OWNER'S MANUAL
32" TFT LCD TV WITH DVD PLAYER
LCDWDVD320
When shipped from the factory, the TV/CABLE menu option is set to the "CABLE" (Cable Television) mode.
If not using CABLE, set this menu option to the "TV" position.
PLEASE HAVE THE MODEL NUMBER READY PRIOR TO THE CALL
FOR INFORMATION ON OUR OTHER PRODUCTS, PLEASE VISIT OUR WEBSITE AT
Before operating the unit, please read this manual thoroughly.
TV/CABLE MODE SELECTION
IF CONTACT WITH CUSTOMER SERVICE IS REQUIRED
CUSTOMER SERVICE – 1-800-289-0980
ORION WEBSITE
www.orionsalesinc.com
R

Advertisement

Table of Contents
loading

Related Manuals for Sansui LCDWDVD320

Summary of Contents for Sansui LCDWDVD320

  • Page 1 OWNER’S MANUAL 32” TFT LCD TV WITH DVD PLAYER LCDWDVD320 TV/CABLE MODE SELECTION When shipped from the factory, the TV/CABLE menu option is set to the “CABLE” (Cable Television) mode. If not using CABLE, set this menu option to the “TV” position. IF CONTACT WITH CUSTOMER SERVICE IS REQUIRED PLEASE HAVE THE MODEL NUMBER READY PRIOR TO THE CALL CUSTOMER SERVICE –...
  • Page 2 RAIN OR MOISTURE. FCC Declaration of Conformity Compliance Statement (Part 15): The Sansui LCDWDVD320, LCD TV/DVD Combination complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. 2) Keep these instruction. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. 8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

  • Page 4: Safety Precautions

    SAFETY PRECAUTIONS The unit emits heat when in operation. Do not place any covers or blankets on the unit, this may cause overheating. Do not block ventilation holes, or set up near radiators. Do not place in direct sunshine. When placing on a shelf leave 10 cm (4 inches) free space around the entire unit.

  • Page 5: Features

    Features LCD color TV With DVD/CD player Unique space saving design combines a 32” LCD color TV and a DVD/CD player. A DVD disc has much more capacity, but is the same size as an audio CD disc. The Picture/Audio quality of a DVD exceeds other software.

  • Page 6: Table Of Contents

    Contents Before using your unit Playback operation Preparation/Status display of disc ....33 IMPORTANT SAFETY INSTRUCTIONS ..3 Playback procedure ........34 SAFETY PRECAUTIONS ......4 Special playback ........35 IMPORTANT NOTICE ......... 4 MP3/WMA/JPEG playback ......36 Features ............5 Setting the JPEG interval ......

  • Page 7: Disc

    Disc Playable discs Disc type and logo mark content CAUTION: • Only the left types of discs can be played on this unit. Audio DVD-ROM, CD-ROM, SVCD, CVD, VCD, etc. cannot be played. Video DVD Video • When you play an 8 cm disc, please assemble it with an (moving off-the-shelf disc adapter before you insert it into the unit.

  • Page 8: Location Of Controls

    Location of controls POWER button EJECT button INPUT button SKIP buttons MENU button STOP button VOLUME UP/DOWN buttons PLAY button CHANNEL UP/DOWN buttons Front Remote sensor POWER indicator Left Side Right Side DISC slot Headphone jack S-VIDEO AUDIO (L/R)/VIDEO IN (VIDEO2) jacks...
  • Page 9 Location of controls (continued) Rear CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: SHOCK HAZARD-DO NOT OPEN AVIS: RISQUE DE CHOC ELECTRIQUE-NE PAS OUVRIR. S-VIDEO IN (VIDEO2) jack VIDEO/AUDIO (L/R) IN (VIDEO2) jacks COMPONENT (Y, P ) IN 2 jacks COMPONENT AUDIO (L/R) IN 2 jacks AC IN socket RF (ANT) IN jack...

  • Page 10: Remote Control

    Remote control Page POWER Power On/Off 14,15,33,34 DISPLAY Call TV information 16,20 Call DVD information TV/DVD Switch between TV/AV and DVD 14,33,34,46 5 (EJECT) Eject a disc 34,51 Direct channel selection of TV 15,18 Input setting 23,26,36,37,40,42 Enter a password 19~21,49~51 VOL +/–...

