Motherboard Overview

Rear chassis fan connector
Auxiliary 12V power
Back panel
I/O connectors
CD audio connector
Video audio connector
Front panel
audio connector
Realtek ALC202A
audio codec
Intel 82562ET
10/100 Mbps (PLC) device
NOTE
supply connector
Intel 82801DB I/O
controller Hub (ICH4)
USB connector
mPGA478 socket
Intel 82845GV Graphics Memory
Controller Hub(GMCH)
CPU fan connector
PCI slots Front panel
connector
Front panel
DIMM sockets
NSC PC87372
super I/O controller
Power supply
connector
FDD connector
Primary EIDE
connector
Secondary EIDE
connector
Speaker
Battery
Auxiliary front
panel power
LED connector
Front Chassis
fan connector
Chassis intrusion
connector
Jumper
FWH
(Firmware Hub)
Motherboard Description
1-3
