FCC Information and Copyright
This equipment has been tested and found to comply with the limits of a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are
designed
to
provide
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. There is no guarantee that interference will not occur in
a particular installation.
The vendor makes no representations or warranties with respect to the
contents here of and specially disclaims any implied
merchantability or fitness for any purpose. Further the vendor reserves
the right to revise this publication and to make changes to the contents
here of without obligation to notify any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without
first obtaining the vendor's approval in writing.
The content of this user's manual is subject to be changed without notice
and we will not be responsible for any mistakes found in this user's
manual. All the brand and product names are trademarks of their
respective companies.
M
7
V
I
G
P
r
o
-
D
M
7
V
I
G
P
r
o
-
D
M
7
V
I
G
P
r
o
-
D
reasonable
protection
i
against
harmful
of
warranties

Advertisement

Table of Contents
loading

Summary of Contents for Biostar M7VIG PRO D

  • Page 1 FCC Information and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits designed provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 2: Table Of Contents

    LAYOUT OF M7VIG PRO-D ..............1 COMPONENT INDEX ................2 ENGLISH ....................3 M7VIG Pro-D Features....................3 Package contents ...................... 4 How to setup Jumper ....................4 CPU Installation ......................5 DDR DIMM Modules: DDR1/ DDR2 ................6 Jumpers, Headers, Connectors & Slots..............6 DEUTSCH ....................13 Spezifikationen von M7VIG Pro-D ................
  • Page 3: Layout Of M7Vig Pro-D

    Layout of M7VIG Pro-D ※NOTE: ●represents the first pin.
  • Page 4: Component Index

    Component Index A. Power Source Selection for M. Communication Network Riser Slot Keyboard and Mouse (JKBV1) (CNR1) B. Power Source Selection for USB N. CNR Codec/ Onboard Selection (JUSBV2) (JCODECSEL) C. Back Panel Connector O. Floppy Disk Connector (FDD1) D. ATX Power Connector (JATXPWER1) P.
  • Page 5: English

    English M7VIG Pro-D Features A. Hardware Provides Socket A. ® Supports single AMD for Athlon™ (Thunderbird™)/ Athlon™ XP/ Duron™ processors. Front Side Bus at 200/266 MHz. Chipset North Bridge: VIA KM266 (VT8375). South Bridge: VIA VT8235. Main Memory Supports up to 2 DDR devices. Supports 200/266 MHz (without ECC) DDR SDRAM devices.
  • Page 6: Package Contents

    1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes. 2 USB2.0 ports. 1 front audio header. Dimensions Micro ATX Form Factor: 21.3 X 24.4cm (W X L) B. BIOS & Software BIOS Award legal Bios. Supports APM1.2. Supports ACPI.
  • Page 7: Cpu Installation

    CPU Installation Step1: Pull the lever sideways away from the socket and then raise the lever up to a 90-degree angle. Step2: Look for the white dot/cut edge. The white dot/cut edge should point towards the lever pivot. The CPU will fit only in the correct orientation. Step3: Hold the CPU down firmly, and then close the lever.
  • Page 8: Ddr Dimm Modules: Ddr1/ Ddr2

    DDR DIMM Modules: DDR1/ DDR2 DRAM Access Time: 2.5V Unbuffered DDR 200/266 MHz Type required. DRAM Type: 64MB/ 128MB/ 256MB/ 512MB/ 1GB DIMM Module (184 pin) Total Memory Size with Unbuffered DIMMs DIMM Socket DDR Module Total Memory Location Size (MB) DDR1 64MB/128MB/256MB/512MB/1GB Max is...
  • Page 9 Peripheral Component Interconnect Slots: PCI 1-3 This motherboard is equipped with 3 standard PCI slots. PCI stands for Peripheral Component Interconnect, and it is a bus standard for expansion cards. This PCI slot is designated as 32 bits. Accelerated Graphics Port Slot: AGP1 Your monitor will attach directly to that video card.
  • Page 10 Wake On LAN Header: JWOL1 Assignment +5V Standby JWOL1 Ground Wake up Power Connectors: JATXPWER1 Assignment Assignment +3.3V +3.3V +3.3V -12V Ground Ground PS_ON Ground Ground Ground Ground Ground PW_OK JATXPWER1 Standby Voltage +12V Power Source Selection for Keyboard and Mouse: JKBV1 JKBV1 Assignment Description...
  • Page 11 Power Source Selection for USB: JUSBV1/ JUSBV2/ JUSBV3 JUSBV1/ JUSBV2/ Assignment Description JUSBV3 JUSBV2: 5V for USB located at the JUSB4 port Pin 1-2 close JUSBV3: 5V for USB located at the JUSB3 port JUSBV1: 5V for USB located at the JUSBLAN1 port JUSBV2: JUSB4 port powered with standby +5V Standby...
  • Page 12 5. Power on AC. 6. Reset your desired password or clear the CMOS data. Case Open Connector: JCI1 Assignment Case Open Signal JCI1 Ground CD-ROM Audio-In Header: JCDIN1 Assignment Left Channel Input Ground JCDIN1 Ground Right Channel Input Front Panel Audio Header: JF_AUDIO JF_AUDIO Assignment Assignment...
  • Page 13 CNR Codec/ Onboard Selection: JCODECSEL JCODECSEL Assignment Onboard Codec is used (default) Pin 1-2 Close CNR Codec is used Pin 2-3 Close CPU Frequency Selection: JCLK1 JCLK1 Assignment 100 MHz Pin 1-2 Close 133 MHz Pin 1-2 Open Game Port Header: JGAME1 JGAME1 Assignment Assignment...
  • Page 14 Back Panel Connectors JUSBLAN1 JUSBLAN1 JKBMS1 JKBMS1 JPRNT1 JPRNT1 PS/2 PS/2 Mouse Mouse Line In Line In Parallel Parallel JUSB4 JUSB4 Speaker Speaker Mic In Mic In PS/2 PS/2 COM1 COM1 VGA1 VGA1 Keyboard Keyboard JCOM1 JCOM1 JVGA1 JVGA1 JAUDIO JAUDIO...
  • Page 15: Deutsch