  • Page 11: Power Source

    Remote control (continued) Inserting Batteries Open the battery compart- Install two “AAA” batteries Replace the compartment ment cover in the direction of (supplied), paying attention to cover. the arrow. the polarity diagram in the battery compartment. Operation • Aim the remote control at the remote sensor and press control buttons to operate.

  • Page 12: Antenna Connections

    Antenna connections If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your antenna system. If you are using a Cable TV service, see page 13 for Cable TV connections. Combination VHF/UHF Antenna (Single 75 ohm cable or 300 ohm twin-lead wire) Connect the 75 ohm cable from the combination Antenna Antenna...

  • Page 13: Cable Tv Connections

    Cable TV connections This TV/DVD has an extended tuning range and can tune most cable channels without using a Cable TV Converter box. Some cable companies offer “premium pay channels” where the signal is scrambled. Descrambling these signals for normal viewing requires the use of a descrambler device which is generally provided by the Cable TV company.

  • Page 14: Setting The On-Screen Display Language

    Setting the on-screen display language You can choose from three different Press POWER to turn on the unit. languages (English, French and Spanish) for the on-screen displays. Press TV/DVD to select the TV mode. Press SETUP/TV MENU. The TV menu screen will appear. Press to select (SETUP) menu.

  • Page 15: Tv Operation

    TV operation To turn on the unit, press POWER. Adjust the volume level by pressing VOL + or – . The volume level will be indicated on the screen by white bars. As the volume level increases, VOLUME so do the number of bars. If the volume decreases, the number of white bars also decreases.

  • Page 16: Quick View

    TV operation (continued) Press and release CH . The channel automatically stops at the next channel set into memory. For proper operation, before selecting A N T A B C D channels, they should be set into the 0 1 2 memory.

  • Page 17: Memorizing Channels

    Memorizing channels This TV/DVD is equipped with a channel memory feature which allows channels to skip up or down to the next channel set into memory, skipping over unwanted channels. Before selecting channels, they must be programmed into the TV/DVD’s memory. In addition to normal VHF and UHF channels, this TV/ DVD can receive up to 113 Cable TV channels.
  • Page 18 Memorizing channels (continued) Automatic memory tuning Press SETUP/TV MENU in the TV mode. The TV menu screen will appear. Press to select (SETUP) menu, then press S E T U P to select “AUTO CH MEMORY”. L A N G UAG E E N G L I S H C L O C K S E T 1 2 : 0 0 A M...

  • Page 19: Setting The V-Chip

    Setting the V-Chip An age limitation can be set to restrict children from viewing or hearing violent scenes or picture that you may choose to exclude. The restriction applies to “TV RATING” and “MOVIE RATING” if this data is transmitted. You may set this restriction separately. To use the V-Chip function, you must register a password.
  • Page 20 Setting the V-Chip (continued) To set the V-Chip Press SETUP/TV MENU in the TV mode. L O C K S Then press to select V- C H I P S E T N E W PA S S WO R D (LOCKS) menu.
  • Page 21 Setting the V-Chip (continued) To change the password Press SETUP/TV MENU in the TV mode. The TV menu screen will appear. Press to select (LOCKS) menu. L O C K S V- C H I P S E T N E W PA S S WO R D : S E L E C T : A D J U S T Press...

  • Page 22: Labeling Channels

    Labeling channels Channel labels appear over the To create channel labels channel number display each time you turn on the TV, select a Select a channel you want to label. channel, or press DISPLAY. You can choose any four charac- Press SETUP/TV MENU in the ters to identify a channel.

  • Page 23: Selecting The Video Input Source

    Selecting the video input source/ Labeling the video input source Selecting the video input source Press INPUT SELECT to view a SOURCE SELECTION signal from another device con- 0. ANT 1. VIDEO1 nected to your TV, such as a VCR 2.

  • Page 24: Setting The Clock

    Setting the clock You must set the clock correctly for EXAMPLE: Setting the clock to “8:30 AM”. the “ON timer” to activate at the correct time. Press SETUP/TV MENU in the TV mode. The TV menu screen will appear. Press to select (SETUP) menu.

  • Page 25: Setting The On Timer

    Setting the on timer This feature allows you to have the EXAMPLE: Turning on the TV to channel 12 at 7:30 AM, daily. TV automatically turn on at a Preparation: predetermined time. If you program Set the clock, if you have not already done so (see page 24). the ON TIMER to daily once, the TV will turn on everyday at the same Press SETUP/TV MENU in the TV mode.

