Frigidaire FRS23H5DS Factory Parts Catalog
Side by side
refrigerator
Hide thumbs
Also See for FRS23H5DS:
- Factory parts catalog (22 pages) ,
- Factory parts catalog (24 pages) ,
- Factory parts catalog (22 pages)
Table of Contents
Advertisement
Quick Links
N58L00001.eps N58FCCBBB2.eps N58RCCBBB5.eps N58BAAAAB1.eps
N58SBBKBD1.eps N58TAAAAB3.eps N58CAAAAC0.eps N58XBAAAB0.eps
N58YDAAACO.eps n58I115T.eps W241526901A.eps S241526901A.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
FRS23H5DSB1 FRS23H5DSB2 FRS23H5DSB3
Series
R134a
Color
stain/blk
Volts
115
Wiring Diagram
241526901
Owner's Guide
241572800
Market
North America
Energy Guide
241538735
Service Data Sheet 240389618
Publication No.
5995415709
04/08/26
(EN/SERVICE/KHB)
357
R134a
R134a
stain/blk
stain/blk
115
115
241526901
241526901
241572800
241572800
North America
North America
241538735
241538735
240389618
240389618
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS23H5DS
©
Copyright
2004 Home Pr
All rights reserved.
oducts, Inc.
Advertisement
Table of Contents
Related Manuals for Frigidaire FRS23H5DS
Summary of Contents for Frigidaire FRS23H5DS
- Page 1 Product No. FRS23H5DSB1 FRS23H5DSB2 FRS23H5DSB3 Series R134a R134a R134a Color stain/blk stain/blk stain/blk Volts Wiring Diagram 241526901 241526901 241526901 Owner's Guide 241572800 241572800 241572800 Market North America North America North America Energy Guide 241538735 241538735 241538735 Service Data Sheet 240389618 240389618 240389618 SIDE-BY-SIDE...
-
Page 2: Freezer Door
Publication No: 5995415709 FRS23H5DS FREEZER DOOR N58FCCBBB2 08/04... - Page 3 FRS23H5DS Publication No: 5995415709 FREEZER DOOR Model Index: A FRS23H5DS (FRS23H5DSB1) B FRS23H5DS (FRS23H5DSB2) C FRS23H5DS (FRS23H5DSB3) POS. NO PART NO. DESCRIPTION 240390608 A B C Gasket-frzr door, black, magnetic 240367301 A B C Bin-door, frzr-upper 240359001 A B C Bin-door 240554231 A B C...
-
Page 4: Refrigerator Door
Publication No: 5995415709 FRS23H5DS REFRIGERATOR DOOR N58RCCBBB5 08/04... - Page 5 FRS23H5DS Publication No: 5995415709 REFRIGERATOR DOOR Model Index: A FRS23H5DS (FRS23H5DSB1) B FRS23H5DS (FRS23H5DSB2) C FRS23H5DS (FRS23H5DSB3) POS. NO PART NO. DESCRIPTION 240390607 A B C Gasket-refr door, black, magnetic 240363701 A B C Bin-door, 2-liter 240338303 A B C Door, dairy, clear 240581905 A B C...
- Page 6 Publication No: 5995415709 FRS23H5DS CABINET N58BAAAAB1 08/04...
- Page 7 FRS23H5DS Publication No: 5995415709 CABINET Model Index: A FRS23H5DS (FRS23H5DSB1) B FRS23H5DS (FRS23H5DSB2) C FRS23H5DS (FRS23H5DSB3) POS. NO PART NO. DESCRIPTION 240435907 A B C Cover-air duct 240475906 A B C Cover-evap coil, lower 5303208309 A B C Plug-hole, factory test 14 # 240505801 A B C...
- Page 8 Publication No: 5995415709 FRS23H5DS SHELVES N58SBBKBD1 08/04...
- Page 9 FRS23H5DS Publication No: 5995415709 SHELVES Model Index: A FRS23H5DS (FRS23H5DSB1) B FRS23H5DS (FRS23H5DSB2) C FRS23H5DS (FRS23H5DSB3) POS. NO PART NO. DESCRIPTION 241510603 A B C Trim-basket 240338801 A B C Shelf-freezer, flip-up 240338703 A B C Shelf-freezer, fixed wire 240355211 A B C Shelf-"Spill-Safe", fixed 240355209...
