Summary of Contents for Asus M5A78L-M LE

  • Page 1 M5A78L-M Series • M5A78L-M LE • M5A78L-M PLUS...
  • Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.
  • Page 3: Table Of Contents

    Welcome! ..................1-1 Package contents ................. 1-1 Special features ................1-1 1.3.1 Product highlights ............1-1 1.3.2 Innovative ASUS features ..........1-3 Before you proceed ..............1-5 Motherboard overview ..............1-6 1.5.1 Placement direction ............1-6 1.5.2 Screw holes ..............1-6 1.5.3...
  • Page 4 Chapter 2: BIOS information Managing and updating your BIOS ..........2-1 2.1.1 ASUS Update ..............2-1 2.1.2 ASUS EZ Flash 2 ............2-2 2.1.3 ASUS CrashFree BIOS 3 ..........2-3 BIOS setup program ..............2-4 2.2.1 BIOS menu screen ............2-5 2.2.2...
  • Page 5 Boot menu .................. 2-19 2.6.1 Boot Device Priority ............2-19 2.6.2 Boot Settings Configuration .......... 2-19 2.6.3 Security ................. 2-20 Tools menu ................. 2-22 2.7.1 ASUS EZ Flash 2 ............2-22 2.7.2 ASUS O.C. Profile ............2-22 Exit menu ..................2-23...
  • Page 6: Notices

    This class B digital apparatus complies with Canadian ICES-003. ASUS Recycling/Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other components as well as the packaging materials.
  • Page 7: Safety Information

    Complying with the REACH (Registration, Evaluation, Authorisation, and Restriction of Chemicals) regulatory framework, we published the chemical substances in our products at ASUS REACH website at http://csr.asus.com/english/REACH.htm. DO NOT throw the motherboard in municipal waste. This product has been designed to enable proper reuse of parts and recycling.
  • Page 8: About This Guide

    Refer to the following sources for additional information and for product and software updates. ASUS websites The ASUS website provides updated information on ASUS hardware and software products. Refer to the ASUS contact information. Optional documentation Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer.
  • Page 9: M5A78L-M Series Specifications Summary

    ** Due to CPU spec., AMD 100 and 200 series CPUs support ® up to DDR3 1066MHz. With ASUS design, this motherboard can support up to DDR3 1333MHz. *** When overclocking, some AMD CPU models may not support DDR3 1600 MHz or higher frequency DIMMs.
  • Page 10 ASUS EPU ASUS CrashFree BIOS 3 ASUS EZ Flash 2 ASUS Q-Fan ASUS MyLogo 2 ASUS C.P.R. (CPU Parameter Recall) ASUS Anti Surge ASUS AI Charger ASUS Turbo Key 100% All high quality conductive polymer capacitors (M5A78L-M PLUS only)
  • Page 11: Chapter 1: Product Introduction

    ASUS motherboard Support DVD Documentation User Manual • M5A78L-M Series motherboards include M5A78L-M PLUS and M5A78L-M LE two models. The package contents vary from models. The layout illustrations in this user guide are for M5A78L-M LE only. • If any of the items is damaged or missing, contact your retailer.
  • Page 12 Cool ‘n’ Quiet Technology ® This motherboard supports the AMD Cool ‘n’ Quiet technology which ® monitors system operation and automatically adjusts CPU voltage and frequency for a cool and quiet operating environment. HyperTransport™ 3.0 support HyperTransport™ 3.0 technology provides 2.6 times more bandwidth than HT1.0 that radically improves system efficiency for a smoother and faster computing environment.
  • Page 13: Innovative Asus Features

    BIOS file using the bundled support DVD or a USB flash disk that contains the BIOS file. ASUS EZ Flash 2 ASUS EZ Flash 2 allows you to update the BIOS from a USB flash disk before entering the OS. ASUS Q-Fan...
  • Page 14 ErP requires products to meet certain energy efficiency requirements in regards to energy consumptions. This is in line with ASUS vision of creating environment-friendly and energy-efficient products through product design and innovation to reduce carbon footprint of the product and thus mitigate environmental impacts.
  • Page 15: Before You Proceed