  • Page 26: Setting The Picture Size

    Setting the picture size You can view 480i and 480p Selecting the picture size format programs in a variety of picture sizes—NATURAL, CINEMA Press SETUP/TV MENU in the WIDE and FULL. TV mode, then press SETUP select (SETUP) menu. CLOSED CAPTION Press to select PICTURE SIZE...

  • Page 27: Selecting The Cinema Mode

    Selecting the cinema mode/Using the aspect feature/ Adjusting the back lighting feature To set the CINEMA MODE to FILM A smoother motion may be obtained by setting the Picture Mode to Film when you view a DVD. Press SETUP/TV MENU in the TV mode, then press select (SETUP) menu.

  • Page 28: Adjusting The Picture Preference

    Adjusting the picture preference/Picture control adjustment You can select four picture Adjusting the picture preference modes—SPORTS, STANDARD, MOVIE, and MEMORY—as de- Press SETUP/TV MENU in the TV scribed in the following table: mode, then press to select P I C T U R E (PICTURE) menu.

  • Page 29: Selecting The Color Temperature

    Selecting the color temperature/ Resetting your picture adjustments Selecting the color temperature Change the picture quality by selecting from three preset color temperatures—COOL, MEDIUM, and WARM: Press SETUP/TV MENU in the TV mode, then press P I C T U R E select (PICTURE) menu.

  • Page 30: Closed Caption

    Closed Caption WHAT IS CLOSED CAPTIONING? This television has the capability to decode and display Closed Captioned television programs. Closed Captioning will display text on the screen for hearing impaired viewers or it will translate and display text in another language. Captions: This Closed Caption Mode will display text on the screen in English or another language.

  • Page 31: Selecting Stereo/Second Audio Program (Sap)

    Selecting stereo/Second Audio Program (SAP)/ Sound control adjustment/Turning off the built-in speakers The multi-channel TV sound (MTS) Selecting stereo/Second Audio Program (SAP) feature provides high-fidelity Press SETUP/TV MENU in the TV mode, then press stereo sound. MTS also can transmit a second audio program select (AUDIO) menu.

  • Page 32: Using The Wow Tm Surround Sound Feature

    Using the WOW surround feature/Selecting the HDMI audio input source/Resetting your audio adjustments Using the WOW surround sound feature WOW is a special combination of SRS Labs audio technologies that creates a thrilling surround sound experience with deep, rich bass from stereo sound sources.

  • Page 33: Preparation/Status Display Of Disc

    Preparation/Status display of disc The following pages describe the Preparation setup/operation in DVD mode. Before DVD/CD operation, please make preparations as follows. Insert the AC cord plug into a standard 120V 60Hz polarized AC outlet. • If the AC cord plug is plugged in for the first time, wait for about 5 seconds before pressing POWER.

  • Page 34: Playback Procedure

    Playback procedure Press TV/DVD to select DVD mode. Place the disc in the disc slot with the label side facing forward. (If the disc has a label.) Hold the disc without touching either of its surfaces, align it with the guides, and place it in position. On the screen, “No Disc”...

  • Page 35: Special Playback

    Special playback NOTE: There may be a slight delay Fast Forward Playback between when you press the button Press SEARCH during normal playback. and the function activating. Each press of SEARCH will increase the speed of the search (x 2), (x 4), (x 8), (x 15).

  • Page 36: Mp3/Wma/Jpeg Playback

    MP3/WMA/JPEG playback MP3 CD playback This player can play back MP3/WMA/JPEG- data which has been recorded on CD-R or Insert a disc to play. CD-RW. To produce MP3/WMA/JPEG-data, Hold the disc without you need a Windows-PC with CD-ROM drive touching either of its and MP3/WMA/JPEG-encoding software surfaces, position it with (not supplied).

  • Page 37: Jpeg Cd Playback

    MP3/WMA/JPEG playback (continued) JPEG CD playback Insert a disc to play. Hold the disc without touching either of its surfaces, position it with the label side to be played facing forward (If the disc has a label), align it with the guides, and place it in position.

  • Page 38: Setting The Jpeg Interval

    Setting the JPEG interval You can continuously play back all Language Picture Sound Parental Other Press SETUP/TV MENU in JPEG files automatically. the stop mode. Press to select “Picture”, then press or ENTER. /Enter/Setup/Return Language Picture Sound Parental Other Press to select Tv Screen 16:9...

