Bosch 37614-01 - 14.4V Brute Tough Lithium Ion Drill Parts List

CORDLESS DRILL DRIVER
3 601 H61 T10
Item Quantity Order No.
1 1 2 605 105 140
2 1 2 607 022 319
4 1 1 607 233 331
5 1 2 601 099 196
9 1 2 601 115 740
11 1 2 600 508 066
12 1 2 600 510 011
20 1 2 601 115 881
21 1 2 601 115 730
46 1 1 609 280 477
47 1 2 605 190 895
61 1 2 608 040 273
62 1 2 600 202 058
101 13 2 603 490 018
107 1 2 603 421 229
651 1 2 607 336 079
652 1 2 607 225 327
654 1 2 610 917 319
655 1 2 602 025 158
813 1 2 600 510 012
816 1 2 607 034 904
825 1 2 608 572 902
832 1 2 601 099 175
845 1 2 606 200 248
37614
Designation
HOUSING SECTION / BLUE
DC MOTOR / 14,4V
ELECTRONICS MODULE
ADJUSTING LEVER / RED
MANUFACTURER'S NAMEPLATE
END CAP / BLACK
FRONT CAP
WARNING PLATE / USA
TYPE IDENTIFYING MARK / USA
COMPRESSION SPRING
LENS
SUPPORT
RETAINING SNAP RING
TORX OVAL-HEAD SCREW / 3x18
COUNTERSUNK-HEAD SCREW / M 6x23
SLIDE-IN ACCU PACKAGE / 2,6Ah,Li-lon XL
FAST CHARGER / USA 120/7,2-24V,1h
HOLDER
AUXILIARY HANDLE
LOCATING RING
CARBON-BRUSH SET
KEYLESS CHUCK
ADJUSTING LEVER
EPICYCLOIDAL GEAR TRAIN
28.08.2008 22:37:27
Price group Page
33 1
42 1
44 1
10 1
13 1
20 1
19 1
13 1
13 1
10 1
10 1
13 1
23 1
10 1
11 1
1
1
1
27 1
19 1
22 1
41 1
18 1
47 1