    ON, in sleep mode, or in soft-off mode. This is a reminder that you should shut down the system and unplug the power cable before removing or plugging in any motherboard component. The illustration below shows the location of the onboard LED. SB_PWR M5A78L-M LE Standby Power Powered Off M5A78L-M LE Onboard LED ASUS M5A78L-M Series...
  • Page 16: Motherboard Overview

    Place six screws into the holes indicated by circles to secure the motherboard to the chassis. DO NOT overtighten the screws! Doing so can damage the motherboard. Place this side towards the rear of the chassis. M5A78L-M LE Chapter 1: Product introduction...
  • Page 17: Motherboard Layout

    KBMS CHA_FAN CPU_FAN KBPWR ATX12V USB34 LAN1_USB12 ® AUDIO RS780L COM1 SATA3G_5 PCIEX1_1 8111E SATA3G_6 CLRTC PCIEX16 16Mb M5A78L-M LE BIOS Super ® SB710 PCI1 Lithium Cell CMOS Power SATA3G_2 SATA3G_4 PCI2 USBPW5-12 SPEAKER SB_PWR SPDIF_OUT USB1112 USB910 USB78 USB56...
  • Page 18: Central Processing Unit (Cpu)

    Installing the CPU To install a CPU: Locate the CPU socket on the motherboard. M5A78L-M LE M5A78L-M LE CPU socket AM3+ Press the lever sideways to unlock the Socket lever socket, then lift it up to a 90°-100° angle. Ensure that the socket lever is lifted up to a 90°-100°...
  • Page 19 Connect the CPU fan cable to the CPU_FAN connector on the motherboard. CPU_FAN M5A78L-M LE M5A78L-M LE CPU fan connector DO NOT forget to connect the CPU fan connector! Hardware monitoring errors can occur if you fail to plug this connector.
  • Page 20: Installing The Heatsink And Fan

    1.6.2 Installing the heatsink and fan Ensure that you use only AMD-certified heatsink and fan assembly. To install the CPU heatsink and fan: Place the heatsink on top of the installed CPU, ensuring that the heatsink fits properly on the retention module base. •...
  • Page 21: System Memory

    DDR2 DIMM socket. DDR3 modules are developed for better performance with less power consumption. The figure illustrates the location of the DDR3 DIMM sockets: Channel Sockets Channel A DIMM_A1 Channel B DIMM_B1 M5A78L-M LE M5A78L-M LE 240-pin DDR3 DIMM sockets ASUS M5A78L-M Series 1-11...
  • Page 22: Memory Configurations

    • Due to the CPU specification, AMD 100 and 200 series CPUs support up to DDR3 ® 1066MHz. With ASUS design, this motherboard can support up to DDR3 1333MHz. • When overclocking, some AMD CPUs may not support DDR3 1600MHz or higher frequency DIMMs.
  • Page 23: Ddr3-1333 Mhz Capability

    2048MB(Kit of 2) Heat-Sink Package 6-6-6-20 1.8V • • Crucial CT12864BA1339.8SFD 3072MB(Kit of 3) Micron 8XD22D9JNM • • Crucial CT25664BA1339.16FF 2048MB Micron 9KF27D9KPT • • Crucial CT25672BA1339.18FF 2048MB Micron 91F22D9KPT(ECC) • • (continued on the next page) ASUS M5A78L-M Series 1-13...
  • Page 24 DDR3-1333 MHz capability DIMM Timing Support Vendor Part No. Size Brand Chip NO. DIMM Voltage (BIOS) Crucial BL25664ABA1336.16SFB1 4096MB(Kit of 2) DS Heat-Sink Package 6-6-6-20 1.8V • • Crucial BL25664BA1336.16SFB1 4096MB(Kit of 2) DS Heat-Sink Package 6-6-6-20 1.8V • • Crucial BL25664BN1337.16FF (XMP) 6144MB(Kit of 3) DS Heat-Sink Package...
  • Page 25 • Due to CPU spec., AMD 100 and 200 series CPUs support up to DDR3 1066MHz. With ® ASUS design, this motherboard can support up to DDR3 1333MHz. • When overclocking, some AMD CPU models may not support DDR3 1600 MHz or higher frequency DIMMs.
  • Page 26: Installing A Dimm

