Congratulations on the purchase of
your Hughes & Kettner ATS
The
ATS 120 has been developed to combine optimum sound quality and flexibility with
simple, user-friendly operation.
The ATS 120's design makes the majority of functions self-explanatory. This user
manual is intended to give you an overview of all the possibilities and features of the
amplifier.
Enjoy your ATS 120!
Front panel control elements
(1) INPUTS:
sockets for connecting your instrument cable.
Nowadays, many different electric guitars are available, ranging from the classic Strat
with its "single coil" pickups to modern designs incorporating very high power active
humbucking units. To ensure that all types of pickups can be ideally matched to the
preamp of the ATS 120, two inputs are provided with different sensitivity ratings.
LO:
Input for guitars fitted with high output / active pickup systems.
HI:
Input for guitars fitted with traditional passive pickup systems.
The ATS 120's three channels
The Hughes & Kettner ATS 120 offers three separate channels, each of which has it's
own distinctive sound characteristics. The individual channels offer a wide variety of
different sounds thanks to their independent GAIN / VOLUME controls and
equalisation sections.
Selecting a channel
Above the individual VOLUME or GAIN control of each channel (Clean - Volume,
Crunch - Gain and Lead - Gain) there is a pushbutton which is used to activate it.
The active channel is indicated by an arrow-shaped LED. When using the CRUNCH
and LEAD channels, different coloured LED arrows are used to indicate which GAIN
and MASTER controls are operational.

Advertisement

loading

Related Manuals for Hughes & Kettner ATS 120

Summary of Contents for Hughes & Kettner ATS 120

  • Page 1 Congratulations on the purchase of 120! your Hughes & Kettner ATS ATS 120 has been developed to combine optimum sound quality and flexibility with simple, user-friendly operation. The ATS 120‘s design makes the majority of functions self-explanatory. This user manual is intended to give you an overview of all the possibilities and features of the amplifier.

  • Page 2: Crunch Gain

    The ATS 120 Clean channel The CLEAN Channel is a “solid state” (i.e. transistor) design. This provides the moderr, crystal-clear sounds popular with contemporary recording artists. However, tht traditional passive three-band equalisation controls and the “Soft-Click” circuitry make it possible to reproduce the mild distortion characteristics of a vintage valve amplifier. The “Soft Click”...
  • Page 3 (10) The ATS 120 Lead channel (7) LEAD GAIN: determines the input sensitivity of the LEAD channel, allowing fine tuning of the degree of distortion and the intensity of the compression effect typical for tubes. LEAD FAT: LEAD FAT switch only affects the LEAD channel, it makes the lead sound fuller. Even “thin”-sounding guitars can be given noticeably more punch by using the LEAD FAT function.
  • Page 4 (11) (12) (13) (14) The Reverb. FX- and Master Section of the ATS 120 An ACCUTRONICS spring system is used to produce the reverb effect in the ATS 120. The quality of a reverb unit depends largely on the length and number of springs used; this genuine Accutronics unit generates a warm, realistic effect for the ATS 120 by having three particularly long springs.
  • Page 5 (15) / (16) / (17) (18) (19) The rear panel on the ATS 120 (15) MAINS LEAD SOCKET point for connecting the euro mains lead included with your amplifier. FUSE: (16) safety holder for the mains fuse (AT 1250mA). The fuse holder can be removed by depressing its fixings on both sides.
  • Page 6 (23) (20) (21) (22) via a RED BOX. This socket can also be used to send the preamplifier signal to an external power amp or to additional guitar amplifiers. LINE OUT AND POWER AMP IN: used together the two sockets can provide an extra loop for connecting external effect units.
  • Page 7 ATS 120 Connections EXTERNAL POWER AMPLIFIER and EFFECTS UNIT, or for practice: 2nd Instru- connected speaker cabinet (s). ment, tape recorder, drum machine. INPUT INPUT OUTPUT LINE LINE OUT FX SEND FX RETURN SPEAKERS STAGEBOARD LINE OUT Signal for PA- and Recording/Studio applications.

  • Page 8: Sound Examples

    ATS 120 Sound Examples The examples shown here are only intended as general illustrations, because they are strongly affected by the instrument used and your individual playing style. However, these settings will give you an initial overview of the range which the ATS 120 is capable of producing.
  • Page 9 Care of your amplifier and guarantee conditions A WORD ABOUT VALVES: Valves need to reach a certain operating temperature. They need a few seconds after the power has been switched on to warm up before they will work. Valves are sensitive to shock. Once you have switched the amplifier off, give it a few minutes to cool down before transporting it.
