Insignia NS-DPF7G User Manual

7" and 9” digital picture frames
Hide thumbs Also See for NS-DPF7G:
Table of Contents

Advertisement

Quick Links

User Guide
7" and 9" Digital Picture Frames
NS-DPF7G/NS-DPF9G

Advertisement

Table of Contents
loading

Related Manuals for Insignia NS-DPF7G

Summary of Contents for Insignia NS-DPF7G

  • Page 1 User Guide 7" and 9” Digital Picture Frames NS-DPF7G/NS-DPF9G...

  • Page 2: Table Of Contents

    6-month limited warranty ..... . .31 Introduction Congratulations on your purchase of a high-quality Insignia product. Your new digital picture frame is designed for reliable and trouble-free performance.

  • Page 3: Safety Information

    NS-DPF7G/NS-DPF9G Safety information Always follow these basic safety precautions when using your digital picture frame. This will reduce the risk of fire, electric shock, and injury. Warnings To reduce the risk of fire or shock hazard, do not expose the frame to rain or moisture and unplug the frame during lightning storms.

  • Page 4: Features

    Features • Displays digital pictures (JPEG format) and picture slideshows without a computer. • Displays pictures directly from an inserted memory card or USB device (not included) • Bright, clear TFT LCD screen • Compatible with a wide variety of memory cards, including: •...
  • Page 5 NS-DPF7G/NS-DPF9G Connectors Description Memory card slot. Supports CompactFlash (CF) Memory card slot, supports: • Secure Digital™ (SD) • SDHC™ • MultimediaCard (MMC™) • Memory Stick® • Memory Stick Pro Duo™ • xD™ • microSD™ USB (type A) port Remote control slot Mini USB port DC 12 V power connector.
  • Page 6 Top (buttons) You can access most of the frame’s features by using either the buttons on top of the frame or by using the remote control. Selecting files for copying, deleting, or viewing requires the remote control, and the instructions in this guide refer to remote control buttons (except where noted).

  • Page 7: Remote Control

    NS-DPF7G/NS-DPF9G Remote control Button Description MENU Press to display the Setup menu. SLIDE SHOW Press to start a slideshow or toggle the multi-image Display mode. (Up) Press to move the selection up. ENTER Press to select the highlighted option or to pause and resume the slideshow.
  • Page 8 Button Description (Left) PREV Press to move the menu selection up or left, display the previous picture, or select the previous file. (Down) Press to move the menu selection down. BACK Press to go back a screen. INFO Press to display information about the picture.

  • Page 9: Setting Up Your Frame

    NS-DPF7G/NS-DPF9G Setting up your frame Setting up the remote control To set up the remote control: • Remove the plastic tab that extends past the bottom edge of the remote control. This tab protects the battery. The remote control will not work until it is removed.

  • Page 10: Setting Up The Frame

    Setting up the frame To set up the frame: Pull out the stand to set the frame in landscape orientation. Turn the stand counterclockwise 90° to set the frame in portrait orientation. Plug the AC power adapter into the frame’s DC power connector and into an AC power outlet.
  • Page 11 NS-DPF7G/NS-DPF9G Extend the stand from the back of the frame, then place the frame on a flat surface. Adjusting the stand changes the frame’s viewing angle. Slide the power switch to the ON position. The frame automatically turns and starts playing a slideshow of the pictures stored in internal memory.

  • Page 12: Using Your Frame

    Using your frame You can use your digital picture frame to: • Play a slideshow of pictures • Adjust a picture’s view • Change display settings Playing slideshows To play an instant slideshow from a memory card or USB device: Insert a memory card or USB device into one of the available memory slots or the USB port.
  • Page 13 NS-DPF7G/NS-DPF9G To manually play a slideshow from an inserted memory card, a USB device, or from internal memory: Insert a memory card or USB drive into one of the available memory slots or the USB port. A slideshow of pictures from the memory card or USB device automatically starts to play.

  • Page 14: Copying Pictures To Internal Memory

    Press SLIDESHOW. A slideshow begins that displays the pictures contained in the memory device you selected. Press SLIDESHOW during a slideshow to switch to multi-image slideshow mode. Press SLIDESHOW again to return to single image display mode. Copying pictures to internal memory You can copy a single picture, multiple pictures, or all pictures from an inserted memory card or USB device to the frame’s internal memory.

  • Page 15: Copy Selected Pictures To Internal Memory

    NS-DPF7G/NS-DPF9G To copy selected pictures to internal memory: Press (BACK) repeatedly until the Home screen opens. Press to highlight the memory card or USB device you want to copy from, then press (ENTER/ ). The Thumbnail screen opens. www.insigniaproducts.com...