    1.7.3 Installing a DIMM Unplug the power supply before adding or removing DIMMs or other system components. Failure to do so can cause severe damage to both the motherboard and the components. Press the retaining clips outward to DIMM notch unlock a DIMM socket.
  • Page 27: Expansion Slots

    This motherboard supports PCI Express x1 network cards, SCSI cards, and other cards that comply with the PCI Express specifications. 1.8.5 PCI Express x16 slot This motherboard supports a PCI Express x16 graphics card that comply with the PCI Express specifications. ASUS M5A78L-M Series 1-17...
  • Page 28: Jumpers

    Normal Clear RTC (Default) M5A78L-M LE Clear RTC RAM To erase the RTC RAM: 1. Turn OFF the computer and unplug the power cord. 2. Move the jumper cap from pins 1-2 (default) to pins 2-3. Keep the cap on pins 2-3 for about 5~10 seconds, then move the cap back to pins 1-2.
  • Page 29: Keyboard Power

    M5A78L-M LE +5VSB (Default) M5A78L-M LE USB device wake-up Keyboard power (3-pin KBPWR) This jumper allows you to enable or disable the keyboard wake-up feature. When you set this jumper to pins 2-3 (+5VSB), you can wake up the computer by pressing a key on the keyboard.
  • Page 30: Connectors

    1.10 Connectors 1.10.1 Rear panel ports PS/2 Mouse port (green). This port is for a PS/2 mouse. LAN (RJ-45) port. This port allows Gigabit connection to a Local Area Network (LAN) through a network hub. LAN port LED indications ACT/LINK SPEED Activity/Link LED Speed LED...
  • Page 31: Internal Connectors

    Legacy AC’97 pin definition compliant definition M5A78L-M LE Front panel audio connector • We recommend that you connect a high-definition front panel audio module to this connector to avail of the motherboard high-definition audio capability. • If you want to connect a high definition front panel audio module to this connector, set the Front Panel Select item in the BIOS to [HD Audio].
  • Page 32: Atx Power Connectors

    The system may become unstable or may not boot up if the power is inadequate. • If you are uncertain about the minimum power supply requirement for your system, refer to the Recommended Power Supply Wattage Calculator at http://support.asus. com/PowerSupplyCalculator/PSCalculator.aspx?SLanguage=en-us for details. 1-22...
  • Page 33 COM1 PIN 1 M5A78L-M LE M5A78L-M LE Serial port (COM1) connector LPT connector (26-1 pin LPT) The LPT (Line Printing Terminal) connector supports devices such as a printer. LPT standardizes as IEEE 1284, which is the parallel port interface on IBM PC-compatible computers.
  • Page 34 SATA3G_4 SATA3G_1 SATA3G_3 M5A78L-M LE M5A78L-M LE SATA 3.0Gb/s connectors • Install the Windows XP Service Pack 3 or later versions before using Serial ATA. ® • If you intend to create a SATA RAID set, set the type of the SATA connectors to [RAID] in the BIOS.
  • Page 35: System Panel Connector

    PIN 1 M5A78L-M LE +HDLED RESET M5A78L-M LE System panel connector • System power LED (2-pin PLED) This 2-pin connector is for the system power LED. Connect the chassis power LED cable to this connector. The system power LED lights up when you turn on the system power, and blinks when the system is in sleep mode.
  • Page 36: Usb Connectors

    This connector is for an additional Sony/Philips Digital Interface (S/PDIF) port. M5A78L-M LE SPDIF_OUT M5A78L-M LE Digital audio connector Ensure that the audio device of Sound playback is Realtek High Definition Audio (the name may be different based on the OS). Go to Start > Control Panel > Sounds and Audio Devices >...
  • Page 37 DO NOT forget to connect the fan cables to the fan connectors. Insufficient air flow inside the system may damage the motherboard components. These are not jumpers! DO NOT place jumper caps on the fan connectors. Only the 4-pin CPU fan supports the ASUS Q-Fan feature. ASUS M5A78L-M Series 1-27...
  • Page 38: Software Support

