Table 2. Board Components Shown in Figure 1
Item/callout
from Figure 1 Description
A Audio codec
B Ethernet LAN controller
C AGP connector
D Rear chassis fan connector
E Back panel connectors
F +12V power connector (ATX12V)
G Intel 82865G GMCH
H LGA775 processor socket
I Processor fan connector
J DIMM Channel A socket
K DIMM Channel B socket
L Legacy I/O controller
M Main Power connector
N Diskette drive connector
O Parallel ATE IDE connectors [2]
P Chassis intrusion connector
Q Battery
R Serial ATA connectors [2]
S 4 Mbit Firmware Hub (FWH)
T Front panel connector
U Intel 82801EB I/O Controller Hub (ICH5)
V Front chassis fan connector
W BIOS Setup configuration jumper block
X Front panel USB connector
Y Front panel USB connector
Z Speaker
AA PCI Conventional bus add-in card connectors [3]
BB ATAPI CD-ROM connector
CC Front panel audio connector

Product Description
