OWNER'S MANUAL
GUIDE D'UTILISATION
22" CLASS WIDE LED TV WITH DVD PLAYER
TÉLÉVISEUR DEL GRAND ÉCRAN CATÉGORIE
22 PO ET LECTEUR DVD
SLEDVD226
If you purchase a universal remote control from your local retailer, please contact the remote manufacturer for the
required programming code.
Si vous utilisez avec cet appareil une télécommande universelle (autre que celle vendue avec ce téléviseur),
consultez la documentation accompagnant la télécommande universelle afin de connaître le code numérique cor-
respondant au téléviseur.
When shipped from the factory, the Signal Type option is set to the "Cable" (Cable Television) mode.
If not using Cable TV, set this menu option to the "Air" position.
Lorsque l'appareil sort de l'usine, l'option Signal Type est en mode « Cable » (câblodistribution). Si vous
n'utilisez pas la câblodistribution, sélectionnez l'option « Air ».
PLEASE HAVE THE MODEL NUMBER READY PRIOR TO THE CALL.
S'IL FAUT CONTACTER LE SERVICE CLIENTÈLE, PRENEZ SOIN D'ÊTRE MUNI
FOR INFORMATION ON OUR OTHER PRODUCTS AND RECYCLING INFORMATION, PLEASE VISIT OUR WEBSITE AT:
POUR OBTENIR DES INFORMATIONS SUR NOS AUTRES PRODUITS ET LE RECYCLAGE, VEUILLEZ VISITER NOTRE SITE WEB:
Before operating the unit, please read this manual thoroughly.
Avant de faire fonctionner l'appareil, veuillez lire le présent guide attentivement.
ATTENTION
ATTENTION
AIR/CABLE MODE SELECTION
SÉLECTION DU MODE AIR/CABLE
IF CONTACT WITH CUSTOMER SERVICE IS REQUIRED
DU NUMÉRO DE MODÈLE AVANT D'APPELER.
CUSTOMER SERVICE – 1-800-289-0980
SERVICE/SERVICE CLIENTÈLE: 1-800-289-0980
ORION WEBSITE
SITE WEB ORION
www.orionsalesinc.com
Advertisement
Table of Contents
Related Manuals for Sansui SLEDVD226
Summary of Contents for Sansui SLEDVD226
- Page 1 OWNER’S MANUAL GUIDE D’UTILISATION 22” CLASS WIDE LED TV WITH DVD PLAYER TÉLÉVISEUR DEL GRAND ÉCRAN CATÉGORIE 22 PO ET LECTEUR DVD SLEDVD226 ATTENTION ATTENTION If you purchase a universal remote control from your local retailer, please contact the remote manufacturer for the required programming code.
- Page 2 ENGLISH The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock. CAUTION: TO REDUCE THE RISK OF ELECTRIC The exclamation point within an...
- Page 3 15) Apparatus should not be exposed to dripping or splashing, and objects filled with liquids, such as vases, should not be placed on the apparatus. 16) An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits.
-
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS (continued) 23) When you connect the product to other equipment, turn off the power and unplug all of the equipment from the wall outlet. Failure to do so may cause an electric shock and serious personal injury. Read the owner's manual of the other equipment carefully and follow the instructions when making any connections. -
Page 5: Safety Precautions
SAFETY PRECAUTIONS The unit emits heat when in operation. Do not place any covers or blankets on the unit, this may cause overheating. Do not block ventilation holes, or set up near radiators. Do not place in direct sunshine. When placing on a shelf leave 10 cm (4 inches) free space around the entire unit. -
Page 6: How To Attach The Stand
How to attach the stand NOTE: • Unplug the AC cord from the AC INPUT terminal. • Before beginning this process, assure that the TV is laid on a clean, safe, and cushioned surface to avoid any damage to the unit. •... -
Page 7: Features
Features LED color TV With DVD/CD player Unique space saving design combines a 22” LED color TV and a DVD/CD player. A DVD disc has much more capacity, but is the same size as an audio CD disc. The Picture/Audio quality of a DVD exceeds other software. -
Page 8: Table Of Contents
Contents Before using your unit DVD operation Preparation .............23 IMPORTANT SAFETY INSTRUCTIONS ...3 Status display of disc ........23 SAFETY PRECAUTIONS .........5 Playback procedure ........23 IMPORTANT NOTICE ........5 Special playback ..........24 How to attach the stand ........6 Zooming ............24 How to remove the stand ........6 Locating desired scene ........24 Features ............7 A-B Repeat playback ........24... -
Page 9: Disc
Disc Playable discs CAUTION: Disc type and logo mark content • Only the left types of discs can be played on this unit. DVD-ROM (for PC), CD-ROM (for PC), SVCD, Audio CVD, VCD, etc. cannot be played. • This unit cannot play an 8 cm disc. It cannot also be DVD Video Video played even using a disc adapter. - Page 10 Disc (continued) ■ Title/Chapter/Track PC-created disc ■ Windows Media Audio (WMA) • You may not be able to play discs recorded compatibility using a personal computer or recorder for disc • WMA is an acronym for Windows Media Audio compatibilities, scratches or marks on the disc, dirty and refers to an audio compression technology lenses of the unit or condensation and so on.
