Intel Desktop Board D865GSA Technical Product Specification
Table 22. Front and Rear Chassis Fan Connectors
Pin Signal Name
1 Control
2 +12 V
3 Tach
Table 23. Processor Fan Connector
Pin Signal Name
1 Control
2 +12 V
3 CPU_FAN_TACH
Table 24. Chassis Intrusion Connector
Pin Signal Name
1 Intruder
2 Ground
Table 25. Serial ATA Connectors
Pin Signal Name
1 Ground
2 TXP
3 TXN
4 Ground
5 RXN
6 RXP
7 Ground
Table 26. ATAPI CD-ROM Connector
Pin Signal Name
1 Left audio input from CD-ROM
2 CD audio differential ground
3 CD audio differential ground
4 Right audio input from CD-ROM
56
