Acesonic KOD-1000 User Manual

Karaoke-on-demand jukebox
Hide thumbs
Table of Contents

Advertisement

Quick Links

User Manual
NOTE: To ensure this system works safely and to its fullest potential, please read the User Manual carefully
before use, and keep it handy for future reference. See important Safety Information on Page 24.
Thank you for purchasing Acesonic's KOD-1000 Ka-
raoke-On-Demand Jukebox. Acesonic takes pride in
providing its customers with only the most advanced
and highest quality products on the market.
With proper care and use you will get many years of
satisfying use from your Acesonic product.
Be sure to keep original packaging in case re-shipping
is required for returns or repairs.
Care and cleaning: Use a slightly damp cloth to clean
the front panel and other surfaces of the KOD-1000.
Do not use the device in areas that are wet or prone
to dampness. Always allow sufficient room around the
device to provide sufficient air flow for cooling.
KOD-1000
®
Karaoke-On-Demand Jukebox
Front Panel
First Things First
Before using your KOD-1000, there are a few things
you should do and know:
• Check to see that your local power outlets supply
the correct voltage for the AC adapter.
• Except for the hard drive compartment, do not open
the device as there are no user-serviceable parts inside.
For repairs, contact the local distributor, an authorized
service center or Acesonic's U.S. headquarters.
• When the system will not be used for a long time,
disconnect the power plug from the wall and remove
all connecting cables for proper storage.
Rear Panel
1

Advertisement

Table of Contents
loading

Related Manuals for Acesonic KOD-1000

Summary of Contents for Acesonic KOD-1000

  • Page 1 See important Safety Information on Page 24. Front Panel First Things First Thank you for purchasing Acesonic’s KOD-1000 Ka- raoke-On-Demand Jukebox. Acesonic takes pride in Before using your KOD-1000, there are a few things...

  • Page 2: Table Of Contents

    Your Acesonic KOD-1000 Karaoke-On-Demand arrives with everything you need to start making music and per- forming except a microphone and speakers. These can be obtained from Acesonic, or you can use any standard audio equipment that conforms to contemporary standards. If you are familiar with audio equipment, use the enclosed Quick Start Guide for setup.

  • Page 3: Player Specifications

    U.S., Canada, most countries in servicing, turn off the player, unplug it and contact an South America, Japan, South Korea and the Philip- Acesonic dealer or service center. pines. The KOD-1000 also supports the PAL format, which...

  • Page 4: Front & Back Panel Functions And Operation

    Front Panel Functions and Operation play immediately. 8. DISPLAY WINDOW: Time, disc format or song 1. POWER: Press this button to toggle the KOD- 1000 on and off. Turning off the power on the player’s number is displayed here. front panel, however, will not allow it to be powered 9.

  • Page 5: Remote Control Functions

    8. RCA VIDEO OUTPUT: This connection is for remote. the RCA video output. While not as high quality as • Select SPEAKER SETUP on the onscreen menu S-video or Component, it is more prevalent in TVs. using the DIRECTIONAL CONTROL on the 9.

  • Page 6: External Storage Devices

    16. INPUT: Press this button to toggle between lan- KEY will flatten the voice a full step. Pressing the FE- guages when selecting and searching for songs. MALE KEY will sharpen the voice a full step. 17. PREVIOUS/NEXT TRACK CONTROLS: 27.

  • Page 7: A/V Connections

    ing files via USB through the KOD-1000. unsupported file types are detected. Please note that the KOD-1000 is not a computer. For best compatibility, format flash in FAT32. If you It cannot support larger, desktop-sized hard drives, have problems formatting in FAT32, please refer to or any Flash Drive device with an abundance of files.

  • Page 8: Power Connection

    5.1 Surround Sound Connections Power Connections cord and an appropriate electrical outlet. Please note that the KOD-1000 uses 100 V to 240 V, When you have completed connecting your KOD- at 50/60 Hz. It is compatible with electrical outlets in 1000 to your video and audio components, refer to the diagram below to connect the player to the power North America and all US states.

  • Page 9: Basic Karaoke Functions

    Basic Karaoke Functions 5. Navigate through the menus using the DIREC- TION CONTROL on your remote. Numbers 1, 4, Random Play 5 and 6 are text selectable modes. Push the left but- After pressing the PLAY/PAUSE button on the ton on the DIRECTION CONTROL to return to remote control, KOD-1000 will play the hard drive’s the last menu.
  • Page 10 8. When you are done searching for the songs in the remote control’s NUMERIC KEYS. your selection, push MENU. The list of songs dis- 3. Confirm your selection by pressing OK or EN- played in your queue will be displayed. TER on your remote control.
  • Page 11 6. Press the PLAY/PAUSE button to begin playing search. An English “A” will appear in the upper your selections. right corner for searches in English, and a Chinese character will appear in the upper right corner for “Singer Class” Displays Songs by Male Singers, searches in Chinese, for example.
  • Page 12 selection, push MENU. The list of songs displayed times, for example. in your queue will be displayed. 4. When the selection or selections are displayed, 6. Press the PLAY/PAUSE button to begin playing press ENTER. Use the DIRECTION CON- your selections. TROLS to choose a song.
  • Page 13 LIST button. If there are more 2. Allow the player to boot. than five songs on the list access them using the right 3. When the Acesonic home screen is displayed, or left keys on the DIRECTION CONTROL or the push the SETUP key.