    Deutsch Spezifikationen von M7VIG Pro-D A. Hardware Unterstützung für Sockel A. ® Unterstützung für die AMD Athlon/(Thunderbird ) /Athlon XP/Duron Prozessoren FSB mit 200/266MHz. Chipsatz Northbridge: VIA KM266.(VT8375) Southbridge: VIA KT8235. Hauptspeicher Unterstützung für 2 DDR Geräte. Unterstützung für 200/266 (ohne ECC) DDR Geräte Die maximale Speichergröße ist 2GB.
  • Page 16: Verpackungsinhalt

    b. Für Vorderseite 1 Floppy-Port mit Unterstützung für 2 Diskettenlaufwerke.(360KB, 720KB, 1.2MB, 1.44MB und 2.88MB) 2 USB 2.0-Ports. 1 Front –Audio-Header. Abmessungen Micro ATX Form-Factor: 21.3 X 24.4cm (W X L) B. BIOS & Software BIOS Award legal Bios. Unterstützung für APM1.2. Unterstützung für ACPI.
  • Page 17: Installation Der Cpu

    Installation der CPU Schritt 1: Ziehen Sie den Hebel seitlich vom Sockel weg. Heben Sie den Hebel dann in 90-Grad-Winkel nach oben. Schritt 2: Suchen Sie nach der scharfen Kante, die auf Drehpunkt des Hebels weisen muss. Die CPU passt nur, wenn sie richtig ausgerichtet ist. Schritt 3: Drücken Sie die CPU fest in den Sockel und schließen Sie den Hebel.
  • Page 18: Ddr-Dimm-Modules: Ddr1/ Ddr2

