PRODUCT NO.
BASE MODEL NO.
FRS23H5ASB8
FRS23H5AS
MARKET
North America
WIRING DIAGRAM - # 240389613
OWNER'S GUIDE - # 240389311
SERVICE DATA SHEET - #240389613
ELECTROLUX HOME PRODUCTS, INC.
P.O. BOX 212378, Augusta, GA 30917
SERIES
COLOR
R134a
stainless/black
Publication No.
5995394151
030814
-EN/SERVICE/KHB
357
PARTS CATALO
VOLTS
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS23H5AS
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY
G

Advertisement

Table of Contents
loading

Related Manuals for Frigidaire FRS23H5AS

Summary of Contents for Frigidaire FRS23H5AS

  • Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRS23H5ASB8 FRS23H5AS R134a stainless/black MARKET North America WIRING DIAGRAM - # 240389613 OWNER’S GUIDE - # 240389311 SERVICE DATA SHEET - #240389613 SIDE BY SIDE REFRIGERATOR ELECTROLUX HOME PRODUCTS, INC. Model No.

  • Page 2: Freezer Door

    Publication No. FRS23H5ASB8 5995394151 FREEZER DOOR 08/03...
  • Page 3 FRS23H5ASB8 Publication No. 5995394151 FREEZER DOOR POS. NO PART NO DESCRIPTION 240390608 Gasket-frzr door,black ,magnetic 240367301 Bin-door,frzr-upper 240359001 Bin-door 240554231 Door-frzr, stainless steel, complete assy 240581906 Door Stop, black ,frzr 240359108 Handle-door, black ,LH 218781100 Screw, pan head ,8-18 x 0.625 240598401 Screw, 10-32 x 1/2 240521302...

  • Page 4: Refrigerator Door

    Publication No. FRS23H5ASB8 5995394151 REFRIGERATOR DOOR 08/03...
  • Page 5 FRS23H5ASB8 Publication No. 5995394151 REFRIGERATOR DOOR POS. NO PART NO DESCRIPTION 240390607 Gasket-refr door,black ,magnetic 240363701 Bin-door,2-liter 240338303 Door,dairy ,clear 240581905 Door Stop,black ,ref 240451985 Door-refr,stainless steel, complete assy 240359103 Handle-door,black ,RH 218781100 Screw,pan head ,8-18 x 0.625 240598401 Screw,10-32 x 1/2 240521302 Screw,#8-18 x 3/4 240328201...
  • Page 6 Publication No. FRS23H5ASB8 5995394151 CABINET 08/03...
  • Page 7 FRS23H5ASB8 Publication No. 5995394151 CABINET POS. NO PART NO DESCRIPTION 240435901 Cover-air duct 240475901 Cover-evap coil,lower 5303208309 Plug-hole,factory test 240505801 Switch,light/lamp 14A# 215486600 Switch-light/lamp 218252200 Screw,#8 truss hd ,10-32CA x 0.500 240457701 Plate-door closer 240402701 Screw-#10-32 x 1/4 flat hd 240335501 Bolt-roller adj,hex wshr hd, 1/4-20 x 4.020, (2), special 240419103...
  • Page 8 Publication No. FRS23H5ASB8 5995394151 SHELVES 08/03...
  • Page 9 FRS23H5ASB8 Publication No. 5995394151 SHELVES POS. NO PART NO DESCRIPTION 240434603 Trim-basket 240338801 Shelf-freezer,flip-up 240338703 Shelf-freezer,fixed wire 240355211 Shelf-"Spill-Safe", fixed 240355209 Shelf-"Spill-Safe", fixed 240350107 Shelf-"Spill-Safe", cantilever ,sliding 240354502 Cover-crisper pan, upper 240362101 Clip-slide, cover-crisper 240354602 Cover-crisper pan, lower 240354705 Pan-crisper, upper 240349801 Clip-slide, pan-crisper 240351101...
  • Page 10 Publication No. FRS23H5ASB8 5995394151 CONTROLS 08/03...
  • Page 11 FRS23H5ASB8 Publication No. 5995394151 CONTROLS POS. NO PART NO DESCRIPTION 5308000010 Fan Blade, red, evaporator fan 5300157666 Bushing-motor mtg, (2) 5303292396 Bracket-motor mtg, front 13 # 240369701 Motor-evap fan 215474201 Washer, "slinger", nylon, evap fan shaft 5303292397 Bracket-motor mtg, rear 240436702 Light Bulb/Lamp, A-15, clear, 40 W, 120 V, miniature 241513901...
  • Page 12 Publication No. FRS23H5ASB8 5995394151 SYSTEM 08/03...
  • Page 13 FRS23H5ASB8 Publication No. 5995394151 SYSTEM POS. NO PART NO DESCRIPTION 240333602 Condenser 218679606 Block-evap coil, styrofoam ,(2) 218944001 Drier-filter, R134a System 240346402 Harness-wiring, machine compt 240449601 Harness-wiring 241508102 Harness-wiring, control box 14 # 5303918253 Defrost Heater Kit 15 # 5303918286 Evaporator Kit 5308000110 Strap-evap/heater, aluminum, (2)
  • Page 14 Publication No. FRS23H5ASB8 5995394151 DISPENSER 08/03...
  • Page 15 FRS23H5ASB8 Publication No. 5995394151 DISPENSER POS. NO PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet, inlet valve to ice maker 218976903 Tube-water inlet, inlet valve to filter 218976907 Tube-water inlet, valve to door 5304422012 Cover-module, black 5304422013 Module-dispenser 5304426649 Spring-torsion 240323910 Label-module cover, black 5304421616...

  • Page 16: Ice Container

    Publication No. FRS23H5ASB8 5995394151 ICE CONTAINER 08/03...
  • Page 17 FRS23H5ASB8 Publication No. 5995394151 ICE CONTAINER POS. NO PART NO DESCRIPTION 5304428402 Auger-ice 5304404343 Cam-drive 218815300 Container-ice, bucket only 5304404346 Drum-ice disp 218815400 Front-ice container 5304404337 Bar-drive 5304404359 Gate 5303001179 Light Bulb/Lamp, 40 W 5303289050 Socket-light/lamp 5304404345 Drive Blade 18 # 240326901 Motor-auger 5304404335...

  • Page 18: Ice Maker

    Publication No. FRS23H5ASB8 5995394151 ICE MAKER 08/03...
  • Page 19 FRS23H5ASB8 Publication No. 5995394151 ICE MAKER POS. NO PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet, inlet valve to ice maker 218976903 Tube-water inlet, inlet valve to filter 218976907 Tube-water inlet, valve to door 240561701 Seal-water inlet, inlet valve to ice maker 5304420650 Spring,shut-off arm 3206299...

  • Page 20: Wiring Schematic

    Publication No. FRS23H5ASB8 5995394151 WIRING SCHEMATIC 08/03...

  • Page 21: Wiring Diagram

    FRS23H5ASB8 Publication No. 5995394151 WIRING DIAGRAM # = Fast-moving Parts 08/03 * = Non-Illustrated Parts...