  • Page 14: Advanced Karaoke Functions

    remote control. 1. Ensure there are no songs in the queue. To begin playing your selections, press the PLAY/ 2. Select a song for the MY FAVORITES folder by PAUSE button. To pause playback and then resume inputting its number and pressing FAVORITES. playback, press the PLAY/PAUSE button.

  • Page 15: Keyboard Connection And Use

    To access the song’s information, enter its numeric modified, use the UP/DOWN keys of the DIREC- code using the NUMERIC KEYS and press REC. TIONAL CONTROL. To correct or change the track’s information: Class: This category is tied to the phylum/language of the song.
  • Page 16 3. KEY CONTROL BUTTONS: Press these 18. DIRECTION: Use these buttons to navigate buttons for tonal control. F10 will flatten the voice a the selection menus. half step. F12 will sharpen the voice a half step. 19. PRIORITY BUTTON: Use this button to move a song to the top of the queue list.

  • Page 17: Other Functions (Dvds And Other Media)

    5. Use the OK BUTTON (ENTER) to confirm selections To Edit the Track’s Information After Recording Users can also use the keyboard (see page 16) to modify song information after recording. Please read the following carefully and follow the steps precisely: •...
  • Page 18 • Press the NUMERIC KEYS 0-9 to select and title, chapter and track. begin playback of the song. Playing MP3s from a USB Flash/Thumb Drive or • Use the PREVIOUS/NEXT TRACK External Hard Drive CONTROLLER remote control buttons to access Please note that the KOD-1000 is not a computer.

  • Page 19: System Setup: Hard Disk Drive Mode

    • Use the remote control’s DIRECTIONAL button. CONTROL buttons to select the media type to • Use the PREVIOUS/NEXT TRACK display and to navigate to the file to open. CONTROLLER remote control buttons to access • JPG files will open a directory of image files. any additional menus.
  • Page 20 Acesonic technician and is not covered by the war- Interlude Timer: When a song completes, the selected ranty. time interval will elapse before the next song begins: 1. Press Direction KEY [▲▼] to choose PASS- WORDS. Pause for 5 Seconds 2.

  • Page 21: System Setup: Disc Mode

    Songs can be assigned to a keyboard’s F1-F9 keys. See Page 15 for more details regarding keyboard use with the KOD-1000. System Setup: Disc Mode NOTE: The screen will change to Screen Saver mode if the player is idle for 20 minutes. While your KOD-1000 is a very capable disc player, the menus below will add more functionality and en- Video...
  • Page 22 NOTE: The Ratings feature only works with discs 3. Press Direction KEY [▲▼] to select language. that support this feature. 4. Press [OK] to confirm it. Default Menu Language 1. Press Direction KEY [▲▼] to choose DE- 1. Press Direction KEY [▲▼] to choose MENU FAULT.

  • Page 23: Troubleshooting

    Distorted Sound If these suggestions do not solve your problem, please • Check connections on the KOD-1000 and audio call Acesonic Customer Service at (626) 820-0645. equipment or television. No Sound • Check input and volume settings on the audio equipment or television.

  • Page 24: Safety, Warnings And Precautions

    KOD-1000 Boots Up to a Blue Screen No Microphone Volume • There may be possible hard drive damage or data- • Check microphone connection. base corruption. Call Acesonic customer service at • Check microphone power. (626) 820-0645. Safety, Warnings and Precautions...
  • Page 25 radio noise emissions from digital devices as set out exposed to rain or moisture, the product does not in the Canadian standard for interference-causing operate normally or it has been dropped. equipment (“Digital Apparatus, ICES-003” from the 11. Never push objects of any kind into this product, Department of Communications).

  • Page 26: Glossary

    Glossary 5.1 Surround Sound An audio standard that uses JPEG ( JPG) Stands for Joint Photographic Experts a center speaker, two front speakers and two rear Group. A popular computer graphic format that allows speakers, as well as a subwoofer (the .1 of the 5.1) to pictures to be shown on a wide range of devices.

  • Page 27: Technical Specifications

    Technical Specifications Laser Wavelength 650nm Signal Format System NTSC, PAL, PAL60, AUTO Frequency Response 20Hz–20KHz ± 2.5 dB Signal-to-Noise Ratio > 85 dB Channel Separation > 85 dB (1 KHz) Dynamic Range > 85 dB (1 KHz) Audio Output (Analog) 2V ±...
  • Page 28 161 S. 8th Avenue Karaoke-On-Demand Jukebox One (1) Year Manufacturer Warranty City of Industry Lifetime Technical Support CA 91746-3208 Designed in U.S.A. U.S.A. Technical Support: (626) 820-0645 techsupport@acesonic.com © 2011 Acesonic USA, Inc. • All rights reserved Web site: www.acesonic.com...
