HEATING ELEMENT

(3-WAY MODELS ONLY)
Check the heating element with ohms resistance using a properly calibrated ohm meter.
You should obtain the following readings, plus or minus 10%:
RM2310
RM2410
RM2510
RM2610
RM2810
RM2453
RM2553
A continuity reading will indicate an open or complete circuit.

FLAME INDICATOR METER

If the from the thermocouple are 5 millivolts or more, the red needle in the meter
millivolts

LP GAS REQUIREMENTS

The LP gas pressure to the refrigerator should be 11 inches water
column with half of all BTU's of the RV turned on. With all other
appliances turned off, the pressure to the refrigerator should not
exceed 12 inches water column. To check the gas pressure when
the refrigerator is operating, there is a pressure test housing
located just prior to the orifice.

LP GAS COMPONENTS

SHUT-OFF VALVE

To check the shut-off valve, remove and inspect
for any obstructions.
MANUAL
GAS VALVE
1.15 OHMS
1.15 OHMS
.82 OHMS
.67 OHMS
.67 OHMS
.83 OHMS
.83 OHMS
REFRIGERATORS WITH TOP MOUNT CONTROLS
12
should
PRESSURE TEST HOUSING
REFRIGERATORS WITH
BOTTOM MOUNT
CONTROLS
MANUAL GAS SHUTOFF VALVE
MANUAL
GAS VALVE
be in the green section.
