Neck
Body
Fingerboard
Bridge
Frame.Unit
Strings
Sensors
Connectors/Controls
Power.Supply
Battery.Life
String.Length
Dimensions.(with the left frame attached and to the end of the strap pin)
Weight
14
Specifications
Mahogany
Maple
Rosewood
Rosewood
Maple
Steel Strings for Acoustic Guitar
LR-Baggs
• AUX IN
• AUX IN Level Control
• LINE OUT jack (monaural)
• PHONES jack (stereo)
• Volume
• BASS control
• TREBLE control
• EFFECT switch (OFF/REV1/REV2/CHORUS/ECHO)
• PHONES switch (ON/OFF)
• LINE OUT Jack with POWER Switch (Inserting a plug into
the jack switches the power on)
AC Adaptor/battery (6LR61 or 6F22) x1 dual power source
* Recommended AC Adaptors: PA-D012(A), PA-130(A), PA-
D09, PA-3C
* Recommended Battery: 6LR61 alkaline battery
Continuous Use
• Using Alkaline battery : approximately 20 hours
• Using Manganese battery : approximately 9 hours
With the effect activated
• Using Alkaline battery : approximately 13 hours
• Using Manganese battery : approximately 5 hours
634 mm (24-15/16")
985 (L) x 355 (W) x 80 (H) mm
38-3/4" (L) x 14" (W) x 3-1/8" (H)
approximately 1.9 kg (4 lbs. 3 oz.)
* Design and specifications are subject to change without notice.