    The contents of the Support DVD are subject to change at any time without notice. Visit the ASUS website at www.asus.com for updates. To run the Support DVD Place the Support DVD into the optical drive.
  • Page 39: Chapter 2: Bios Information

    BIOS in the future. Copy the original motherboard BIOS using the ASUS Update utility. 2.1.1 ASUS Update The ASUS Update is a utility that allows you to manage, save, and update the motherboard BIOS in Windows environment. ®...
  • Page 40: Asus Ez Flash 2

    Follow the onscreen instructions to complete the updating process. 2.1.2 ASUS EZ Flash 2 The ASUS EZ Flash 2 feature allows you to update the BIOS without using an OS-based utility. Before you start using this utility, download the latest BIOS file from the ASUS website at www.asus.com.
  • Page 41: Asus Crashfree Bios 3

    2.1.3 ASUS CrashFree BIOS 3 ASUS CrashFree BIOS 3 is an auto recovery tool that allows you to restore the BIOS file when it fails or gets corrupted during the updating process. You can restore a corrupted BIOS file using the motherboard support DVD or a USB flash drive that contains the BIOS file.
  • Page 42: Entering Bios Setup At Startup

    • The BIOS setup screens in this chapter are for reference only. They may not exactly match what you see on your screen. • Visit the ASUS website at www.asus.com to download the latest BIOS file for this motherboard. Chapter 2: BIOS information...
  • Page 43: Bios Menu Screen

    2.2.1 BIOS menu screen Menu items Menu bar Configuration fields General help M5A78L-M LE BIOS Setup Version 0205 Main Advanced Power Boot Tools Exit Main Settings Use [ENTER], [TAB] System Time [16:34:30] or [SHIFT-TAB] to System Date [Tue 01/11/2011] select a field.
  • Page 44: Menu Items

    A configurable field is enclosed in brackets, and is highlighted when selected. To change the value of a field, select it then press <Enter> to display a list of options. Refer to 2.2.7 Pop-up window. 2.2.7 Pop-up window M5A78L-M LE BIOS Setup Version 0205 Main Advanced Power...
  • Page 45: Main Menu

    When you enter the BIOS Setup program, the Main menu screen appears, giving you an overview of the basic system information. Refer to section 2.2.1 BIOS menu screen for information on the menu screen items and how to navigate through them. M5A78L-M LE BIOS Setup Version 0205 Main Advanced...
  • Page 46: Sata Configuration

    LBA/Large Mode [Auto] Enables or disables the LBA mode. Setting this item to [Auto] enables the LBA mode if the device supports this mode, and if the device was not previously formatted with LBA mode disabled. Configuration options: [Disabled] [Auto] Block (Multi-Sector Transfer) Mode [Auto] Enables or disables data multi-sectors transfers.
  • Page 47: System Information

    This menu gives you an overview of the general system specifications. The BIOS automatically detects the items in this menu. BIOS information Displays the auto-detected BIOS information. Processor Displays the auto-detected CPU specification. System Memory Displays the auto-detected system memory. ASUS M5A78L-M Series...
  • Page 48: Advanced Menu

    The Advanced menu items allow you to change the settings for the CPU and other system devices. Take caution when changing the settings of the Advanced menu items. Incorrect field values can cause the system to malfunction. M5A78L-M LE BIOS Setup Version 0205 Main Advanced...
  • Page 49 Sets the HT over voltage. The values range from 1.20000V to 1.38000V with a 0.01000V increment. Use the <+> / <-> keys to adjust the value. Configuration options: [Auto] [Max. = 1.38000V] [Min. = 1.20000V] Memory Clock Mode [Auto] Configuration options: [Auto] [Manual] ASUS M5A78L-M Series 2-11...
  • Page 50: Dram Timing Configuration

    The following items only appear when you set Memory Clock Mode to [Manual]. Memory Clock Speed [400MHz] Selects the memory clock frequency programming method. Configuration options: [400MHz] [533MHz] [667MHz] [800MHz] DRAM Timing Configuration The configuration options for some of the following items vary depending on the DIMMs you install on the motherboard.
  • Page 51: Cpu Configuration

