Chapter 1
CD-ROM Eject Button
CD-ROM CD-ROM Activity LED
SCSI Disk ID 0
Figure 1-2. Control Panel Indicators
Table 1-1. Control Panel Switches and Indicators
Control/Indicator
Power On/Off/Sleep
Switch & LED
Power
Power
Switch
LED
Reset Switch
RESET
2
FDD Activity LED
SCSI Disk ID 1
Description
The power switch turns the Netserver power On or Off. If
sleep states are available, it also transitions between Power
On and sleep states.
Sleep states are NOS dependent and only available if your
NOS supports power management based on the ACPI
(Advanced Configuration and Power Interface) standard.
Refer to "Applying Power to the HP Netserver" and
"Sleep States (ACPI)" later in this chapter.
The LED indicates the power state of the Netserver:
• Steady Green indicates the Netserver is operating
normally.
• Blinking Green indicates the Netserver is in a sleep
state and under ACPI control.
• Off (unlit) indicates the Netserver is powered off or in
standby mode.
This switch creates a hard system reset, which is
equivalent to a power-on reset.
Controls, Ports and Indicators
FDD Eject Button
Flexible Disk Drive
(FDD)
SCSI Disk ID 2
