Lexmark 4227 - Forms Printer B/W Dot-matrix Service Manual page 129

4227-300
Asm- Part
Index number
3-1 40X3071
2 40X3107
3 40X3096
4 40X3057
5 40X3098
6 40X3105
7 40X3062
9 40X3063
10 40X3112
11 40X3132
12 40X3099
13 40X3122
14 40X3123
15 40X3117
16 40X3037
17 40X3038
18 40X3116
19 40X3066
20 40X3124
21 40X3065
22 40X3070
23 40X3056
24 40X3108
NS 40X3138
Description
Sensor, Auto Gap
Board and bracket, sub logic
Screw, parts packet
Motor, paper feed assembly with bracket
Bearing kit
Gears, parts packet
Motor, ribbon drive and gear plate assembly
Plate assembly with belt tension pulley
Motor, Auto Gap
Roller, lower pinch
Spring kit
Bracket, carrier motor
Motor, carrier assembly
Cable, printhead and retainer
Cam, release slider
Cam, sub slider
Printhead
Roller and spring, carrier
Carrier asm. with belt & head cooling gum
Shaft, carrier
Lever, Paper Select
Gear plate (right)
Cable, sub logic board
Gear cover (left)
7-7
Parts catalog