  • Page 39: Setting The Select Files

    Setting the select files When playing back a CD containing a Press SETUP/TV MENU in mixture of MP3, WMA and JPEG files, Language Picture Sound Parental Other the stop mode. only MP3/WMA or JPEG files will be displayed on the file menu. Press to select “Picture”, then press...

  • Page 40: Zooming

    Zooming/Locating desired scene Zooming This unit will allow you to zoom in on the frame image. You can then make selections by switching the position of the frame. Press ZOOM during playback. The center part of the image will be zoomed in. Each press of ZOOM will change the ZOOM magnification...

  • Page 41: Repeat Playback

    Repeat playback Title, Chapter, Track Playback Press PLAY MODE during playback or stop mode. Audio-CD Play Mode Repeat Repeat /Enter/Play Mode /Enter/Play Mode /Enter/Play Mode Press or ENTER once or twice to select “Chapter” or “Title”. In case of an Audio-CD, first press to select “Repeat”, and then press or ENTER once or twice to select “Track”...

  • Page 42: Program Playback

    Program playback/Random playback (CD) Program playback You can arrange the order of tracks on the disc. Press PLAY MODE in the stop Play Mode mode. Repeat /Enter/Play Mode Press to select Play Mode Program “Play Mode” then press Repeat ENTER to select “Program”. Clear Program Playback /Enter/0 9/Cancel/Play Mode...

  • Page 43: Marking Desired Scenes

    Marking desired scenes The TV/DVD stores the points that you Marking the Scenes want to watch again. You can resume playback from that scene. Press MARKER during Marker playback. Marker Marker /Enter/Cancel/Marker Select the blank Marker Marker using , then press Marker ENTER at the desired Marker...

  • Page 44: Changing Soundtrack Language

    Changing soundtrack language/ Subtitles/Karaoke playback Changing soundtrack language You can select the language when you play a multilingual disc. Press AUDIO during playback. 1/8 Eng Dolby Digital The current soundtrack language will appear. Press AUDIO repeatedly until the desired language 2/8 Fra Dolby Digital is selected.

  • Page 45: Changing Angles

    Changing angles/Title selection/DVD menu Changing angles When playing back a disc recorded with multi-angle facility, you can change the view angle. Press ANGLE during playback. The current angle will appear. Press ANGLE repeatedly until the desired angle is selected. Title selection Two or more titles are recorded on some discs.

  • Page 46: Setting The Language

    Setting the language The setup language can be selected. Press TV/DVD to select No Disc the DVD mode. “No Disc” will appear on the screen (If a DVD disc has already loaded, the playback will start auto- matically). Press SETUP/TV MENU Language Picture Sound Parental Other...

  • Page 47: Setting The Aspect Ratio Of Tv Screen

    Setting the aspect ratio of TV screen/Setting on screen display Setting the aspect ratio of TV screen You can select the aspect ratio of the picture. Press SETUP/TV MENU in the Language Picture Sound Parental Other stop mode or No Disc. Press to select “Picture”.

  • Page 48: Dynamic Range Control

    Dynamic Range Control DRC (Dynamic Range Control) Press SETUP/TV MENU enables you to control the dynamic Language Picture Sound Parental Other in the stop mode or No range so as to achieve a suitable Disc. sound for your equipment. Press to select “Sound”.

  • Page 49: Parental Control Setting

    Parental control setting Some discs are specified not suit- able for children. Such discs can be Language Picture Sound Parental Other Press SETUP/TV MENU in limited not to play back with the unit. the stop mode or No Disc. Password Press to select Parental...

  • Page 50: Changing The Parental Level

    Changing the parental level Language Picture Sound Parental Other Press SETUP/TV MENU in the stop mode or No Disc. Password Press to select Parental “Parental”. Then press ENTER. 0 9/Cancel /Enter/Setup/Return Language Picture Sound Parental Other Press Number buttons (0-9) to enter the password you Password 1234...

  • Page 51: Temporary Disabling Of Rating Level By Dvd Disc

    Temporary disabling of rating level by DVD disc Depending on the DVD disc, the disc Load a DVD disc (see page 34). may try to temporarily cancel the rating level that you have set. It is up to you to decide whether to cancel the rating level or not.

