Frigidaire FRS23H7CS Factory Parts Catalog

Frigidaire frs23h7cs: supplementary guide
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PRODUCT NO.
FRS23H7CSB0
MARKET
North America
ENERGY GUIDE - 240592210
OWNER'S GUIDE - 240389311
SERVICE DATA SHEET - 240389610
ELECTROLUX HOME PRODUCTS, INC
P.O. BOX 212378, Augusta, GA 30917
BASE MODEL NO.
SERIES
FRS23H7C
R134a Gallery
Publication No.
5995391876
-EN/SERVICE/KHB
COLOR
black
030616
357
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY
PARTS CATALO
VOLTS
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS23H7CS
G

Advertisement

Table of Contents
loading

Related Manuals for Frigidaire FRS23H7CS

Summary of Contents for Frigidaire FRS23H7CS

  • Page 1 SERVICE DATA SHEET - 240389610 ELECTROLUX HOME PRODUCTS, INC P.O. BOX 212378, Augusta, GA 30917 SERIES COLOR R134a Gallery black SIDE BY SIDE REFRIGERATOR Publication No. 5995391876 030616 -EN/SERVICE/KHB ©2003 Electrolux Home Products, Inc. All rights reserved FACTORY PARTS CATALO VOLTS Model No. FRS23H7CS...

  • Page 2: Freezer Door

    Publication No. FRS23H7CSB0 5995391876 FREEZER DOOR 06/03...
  • Page 3 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRS23H7CSB0 FREEZER DOOR PART NO DESCRIPTION 240390608 Gasket-frzr door, black, magnetic 240367301 Bin-door, frzr-upper 240359001 Bin-door 240554224 Door-frzr, stainless steel, complete assy 240581906 Door Stop, black, frzr 240359108 Handle-door, black, LH 218781100 Screw,pan head ,8-18 x 0.625 240598401...

  • Page 4: Refrigerator Door

    Publication No. FRS23H7CSB0 5995391876 REFRIGERATOR DOOR 06/03...
  • Page 5 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRS23H7CSB0 REFRIGERATOR DOOR PART NO DESCRIPTION 240390607 Gasket-refr door, black, magnetic 240363702 Bin-door, 2-liter 240338303 Door, dairy, clear 240572601 Label-nameplate 240581905 Door Stop, black, ref 240451979 Door-refr, stainless steel, complete assy...
  • Page 6 Publication No. FRS23H7CSB0 5995391876 CABINET 06/03...
  • Page 7 POS. NO 14 # 14A# 66B* 100* # = Fast-moving Parts * = Non-Illustrated Parts FRS23H7CSB0 CABINET PART NO DESCRIPTION 240435901 Cover-air duct 240475901 Cover-evap coil,lower 5303208309 Plug-hole,factory test 240505801 Switch,light/lamp 215486600 Switch-light/lamp 218252200 Screw,#8 truss hd ,10-32CA x 0.500 240457701 Plate-door closer 240402701...
  • Page 8 Publication No. FRS23H7CSB0 5995391876 SHELVES 06/03...
  • Page 9 POS. NO 16A* 42A* 42A* 140A # = Fast-moving Parts * = Non-Illustrated Parts FRS23H7CSB0 SHELVES PART NO DESCRIPTION 240434603 Trim-basket 240350648 Shelf-freezer, glass, lower 240350647 Shelf-freezer, glass, upper 240588001 Light Bulb 240436702 Light Bulb/Lamp, A-15, clear, 40 W, 120 V, miniature 240590401 Socket-light 218906801...
  • Page 10 Publication No. FRS23H7CSB0 5995391876 CONTROLS 06/03...
  • Page 11 POS. NO 13 # 137* 139* 199* # = Fast-moving Parts * = Non-Illustrated Parts FRS23H7CSB0 CONTROLS PART NO DESCRIPTION 5308000010 Fan Blade, red, evaporator fan 5300157666 Bushing-motor mtg, (2) 5303292396 Bracket-motor mtg, front 240315802 Motor-evap fan 215474201 Washer, "slinger", nylon, evap fan shaft 5303292397 Bracket-motor mtg,rear 240436702...
  • Page 12 Publication No. FRS23H7CSB0 5995391876 SYSTEM 06/03...
  • Page 13 POS. NO 14 # 15 # 29 # 30 # 55 # 60 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts FRS23H7CSB0 SYSTEM PART NO DESCRIPTION 240333602 Condenser 218679606 Block-evap coil, styrofoam ,(2) 218944001 Drier-filter, R134a System 240346402 Harness-wiring, machine compt 240449601...
  • Page 14 Publication No. FRS23H7CSB0 5995391876 DISPENSER 06/03...
  • Page 15 POS. NO 38A# 38C* # = Fast-moving Parts * = Non-Illustrated Parts FRS23H7CSB0 DISPENSER PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet, inlet valve to ice maker 218976903 Tube-water inlet, inlet valve to filter 218976907 Tube-water inlet, valve to door 5304422012 Cover-module,black 5304433616...

  • Page 16: Ice Container

    Publication No. FRS23H7CSB0 5995391876 ICE CONTAINER 06/03...
  • Page 17 POS. NO 18 # 45 # # = Fast-moving Parts * = Non-Illustrated Parts FRS23H7CSB0 ICE CONTAINER PART NO DESCRIPTION 5304428402 Auger-ice 5304404343 Cam-drive 218815300 Container-ice,bucket only 5304404346 Drum-ice disp 5304422805 Front-ice container 5304404337 Bar-drive 5304404359 Gate 5303001179 Light Bulb/Lamp,40 W 5303289050 Socket-light/lamp 5304404345...

  • Page 18: Ice Maker

    Publication No. FRS23H7CSB0 5995391876 ICE MAKER 06/03...
  • Page 19 POS. NO 11 # 12 # 13 # 15 # 17 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts FRS23H7CSB0 ICE MAKER PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet, inlet valve to ice maker 218976903 Tube-water inlet, inlet valve to filter 218976907 Tube-water inlet, valve to door 240561701...

  • Page 20: Wiring Schematic

    Publication No. FRS23H7CSB0 5995391876 WIRING SCHEMATIC 06/03...

  • Page 21: Wiring Diagram

    FRS23H7CSB0 Publication No. 5995391876 WIRING DIAGRAM # = Fast-moving Parts 06/03 * = Non-Illustrated Parts...
