Page 2
Current characterized errata are available on request. Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order. Copies of documents which have an ordering number and are referenced in this document, or other Intel literature, may be obtained from Intel Corporation by going to the World Wide Web site at: http://www.intel.com or by calling...
Safety and Regulatory Notice See the Intel Desktop Board D845GVAD2 Product Guide for all applicable regulatory compliance statements, product certification markings, and safety and electromagnetic compatibility (EMC) standards and regulations this desktop board is compliant with.
Desktop Board Components Line USB 2.0 Devices 2-pin alternate HD LED power/sleep LED Power LED connector Reset No Connection OM14565 continued Intel Desktop Board D845GVAD2 Quick Reference...
CAUTION Failure to use an ATX12V or SFX-12V power supply, or not connecting the additional power supply lead to the Desktop Board D845GVAD2 may result in damage to the desktop board and/or power supply. For more information on the ATX12V and SFX -12V power supply, refer to the Intel Desktop Board D845GVAD2 Product Guide on the Intel Express Installer CD-ROM.
Page 6
DIMM Specification. To view or download these specifications, refer to this Intel World Wide Web site: http://www.intel.com/technology/memory/pcsdram/ For information about vendors that support these memory requirements, refer to the Desktop Board D845GVAD2 link on this Intel World Wide Web site: http://support.intel.com/support/motherboards/desktop/ Intel Desktop Board D845GVAD2...
Secure the desktop board to the chassis standoffs using the screws. Desktop Board D845GVAD2 is secured to the chassis with six screws. Refer to the illustration on page 4 for the location of the mounting holes. Intel Desktop Board D845GVAD2...
The desktop board comes with an integrated processor heat sink retention mechanism (RM). For instructions on how to install the processor fan heat sink, refer to the boxed processor manual or the Intel customer support World Wide Web site: http://support.intel.com/support/processors/pentium4/intnotes478.htm...
Connect the chassis fan cables to the board connectors as shown in the following figure. Chassis Rear J1B1 Processor J2F1 Chassis Front J8H2 OM14566 Intel Desktop Board D845GVAD2 Quick Reference...
The BIOS Setup program can be used to view and change the BIOS settings for the computer. The BIOS Setup program is accessed by pressing the <F2> key after the Power-On Self-Test (POST) memory test begins and before the operating system boot begins. Intel Desktop Board D845GVAD2 Quick Reference...
None diskette in the event of a failed BIOS update.* *To update or recover the BIOS, see the instructions in the Intel Desktop Board D845GVAD2 Product Guide on the Intel Express Installer CD-ROM For a complete list of BIOS Setup settings, see: •...
Customer Support Links View or download product support information from Intel’s World Wide Web site: http://support.intel.com/support/motherboards/desktop/ Follow the link to your Intel Desktop Board for the following information: • Known Issues and Solutions • Software and Drivers (latest BIOS and driver updates) •...
Page 25
Zawartość dysku CD-ROM z programem Express Installer firmy Intel ® • Gwarancja produktu • Program Express Installer firmy Intel • ® Podręcznik użytkowania płyty głównej D845GVAD2 firmy Intel • Programy narzędziowe i sterowniki • Umowa licencyjna oprogramowania • Plik Readme...
Page 26
Kopie oznaczonych numerami porządkowymi dokumentów, do których występują odniesienia w tym dokumencie, a także inne publikacje firmy Intel można uzyskać w witrynie sieci Web firmy Intel Corporation pod adresem: http://www.intel.com lub zamówić telefonicznie, dzwoniąc pod numer 1-800-548-4725.
Uwaga dotycząca bezpieczeństwa i obowiązujących przepisów ® W dokumencie Podręcznik użytkowania płyty głównej D845GVAD2 firmy Intel można znaleźć wszystkie odpowiednie oświadczenia dotyczące zgodności z przepisami, oznaczenia certyfikacji produktów oraz informacje na temat bezpieczeństwa oraz norm zgodności elektromagnetycznej (EMC), z którymi zgodna jest niniejsza płyta główna.
Podzespoły płyty głównej Line USB 2.0 Devices 2-pin alternate HD LED power/sleep LED Power LED connector Reset No Connection OM14565 cdn. Płyta główna D845GVAD2 firmy Intel Skrócony opis...
128 KB ® ® Procesor Intel Celeron 1,8 i 1,7 GHz w obudowie mPGA478 Najnowsze informacje na temat procesorów obsługiwanych przez płytę główną D845GVAD2 można znaleźć w witrynie sieci Web firmy Intel pod adresem: Płyta główna D845GVAD2 firmy Intel Skrócony opis...
Page 30
DIMM muszą być zgodne ze specyfikacjami pamięci PC SDRAM. Dotyczy to specyfikacji pamięci PC SDRAM (specyficznej dla określonego składnika pamięci) i specyfikacji PC Unbuffered DIMM. Specyfikacje te można wyświetlić lub pobrać w witrynie sieci Web firmy Intel pod adresem: http://www.intel.com/technology/memory/pcsdram/ Informacje na temat dostawców sprzętu zgodnego z tymi wymaganiami dotyczącymi pamięci można znaleźć...
Za pomocą śrub przymocuj płytę główną do wsporników w obudowie. Płyta główna D845GVAD2 jest mocowana do obudowy za pomocą sześciu śrub. Położenie otworów montażowych na płycie można określić na podstawie ilustracji zamieszczonej na stronie 4.
PCI 1, aby uchwyt modułów pamięci nie przeszkadzał w czasie jej instalowania. Dwa gniazda pamięci DIMM na płycie głównej D845GVAD2 oznaczone są jako DIMM 0 oraz DIMM 1, jak pokazano na poniższej ilustracji. Jeśli ma zostać...
Podłącz kable wentylatora obudowy do złączy wentylatorów na płycie głównej, jak pokazano na poniższej ilustracji. Chassis Rear J1B1 Processor J2F1 Chassis Front J8H2 OM14566 Płyta główna D845GVAD2 firmy Intel Skrócony opis...
6 Podłączanie dysków IDE ® W opakowaniu z płytą główną firmy Intel dostarczony jest kabel do podłączenia dysków IDE. Kabel ten pozwala na podłączenie do płyty głównej dwóch dysków. Kabel ten jest zgodny z protokołem przesyłania danych ATA-66/100 (40 styków, 80 przewodów) a także jest zgodny z protokołami wolniejszej transmisji danych wykorzystywanymi w starszych dyskach IDE.
*Aby zaktualizować system BIOS lub odzyskać dane systemu BIOS, należy postępować zgodnie z instrukcjami zawartymi w dokumencie Podręcznik płyty głównej D845PESV firmy Intel, który można znaleźć na dysku CD-ROM z programem Express Installer firmy Intel. Listę wszystkich ustawień programu BIOS Setup można znaleźć...
Informacje pomocy technicznej dotyczącej produktu można wyświetlić lub pobrać z witryny sieci Web firmy Intel pod adresem: http://support.intel.com/support/motherboards/desktop/ Użyj łącza do strony sieci Web z opisem używanej płyty głównej firmy Intel, aby uzyskać następujące informacje: • Znane problemy i rozwiązania •...
