ECS G43T-M3 Manual page 34

28
CMOS Setup Utility - Copyright (C) 1985-2008, American Megatrends, Inc.
SATA1
Device :
Type
LBA/Large Mode
Block (Multi-Sector Transfer
PIO Mode
DMA Mode
S.M.A.R.T.
32Bit Data Transfer
Type (Auto)
Use this item to configure the type of the IDE device that you specify. If the feature
is enabled, it will enhance hard disk performance by reading or writing more data
during each transfer.
LBA/Large Mode (Auto)
Use this item to set the LBA/Large mode to enhance hard disk performance by
optimizing the area the hard disk is visited each time.
Block (Multi-Sector Transfer) (Auto)
If the feature is enabled, it will enhance hard disk performance by reading or writing
more data during each transfer.
PIO Mode (Auto)
Use this item to set the PIO mode to enhance hard disk performance by optimizing
the hard disk timing.
DMA Mode (Auto)
DMA capability allows user to improve the transfer-speed and data-integrity for
compatible IDE devices.
S.M.A.R.T. (Auto)
The S.M.A.R.T. (Self-Monitoring, Analysis and Reporting Technology) system is a
diagnostics technology that monitors and predicts device performance. S.M.A.R.T.
software resides on both the disk drive and the host computer.
32Bit Data Transfer (Enabled)
Use this item to enable or disable 32Bit Data Transfer.
Press <Esc> to return to the Standard CMOS Setup page.
IDE BusMaster (Enabled)
This item enables or disables the DMA under DOS mode. We recommend you to leave
this item at the default value.
Press <Esc> to return to the main menu setting page.
SATA1
Not Detected
Auto
Auto
Auto
Auto
Auto
Auto
Enabled
: Move Enter : Select
+/-/: Value F10: Save ESC: Exit
F1: General Help
F9: Load Default Settings
Using BIOS
Help Item
Select the type
of device connected
to the system.
