Thread the cables through the opening in the drawer, and then connect them to the backplane
1.
board.
CAUTION: To avoid damage to the equipment, be sure that the cables are properly
connected. The red cable is 12V. The black cable is GND.
Install the backplane board:
2.
Be sure the board is lined up on the standoffs.
a.
Install the screws.
b.
Connect the LED panel cable.
3.
Install the cover.
4.
Install the cable management arm.
5.
Install the hard drive drawer.
6.
Install the hard drives.
7.
Close the hard drive drawer.
8.
Install all rear panel components.
9.
Connect the cables.
10.
Removal and replacement procedures 48