-
Page 11: Parts And Functions
Parts and functions Left side FOR SERVICE PERSONNEL USE ONLY Do NOT insert ANY USB device into this port. Use of this port by other than Service Personnel may void this products Front warranty. HDMI/DVI IN jack ANT. (RF) IN jack VIDEO IN jacks (VIDEO/AUDIO (L (MONO)/R)) -
Page 12: Remote Control
Remote control POWER Power On/Off DISPLAY/– Call TV information Call DVD information Input “–” for digital channels TV/DVD Switch between TV and DVD (EJECT) Eject a disc Direct channel selection of TV Input setting Enter a password VOL +/– Adjust volume of TV MUTE Switch off the sound SLEEP... -
Page 13: Power Source
Remote control (continued) Inserting Batteries Open the battery compartment Install two “AAA” batteries Replace the compartment cover. cover in the direction of the arrow. (supplied), paying attention to the polarity diagram in the battery compartment. Operation • Aim the remote control at the remote sensor and press control buttons to operate. -
Page 14: Antenna Connections
Antenna connections If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your antenna system. If you are using a Cable TV service, see “Cable TV connections”. Combination VHF/UHF Antenna (Single 75-ohm cable) Antenna Connect the 75-ohm cable from the combination Jack VHF/UHF antenna to the Antenna Jack. -
Page 15: Tv Operation
Starting setup TO SELECT ANALOG CHANNELS 1-9: Press 1-9 as needed. Example, to select channel 2, press 2, then press The Auto Setup menu appears the first time you ENTER. turn on the TV, and assists you to specify the 10-99: Press the 2 digits in order. -
Page 16: Quick Guide For Menu Operation
Quick guide for menu DISPLAY Press DISPLAY to display the current information on operation the screen. When the TV receives a digital signal, the digital information will appear. Call menu and for example: Select Language. 62-1 HDTV_Moving_Picture... Sleep Timer Press INPUT SELECT to select TV mode. CH-1 TV-MA English... -
Page 17: Convenience Functions
Convenience functions You can change the default settings by pressing the TV MENU button on your remote, then select the one of the icons at the left of the menu - follow the On-Screen prompts to set your preferences. Icon Selected Items Setup hint Picture... -
Page 18: Memorizing Channels
Memorizing channels The TV will begin memorizing all the channels available in your area. • It may take from 15 minutes to 30 minutes to This TV is equipped with a channel memory complete memorizing digital cable channels. feature which allows channels to skip up or down Depending on the reception condition, a bar to the next channel set into memory, skipping display may not advance for several minutes,... -
Page 19: Checking The Digital Signal Strength
Clear All Ch Label All channels are deleted from the channel memory. Channel Number 15-1 Ch Label CH-1 Label Clear >> Select “Channel”, then press ▶ or ENTER. Press ▲ or ▼ to select “Add/Delete”, then press ▶ or ENTER. :Adjust :Select Press ◀... -
Page 20: Setting The V-Chip
Setting the V-Chip When you select TV-Y7, TV-PG, TV-14 or TV-MA, press DISPLAY to explain the rating. Genre: An age limitation can be set to restrict children from : Dialogue viewing or hearing violent scenes or pictures that you : Language may choose to exclude. -
Page 21: Closed Caption
Press ◀ or ▶ to set “CC Setting” to “On”. Press ◀ or ▶ to set “V-Chip” to “On”. On: Captions will be displayed on the screen. Press ▲ or ▼ to select “V-Chip Set (DTV)”, then Off: Captions will not be displayed on the screen. press ▶... -
Page 22: Setting The Picture Size
Press ▲ or ▼ to select “CC Advanced”, then press ▶ or ENTER. The CC Advanced menu will appear. Press ▲ or ▼ to select the desired item, then press ◀ or ▶ to change the setting. Cinema Wide1 (for 4:3 format programs) To fill the screen, the right and left edges are CC Advanced extended, however;... -
Page 23: Preparation
Preparation On the screen, “ ” changes to “Loading” and then playback will commence. • A menu screen may appear on the TV screen, The following pages describe the setup/ if the disc has a menu feature. In this case, operation in DVD mode. -
Page 24: Special Playback
Special playback In the zoom mode, press ZOOM repeatedly to return to a 1:1 view. Fast Forward Playback Press SEARCH (u u) during normal playback. NOTE: Each press of SEARCH (u u) will increase the speed of • You can select the Still Playback or Fast Forward the search. -
Page 25: Marking Desired Scenes
Marking desired scenes Changing soundtrack language The TV/DVD stores the points that you want to watch again up to 12 points. You can select the language when you play a You can resume playback from each scene. multilingual disc. Marking the scenes Press AUDIO during playback. -
Page 26: Using Home Menu