    Enable the Unleashing Mode to get full computing power of the processor. However, this might make your system unstable depending on your processor’s overclocking capability. Configuration options: [Enabled] [Disabled] Active CPU Cores [Auto] Allows you to manually turn ON/OFF a process core. Configuration options: [Auto] [Manual] ASUS M5A78L-M Series 2-13...
  • Page 52: Chipset

    2nd / 3rd / 4th / 6th / 8th Core [On] These items only appear when you set Active CPU Cores to [Manual]. Configuration options: [On] [Off] Value (All Cores) [-2%] This item only appears when you set Advanced Clock Calibration to [All Cores]. It allows you to set the overclocking percentage for all the processor cores as a whole.
  • Page 53: Onboard Devices Configuration

    [AC97] [HD Audio] OnBoard LAN Controller [Enabled] Enables or disables the onboard LAN controller. Configuration options: [Disabled] [Enabled] OnBoard LAN Boot ROM [Disabled] Enables or disables the onboard Gigabit LAN Boot ROM. Configuration options: [Disabled] [Enabled] ASUS M5A78L-M Series 2-15...
  • Page 54: Pcipnp

    2.4.5 PCIPnP The PCI PnP menu items allow you to change the advanced settings for PCI/PnP devices. The menu includes setting IRQ and DMA channel resources for either PCI/PnP or legacy ISA devices, and setting the memory size block for legacy ISA devices. Take caution when changing the settings of the PCI PnP menu items.
  • Page 55: Power Menu

    The Power menu items allow you to change the settings for the Advanced Configuration and Power Interface (ACPI) and the Advanced Power Management (APM). Select an item then press <Enter> to display the configuration options. M5A78L-M LE BIOS Setup Version 0205 Main...
  • Page 56: Hw Monitor Configuration

    CPU Q-Fan Function [Enabled] Enables or disables the ASUS Q-Fan feature that smartly adjusts the CPU fan speeds for more efficient system operation. Configuration options: [Disabled] [Enabled] The following item appears only when you set CPU Q-Fan Function to [Enabled].
  • Page 57: Boot Menu

    Configuration options: [Removable Dev.] [Hard Drive] [ATAPI CD-ROM] [Disabled] • To select the boot device during system startup, press <F8> when ASUS logo appears. • To access Windows OS in Safe Mode, do any of the following: Press <F5>...
  • Page 58: Security

    Bootup Num-Lock [On] Selects the power-on state for the NumLock. Configuration options: [Off] [On] Wait for ‘F1’ If Error [Enabled] When this item is set to [Enabled], the system waits for the F1 key to be pressed when error occurs. Configuration options: [Disabled] [Enabled] Hit ‘DEL’...
  • Page 59: Change User Password

    Password Check [Setup] When set to [Setup], BIOS checks for user password when accessing the Setup utility. When set to [Always], BIOS checks for user password both when accessing Setup and booting the system. Configuration options: [Setup] [Always] ASUS M5A78L-M Series 2-21...
  • Page 60: Tools Menu

    2.7.1 ASUS EZ Flash 2 Allows you to run ASUS EZ Flash 2. When you press <Enter>, a confirmation message appears. Use the left/right arrow key to select between [Yes] or [No], then press <Enter> to confirm your choice. See section 2.1.2 for details.
  • Page 61: Exit Menu

    Exit menu The Exit menu items allow you to load the optimal or failsafe default values for the BIOS items, and save or discard your changes to the BIOS items. Version 0205 M5A78L-M LE BIOS Setup Main Advanced Power Boot...
  • Page 62 2-24 Chapter 2: BIOS information...
  • Page 63: Asus Contact Information

    +1-510-739-3777 +1-510-608-4555 Web site usa.asus.com Technical Support Telephone +1-812-282-2787 Support fax +1-812-284-0883 Online support support.asus.com ASUS COMPUTER GmbH (Germany and Austria) Address Harkort Str. 21-23, D-40880 Ratingen, Germany +49-2102-959911 Web site www.asus.de Online contact www.asus.de/sales Technical Support Telephone (Component) +49-1805-010923*...
