Figure 8
configuration commands for this configuration follow the figure.
Figure 8
slot0:rsp-k-mx11.1
slot0:rsp-k-mx11.2
Active RSP card
Flash memory
Because you always view the environment from the active RSP's perspective, in the following command
Step 1
you view the active PC Card slot 0 to verify the location and version of the active software image:
Router# dir slot0:
-#- -length- -----date/time------ name
1 3482496
7993896 bytes available (1496 bytes used)
Now view the standby software image location and version:
Step 2
Router# dir slaveslot0:
-#- -length- -----date/time------ name
1 3482496
7993896 bytes available (1496 bytes used)
Because you want to run the Cisco IOS Release 12.1(12)E system image on one RSP and the Cisco IOS
Step 3
Release 12.1(13)E system image on the other RSP, copy the Cisco IOS Release 12.1(13)E system image
to the active's slot 0:
Router# copy tftp slot0:rsp-k-mx11.1
32
illustrates the software error protection configuration for this sample scenario. The
Software Error Protection—Upgrading to a New Software Version
boot system flash slot0:rsp-k-mx11.2
boot system flash slot0:rsp-k-mx11.1
.
.
.
May 4 1999 21:38:04 rsp-k-mx11.1
May 4 1999 21:38:04 rsp-k-mx11.1
config.file
slot0:rsp-k-mx11.1
Standby RSP card
Flash memory