Using HOME MENU Press ▲/▼ to select “A-B Repeat”, then press ▶ or ENTER. Playing a disc Press ▲/▼ to select “A(Start Point)”, then press Press SETUP during stop mode. ENTER. The start point is selected. HOME MENU will appear. Press ▲/▼... -
Page 27: Audio Settings Menu
Program playback Input Title, Chapter, Play Mode Track or Folder number Press PLAY MODE during playback or stop mode. A-B Repeat Title Search Input Chapter or Time by using Repeat Chapter Search Play Mode screen will appear. Random Time Search 0 0 1 Number buttons Program... -
Page 28: Video Adjust Menu
Video Adjust menu Quick guide for DVD menu operation From the Video Adjust menu you can adjust various settings that affect how the picture is presented. You can change the default settings to customize performance to your preference. Press SETUP during stop mode. HOME MENU will appear. -
Page 29: Function Setup
Function Setup Setting Option Digital Audio Out settings Digital Out Digital audio is output when playing a disc. Digital audio is not output when playing a disc. Dolby Digital Out Dolby Digital Dolby Digital encoded digital audio is output when playing a Dolby Digital DVD disc. -
Page 30: Parental Control
Parental Control Level Change Press ▲ or ▼ to select Initial Settings Some discs are specified as not suitable for children. “Level Change”, then Digital Audio Out Parental Lock Password Change Such discs can be limited not to playback with the Video Output Level Change press ENTER. -
Page 31: Language Code List
Language Code List Language (Language code letter), Language code Japanese (ja), 1001 Bhutani (dz), 0426 Kirghiz (ky), 1125 Sinhalese (si), 1909 English (en), 0514 Esperanto (eo), 0515 Latin (la), 1201 Slovak (sk), 1911 French (fr), 0618 Estonian (et), 0520 Lingala (ln), 1214 Slovenian (sl), 1912 German (de), 0405 Basque (eu), 0521... -
Page 32: Connections To Other Equipment
Connections to other equipment The exact arrangement you use to interconnect various video and audio components to this unit is dependent on the model and features of each component. Check the Owner’s Manual provided with each component for the location of video and audio inputs and outputs. To connect the TV to a VCR Left of the unit To VIDEO/AUDIO IN... - Page 33 Connections to other equipment (continued) Using an AV Amplifier with built-in digital surround If you are using an AV Amplifier with built-in digital surround sound, you can enjoy various audio systems including Dolby Digital Surround audio that sounds just like the movie. Connect an AV amplifier with built-in Dolby Digital decoder, etc.
- Page 34 Connections to other equipment (continued) To connect a HDMI or a DVI device to the unit The HDMI/DVI input receives digital audio and uncompressed video from a HDMI device or uncompressed digital video from a DVI device. When you connect to a DVI device with a HDMI-to-DVI adapter cable, it transfers only video signal. Separate analog audio cords required.
-
Page 35: Reception Disturbances
Reception disturbances Most types of television interference can be remedied by adjusting the height and position of the VHF/ UHF antenna. Outdoor antennas are recommended for best results. The most common types of television interference are shown below. If one of these symptoms appear when the TV is connected to a Cable TV system, the disturbance may be caused by the local Cable TV company broadcast. -
Page 36: Problems And Troubleshooting
Problems and troubleshooting Use the following check list for troubleshooting when you have problems with your TV/DVD. Consult your local dealer or service outlet if problems persist. Be sure all connections are properly made when using with other units. SYMPTOMS POSSIBLE SOLUTIONS PAGE POWER... - Page 37 Problems and troubleshooting (continued) SYMPTOMS POSSIBLE SOLUTIONS PAGE • No disc is inserted. Playback doesn’t start or • The disc may be dirty. Clean up the disc. disc ejects automatically. • The disc is scratched or warped. • The unit cannot play CD-ROMs, etc. No picture.
-
Page 38: Specifications
Specifications GENERAL Power supply: AC 120V, 60Hz Power consumption: Operation: 35W Stand by: 0.3W Weight: 3.6 kg (7.9 lbs) Dimensions: Width: 516.4 mm (20-5/16 inches) Height: 368.2 mm (14-1/2 inches) Depth: 168 mm (6-5/8 inches) Operating temperature: 5˚C - 40˚C Operating humidity: Less than 80% RH TELEVISION... -
Page 39: Limited Warranty
limited WARRANTY 22” CLASS WIDE LED TV WITH DVD PLAYER ORION warrants this product to be free from manufacturing defects in material and workmanship under normal use and conditions for a period of 1 year from date of original purchase in the United States. Should service be necessary under this warranty for any reason due to a manufacturing defect or malfunction during the first 12 months from date of original purchase, ORION will provide carry-in service only by an ORION authorized Independent Service Center at no charge.
