Feature
Expansion
Capabilities
Fans
System
Management
®
Intel Server Board S3000AH User's Guide
Table 2. Server Board Features
S3000AHLX SKU:
•
Two full length 32-bit/33MHz, 3.3V Universal PCI connectors
•
One physical x4 PCI Express* connector (operating at x1 lane speed)
•
One full length PCI-X* connector (64-bit/133MHz)
•
®
One Intel Adaptive Slot connector (supports one PCIe* x8 or one PCI-X*
64-bit/133MHz add-in card)
S3000AH SKU:
•
Two full length 32-bit/33MHz, 3.3V Universal PCI connectors
•
One x8 PCI Express* connector
•
One physical x4 PCI Express* connector (operating at x1 lane speed)
•
One physical x8 PCI Express* connector (operating at x4 lane speed)
S3000AHV SKU:
•
Two full length 32-bit/33MHz, 3.3V Universal PCI connectors
•
One x8 PCI Express* connector
•
One physical x8 PCI Express* connector (operating at x4 lane speed)
Support for up to four system fans and one processor fan
®
Intel System Management Software
Description
3