- Page 10 Publication No: 5995415709 FRS23H5DS CONTROLS 08/04...
- Page 11 FRS23H5DS Publication No: 5995415709 CONTROLS Model Index: A FRS23H5DS (FRS23H5DSB1) B FRS23H5DS (FRS23H5DSB2) C FRS23H5DS (FRS23H5DSB3) POS. NO PART NO. DESCRIPTION 5308000010 A B C Fan Blade, red, evaporator fan 215474201 A B C Washer, "slinger", nylon, evap fan shaft 241563601 A B C Bushing-motor mtg, (2)
- Page 12 Publication No: 5995415709 FRS23H5DS SYSTEM 08/04...
- Page 13 FRS23H5DS Publication No: 5995415709 SYSTEM Model Index: A FRS23H5DS (FRS23H5DSB1) B FRS23H5DS (FRS23H5DSB2) C FRS23H5DS (FRS23H5DSB3) POS. NO PART NO. DESCRIPTION 240333602 A B C Condenser 218679606 A B C Block-evap coil, styrofoam, (2) 218944001 A B C Drier-filter, R134a System 240346402 A B C Harness-wiring, machine compt...
-
Page 14: Ice And Water Dispenser
Publication No: 5995415709 FRS23H5DS ICE & WATER DISPENSER 08/04... - Page 15 FRS23H5DS Publication No: 5995415709 ICE & WATER DISPENSER Model Index: A FRS23H5DS (FRS23H5DSB1) B FRS23H5DS (FRS23H5DSB2) C FRS23H5DS (FRS23H5DSB3) POS. NO PART NO. DESCRIPTION 218976409 A B C Tube-water 218976901 A B C Tube-water inlet, inlet valve, to ice maker 218976903 A B C Tube-water inlet, inlet valve, to filter...
-
Page 16: Ice Container
Publication No: 5995415709 FRS23H5DS ICE CONTAINER 37A 34 34 33 N58YDAAAC0 08/04... - Page 17 FRS23H5DS Publication No: 5995415709 ICE CONTAINER Model Index: A FRS23H5DS (FRS23H5DSB1) B FRS23H5DS (FRS23H5DSB2) C FRS23H5DS (FRS23H5DSB3) POS. NO PART NO. DESCRIPTION 5304428402 A B C Auger-ice 5304404343 A B C Cam-drive 241561301 A B C Container-ice, bucket only 5304404346 A B C Drum-ice disp 241561401...
-
Page 18: Ice Maker
Publication No: 5995415709 FRS23H5DS ICE MAKER INSTALLATION PARTS N58I115T 08/04... - Page 19 FRS23H5DS Publication No: 5995415709 ICE MAKER Model Index: A FRS23H5DS (FRS23H5DSB1) B FRS23H5DS (FRS23H5DSB2) C FRS23H5DS (FRS23H5DSB3) POS. NO PART NO. DESCRIPTION 218976409 A B C Tube-water 218976901 A B C Tube-water inlet, inlet valve, to ice maker 218976903 A B C Tube-water inlet, inlet valve, to filter 218976907 A B C...
- Page 20 Publication No: 5995415709 FRS23H5DS ICE MAKER INSTALLATION PARTS N58I115T 08/04...
- Page 21 FRS23H5DS Publication No: 5995415709 ICE MAKER Model Index: A FRS23H5DS (FRS23H5DSB1) B FRS23H5DS (FRS23H5DSB2) C FRS23H5DS (FRS23H5DSB3) POS. NO PART NO. DESCRIPTION 240542901 A B C Cap-water valve 5303001343 A B C Screw, hex washer head, 8-15A x 0.500 5303001549 A B C Clamp, 0.31 ID, steel, copper wtr line 5304436611...
-
Page 22: Wiring Schematic
Publication No: 5995415709 FRS23H5DS WIRING SCHEMATIC 08/04... -
Page 23: Wiring Diagram
FRS23H5DS Publication No: 5995415709 WIRING DIAGRAM 08/04 # Functional Parts * Non-Illustrated Parts...
