Logic Board - Usb Cable (9W & 24W); Logic Board - Dc Power (9W & 24W) - Lexmark Forms Printer 2400 Service Manual

24xx
Logic Board - USB Cable (9w & 24w)
Connector
CN201
Logic Board - DC Power (9w & 24w)
Connector
CN12
Pin # Signal
1 +5 V dc
2 DMNS
3 DPLS
4 Signal Gnd
Pin # Signal
1 +40 V dc
2 +40 V dc
3 Power Gnd
4 Power Gnd
5 Signal Gnd
6 +5 V dc
7 Power Save Mode
Connector Locations
5-9
