105
SERVICE DATA SHEET - # 240379009
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
bisque
R134a
bisque
R134a
bisque
R134a
white
R134a
white
R134a
white
R134a
white
Publication No.
5995372298
020516
-EN/SERVICE /MLR
924 / 05
FACTORY
PARTS CATALO
VOLTS
115
115
115
115
115
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21KD3A
©2002 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT21KD3A
Summary of Contents for Frigidaire FRT21KD3A
- Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21KD3AQ3 FRT21KD3A R134a bisque FRT21KD3AQ4 FRT21KD3A R134a bisque FRT21KD3AT3 FRT21KD3A R134a bisque FRT21KD3AT4 FRT21KD3A R134a bisque FRT21KD3AW3 FRT21KD3A R134a white FRT21KD3AW4 FRT21KD3A R134a white FRT21KD3AZ3 FRT21KD3A R134a white FRT21KD3AZ4 FRT21KD3A R134a white...
- Page 2 Publication No. FRT21KD3A 5995372298 DOOR 05/02...
- Page 3 FRT21KD3A Publication No. 5995372298 DOOR A = FRT21KD3A (FRT21KD3AQ3, FRT21KD3AT3) B = FRT21KD3A (FRT21KD3AQ4, FRT21KD3AT4) C = FRT21KD3A (FRT21KD3AW3, FRT21KD3AZ3) D = FRT21KD3A (FRT21KD3AW4, FRT21KD3AZ4) POS. NO PART NO DESCRIPTION 240514607 A B C D Gasket,frzr door seal ,white ,magnetic 240514608 A B C D Gasket,refr door seal ,white ,magnetic...
- Page 4 Publication No. FRT21KD3A 5995372298 CABINET 05/02...
- Page 5 FRT21KD3A Publication No. 5995372298 CABINET A = FRT21KD3A (FRT21KD3AQ3, FRT21KD3AT3) B = FRT21KD3A (FRT21KD3AQ4, FRT21KD3AT4) C = FRT21KD3A (FRT21KD3AW3, FRT21KD3AZ3) D = FRT21KD3A (FRT21KD3AW4, FRT21KD3AZ4) POS. NO PART NO DESCRIPTION 240355402 A B C D Cover-fan 240367001 A B C D Knob-damper control 5303001028 A B C D...
- Page 6 Publication No. FRT21KD3A 5995372298 SHELVES 05/02...
- Page 7 FRT21KD3A Publication No. 5995372298 SHELVES A = FRT21KD3A (FRT21KD3AQ3, FRT21KD3AT3) B = FRT21KD3A (FRT21KD3AQ4, FRT21KD3AT4) C = FRT21KD3A (FRT21KD3AW3, FRT21KD3AZ3) D = FRT21KD3A (FRT21KD3AW4, FRT21KD3AZ4) POS. NO PART NO DESCRIPTION 215667501 A B C D Tray,ice cube ,plastic 240358003 A B C D Shelf,freezer ,full-width ,wire 5303299664 A B C D...
- Page 8 Publication No. FRT21KD3A 5995372298 SYSTEM 05/02...
- Page 9 FRT21KD3A Publication No. 5995372298 SYSTEM A = FRT21KD3A (FRT21KD3AQ3, FRT21KD3AT3) B = FRT21KD3A (FRT21KD3AQ4, FRT21KD3AT4) C = FRT21KD3A (FRT21KD3AW3, FRT21KD3AZ3) D = FRT21KD3A (FRT21KD3AW4, FRT21KD3AZ4) POS. NO PART NO DESCRIPTION 240444401 A B C D Condenser,dynamic 218944001 A B C D Drier-filter,R134a System 240496101 A B C D...
-
Page 10: Wiring Schematic
Publication No. FRT21KD3A 5995372298 WIRING SCHEMATIC 05/02... -
Page 11: Wiring Diagram
FRT21KD3A Publication No. 5995372298 WIRING DIAGRAM # = Fast-moving Parts 05/02 * = Non-Illustrated Parts...