  • Page 52: Setting The Language

    Setting the language You can select the language of “Menu”, “Subtitle” and “Audio” if Press SETUP/TV MENU in the Language Picture Sound Parental Other more than one languages are stop mode. recorded onto the disc. Press to select “Language”. /Enter/Setup/Return Language Pi c ture Sound Parental...

  • Page 53: Language Code List

    Language code list Enter the appropriate code number for the initial settings “Menu”, “Subtitle” and/or “Audio” (see page 52). Language Name Code Language Name Code Language Name Code Language Name Code Abkhazian 1112 Fiji 1620 Lingala 2224 Singhalese 2919 Afar 1111 Finnish 1619...

  • Page 54: Connections To Other Equipment

    Connections to other equipment The exact arrangement you use to interconnect various video and audio components to this unit is dependent on the model and features of each component. Check the Owner's Manual provided with each component for the location of video and audio inputs and outputs. To connect the LCD TV/DVD to a VCR Rear lower right of the unit To Audio/Video OUT...
  • Page 55 Connections to other equipment (continued) To connect a HDMI or a DVI device to the unit The HDMI input receives digital audio and uncompressed video from a HDMI device or uncompressed digital video from a DVI device. When you connect to a DVI device with a HDMI-to-DVI adapter cable, it transfers only video signal. Separate analog audio cords required.
  • Page 56 Connections to other equipment (continued) To connect an audio system or Subwoofer This connection allows you to hear the TV sound through external speakers connected to an audio amplifier or subwoofer. To control the audio, turn on the TV/DVD and the stereo amplifier, and turn off the TV/DVD’s built-in speakers (see “Turning off the built-in speakers”...
  • Page 57 Connections to other equipment (continued) To connect the TV/DVD to a camcorder, or a TV Game To playback from a camcorder, connect the camcorder to the unit as shown. This unit can also be used as a display device for many video games. However, due to the wide variety of signals generated by these devices and subsequent hook-up variations required, they have not all been included in the suggested connection diagrams.

  • Page 58: Picture/Audio Control Adjustment In The Pc Mode

    Picture/Audio control adjustment in the PC mode PC Monitor Menu There are a number of picture and audio settings you can adjust to optimize the performance of the unit in PC mode. PICTURE menu AUDIO menu PICTURE AUDIO BRIGHTNESS BASS CONTRAST TREBLE HOR POSITION...

  • Page 59: Reception Disturbances

    Reception disturbances Most types of television interference can be remedied by adjusting the height and position of the VHF/ UHF antenna. Outdoor antennas are recommended for best results. The most common types of television interference are shown below. If one of these symptoms appear when the TV/DVD is connected to a Cable TV system, the disturbance may be caused by the local Cable TV company broadcast.

  • Page 60: Problems And Troubleshooting

    Problems and troubleshooting Use the following check list for troubleshooting when you have problems with your TV/DVD. Consult your local dealer or service outlet if problems persist. Be sure all connections are properly made when using with other units. SYMPTOMS POSSIBLE SOLUTIONS PAGE POWER...
  • Page 61 Problems and troubleshooting (continued) SYMPTOMS POSSIBLE SOLUTIONS PAGE • No disc is inserted. Playback doesn’t start. • The disc may be dirty. Clean up the disc. • The unit cannot play CD-ROMs, etc. No picture. • TV/DVD selector is not set correctly. •...

  • Page 62: Specifications

    Specifications GENERAL Power supply: AC 120V 60Hz Power consumption: Operation: 170W Stand by: 1W Weight: 19 kg (41.9 lbs) Dimensions: Width : 822 mm (32-3/8 inches) Height : 604 mm (23-3/4 inches) Depth : 332.5 mm (13-1/16 inches) Operating temperature: 5°C - 40°C Operating humidity: Less than 80%...

  • Page 63: Limited Warranty

    limited WARRANTY 32” TFT LCD TV WITH DVD PLAYER ORION warrants this product to be free from manufacturing defects in material and workmanship under normal use and conditions for a period of ninety (90) days from date of original purchase in the United States only. Should service be necessary under this warranty for any reason due to a manufacturing defect or malfunction during the first ninety (90) day period from date of original purchase, ORION will provide carry-in repair service at an ORION authorized Independent Service Center at no charge.
  • Page 64 J5V10101A SH 05/10 Printed in Thailand...
