BIOS User Interface
Setup Item
IRQ
Serial B
Enable
Address
IRQ
6.3.2.2.5 USB Configuration Screen
The USB Configuration screen allows the user to configure the USB controller options.
To access this screen from the Main screen, select Advanced > USB Configuration.
Advanced
USB Configuration
Detected USB Devices
<Total USB Devices in System>
USB Controller
Legacy USB Support
Port 60/64 Emulation
Make USB Devices Non-Bootable
USB Mass Storage Device Configuration
Device Reset timeout
Mass Storage Devices:
<Mass storage devices one line/device>
USB 2.0 controller
Figure 25. Setup Utility – USB Controller Configuration Screen Display
60
Options
3 Select Serial port A interrupt request (IRQ) line.
4
Enabled Enable or Disable Serial port B.
Disabled
3F8h Select Serial port B base I/O address.
2F8h
3E8h
2E8h
3 Select Serial port B interrupt request (IRQ).
4
Enabled/Disabled
Enabled/Disabled/Auto
Enabled/Disabled
Enabled/Disabled
10 seconds/20 seconds/30 seconds/40 seconds
Auto/Floppy/Forced FDD/Hard Disk/CD-ROM
Enabled/Disabled
Intel order number E65697-010
Intel® Server Board S3420GP TPS
Help Text
Revision 2.4
