Your Display Telephone
Button labeling cards
Cards you can label with the line
or feature assigned to each line
button
Contrast control (not shown)
A sliding switch on the top of the
phone used to brighten and dim
the display
Dedicated feature buttons
The 8 imprinted buttons for the
features used most often
Desk stand (not shown)
A support that adjusts to two
heights
Dialpad
The numbered buttons, asterisk
( ), and pound sign ( # )
Display buttons
The Home, Menu, More, and
Inspect buttons that control the
display screens, and the
unlabeled buttons that activate
features shown on the screens
Display screen
A 7-line by 24-character screen
where you view call information,
phone directories, and
instructions for using features
and programming the phone
Handset
The hand-held part of the phone
that you pick up, talk into, and
listen from
Line buttons
The 20 buttons with red and
green lights used to make and
receive calls. You can program
any unlabeled buttons for feature
use.
Message light
A light that goes on when a
co-worker or system operator
leaves a message on your
display or when you have a
voice-mail message or a fax
User cards and tray
Instructions for feature use and
directory information in a sliding
tray under the phone
Volume control
A button for controlling the
volume of the speaker, handset,
and ringer
1-7
MLX-20L