  • Page 16: Copy Pictures To Memory/Device

    Press to highlight each picture you want to copy, then press (SELECT) to mark it. A check mark appears in the upper-right corner of each marked thumbnail. Mark as many pictures as you want to copy. Press (DEL/COPY), then press to select Copy Selected (to copy the pictures you select), or Copy All (to copy all pictures).
  • Page 17 NS-DPF7G/NS-DPF9G Use your computer's standard drag and drop or copy and paste procedures to move pictures on your computer to the frame's internal memory or a memory card you inserted in the frame. Deleting pictures from internal memory Note You cannot delete pictures from an inserted memory card or USB device.
  • Page 18 Press to highlight Internal Memory, then press (ENTER/ ). The Thumbnail screen opens. Press / / / to highlight each picture you want to delete, then press (SELECT) to mark it. A check mark appears in the upper-right corner of each marked thumbnail.
  • Page 19 NS-DPF7G/NS-DPF9G To delete pictures with your PC: Make sure that your computer is on before you begin. Connect the mini plug of the supplied USB cable to the mini USB port on the digital picture frame, and connect the other end to an available USB port on your computer.
  • Page 20 Press to highlight the picture you want to include in the slideshow, then press (SELECT). A check mark appears at the upper-right corner of the thumbnail. Repeat until all pictures you want to add to the slideshow are selected. Press (DEL/COPY), then press to select Play Selected.

  • Page 21: Frame Orientation

    NS-DPF7G/NS-DPF9G Customizing the picture display You can rotate, magnify, and display information about any picture that the frame displays. To rotate a picture: While a picture is displayed full screen (not as a thumbnail), press (ROTATE). The picture is rotated 90°...

  • Page 22: Setting Viewing Options

    Setting viewing options You can change all of the viewing options in the Setup menu using the buttons on the top of the frame or on the remote control. You can display the Setup menu at any time by pressing MENU. Only the available setup options are displayed for each menu.
  • Page 23 NS-DPF7G/NS-DPF9G Setup options The following table lists and describes Setup menu options: Menu Settings Description option Slideshow 5 Seconds Sets the interval between each interval picture transition in a slideshow. 10 Seconds 30 Seconds 60 Seconds 60 Minutes 24 Hours...
  • Page 24 Menu Settings Description option Panorama When Panorama Scroll is Scroll enabled, pictures that were taken in panorama mode will be scrolled across the screen during slideshows rather than resized to fit the screen. Image display Normal Adjusts how the image is sized format to fit the screen.
  • Page 25 NS-DPF7G/NS-DPF9G Menu Settings Description option Power saving Sets the power save option. If the buttons on the frame or 15 Minutes remote control are not used for 30 Minutes the specified time, the frame 1 Hour enters Power Saving (Standby) 2 Hours mode.

  • Page 26: Maintaining

    Maintaining Cleaning the digital picture frame Clean the outer surface of the digital picture frame with the included cleaning cloth. Replacing the remote control battery To replace the remote control battery: Turn the remote control over. While pressing down on the ridged area of the battery cover, slide the battery tray out and remove the old battery.

  • Page 27: Troubleshooting

    NS-DPF7G/NS-DPF9G Troubleshooting Problem Solution The frame will not The power adapter is not securely connected to turn on. the picture frame, or the power switch is not on. Check power adapter connections, then switch the power on. A memory device is •...

  • Page 28: Specifications

    Specifications Screen size NS-DPF7G: 7" (178 mm) NS-DPF9G: 9" (203 mm) Screen format Widescreen Memory card formats • Secure Digital™ (SD) • SDHC™ ® • CompactFlash • MultimediaCard (MMC™) ® • Memory Stick • Memory Stick PRO Duo™ (requires included adapter) •...
  • Page 29 NS-DPF7G/NS-DPF9G FCC warning Changes or modifications not expressly approved by the party responsible for compliance with the FCC Rules could void the user’s authority to operate this equipment. Canada ICES-003 statement This Class B digital apparatus complies with Canadian ICES-003.

  • Page 30: 6-Month Limited Warranty

    Product is determined to be defective by an authorized Insignia repair center or store personnel, Insignia will (at its sole option): (1) repair the Product with new or rebuilt parts; or (2) replace the Product at no charge with new or rebuilt comparable products or parts.
  • Page 31 To obtain in-home warranty service for a television with a screen 25 inches or larger, call 1-888-BESTBUY. Call agents will diagnose and correct the issue over the phone or will have an Insignia-approved repair person dispatched to your home. Where is the warranty valid? This warranty is valid only to the original purchaser of the product in the United States, Canada, and Mexico.
  • Page 32 7601 Penn Avenue South, Richfield, Minnesota, U.S.A. 55423-3645 © 2010 BBY Solutions, Inc. All rights reserved. INSIGNIA is a trademark of BBY Solutions, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
  • Page 33 7601 Penn Avenue South, Richfield, MN USA 55423-3645 © 2010 BBY Solutions, Inc. All rights reserved. INSIGNIA is a trademark of BBY Solutions, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.

This manual is also suitable for:

Ns-dpf9g