    DDR-DIMM-Modules: DDR1/ DDR2 DRAM-Zugriffszeit: 2.5V unbuffered DDR 200/266 MHz Typ erforderlich. DRAM Typen: 64MB/ 128MB/ 256MB/ 512MB/ 1GB DIMM-Module (184-Pin) Gesamt Speichergröße von nicht registrierter DIMMs DIMM-Sockel DDR-Modul Speichergröße Standort DDR1 64MB/128MB/256MB/512MB/1GB Maximal 2 GB DDR2 64MB/128MB/256MB/512MB/1GB **Nur als Referenz*** Installation von DDR-Modul Öffnen Sie einen DIMM-Slots, indem Sie die seitlich Chips nach außen drücken.
  • Page 19 Peripheral Component Interconnect Slots: PCI1-3 Dieses Motherboard ist mit 3 standardmäßigen PCI-Slots ausgestattet. PCI steht für Peripheral Component Interconnect und bezieht sich auf einem Busstandard für Erweiterungskarten, älteren ISA-Busstandard meisten Schnittstellen ersetzt hat. Dieser PCI-Slot ist für 32 bits vorgesehen. Accelerated Graphics Port Slot: AGP1 Ihr Monitor wird direkt an die Grafikkarte angeschlossen.
  • Page 20 Anschlüsse für die Vorderseite: JPANEL1 PWR_LED ON/OFF JPANEL1 (+) (-) HLED Belegung Funktion Belegung Funktion Sleep Control Schlafen- Lautsprecher Knopf Kein Masse Anschluss Kein Kein Kein Lautsprecher Power LED (+) Power- HDD LED (+) Festplatte Power LED (+) HDD LED (-) Power LED (-) Masse Power-Knopf...
  • Page 21 Auswahl von Stromsmodi für Tastatur/ Maus: JKBV1 JKBV1 Beschreibung Belegung +5V für Tastatur und Maus Pin 1-2 gescglossen Durch +5V reservierte Sapnnung für +5V reservierte PS/2-Tastatur und PS/2-Maus zum Spannung Erwecken von dem System Pin 2-3 geschlossen Anmerkung: Um die Funktion ─ Erwecken durch Tastatur/Maus ─...
  • Page 22 Jumper zum Löschen CMOS: JCMOS1 Beschreibung JCMOS1 Normale Operation (Default) Pin 1-2 geschlossen CMOS-Daten Löschen Pin 2-3 geschlossen Die folgende Schritte leiten Sie, das Kennwort für BIOS-System zurückzusetzen. Es ist wichtig, die Anweisung zu folgen. ※ Prozeß zum Löschen des CMOS: 1.
  • Page 23 Front Panel Audio Header: JF_AUDIO JF_AUDIO Belegung Belegung Mikrofon-Eingabe/Zentrum Masse Mikrofon-Betriebsspannung/B Audio-Betriebsspannung Audio-Signal des rechten Audio-Signal des rechten Kanals zur Vorderseite / Kanals zurVorderseite / Lautsprecher-Signal des Lautsprecher-Signal des rechten Kanals zur rechten Kanals zur Vorderseite Vorderseite Reservieret für spät. Verwendung durch Schlüsse Kopfhörer-Verstärker...
  • Page 24 CPU Frequenz Auswahl: JCLK1 JCLK1 Beschreibung 100MHZ Pin 1-2 geschlossen 133MHz Pin 1-2 geööffnet Game Header: JGAME1 Belegung Belegung Joystick B Knopf 1 Joystick A Knopf 1 Joystick B Koordierung X Joystick A Koordierung X MIDI Ausgabe Masse Joystick B Koordierung Y Masse Joystick B Knopf 2 Joystick A Koordierung Y...
  • Page 25: Warpspeeder

    WarpSpeeder Introduction [ WarpSpeeder™ ], a new powerful control utility, features three user-friendly functions including Overclock Manager, Overvoltage Manager, and Hardware Monitor. With the Overclock Manager, users can easily adjust the frequency they prefer or they can get the best CPU performance with just one click. The Overvoltage Manager, on the other hand, helps to power up CPU core voltage and Memory voltage.
  • Page 26: Installation

    Installation Execute the setup execution file, and then the following dialog will pop up. Please click “Next” button and follow the default procedure to install. When you see the following dialog in setup procedure, it means setup is completed. If the “Launch the WarpSpeeder Tray Utility” checkbox is checked, the Tray Icon utility and [WarpSpeeder™] utility will be automatically and immediately launched after you click “Finish”...
  • Page 27: Usage

    Usage The following figures are just only for reference, the screen printed in this user manual will change according to your motherboard on hand. [WarpSpeeder™] includes 1 tray icon and 5 panels: 1. Tray Icon: Whenever the Tray Icon utility is launched, it will display a little tray icon on the right side of Windows Taskbar.
  • Page 28 This utility is responsible for conveniently invoking [WarpSpeeder™] Utility. You can use the mouse by clicking the left button in order to invoke [WarpSpeeder™] directly from the little tray icon or you can right-click the little tray icon to pop up a popup menu as following figure.
  • Page 29 3. Voltage Panel Click the Voltage button in Main Panel, the button will be highlighted and the Voltage Panel will slide out to up as the following figure. In this panel, you can decide to increase CPU core voltage and Memory voltage or not. The default setting is “No”.
  • Page 30 4. Overclock Panel Click the Overclock button in Main Panel, the button will be highlighted and the Overclock Panel will slide out to left as the following figure.
  • Page 31 Overclock Panel contains these features: a. “–3MHz button”, “-1MHz button”, “+1MHz button”, and “+3MHz button”: provide user the ability to do real-time overclock adjustment. Warning: Manually overclock is potentially dangerous, especially when the overclocking percentage is over 110 %. We strongly recommend you verify every speed you overclock by click the Verify button.
  • Page 32 “Auto-overclock button”: User can click this button and [ WarpSpeeder™ ] will set the best and stable performance and frequency automatically. [ WarpSpeeder™ ] utility will execute a series of testing until system fail. Then system will do fail-safe reboot by using Watchdog function. After reboot, the [ WarpSpeeder™ ] utility will restore to the hardware default setting or load the verified best and stable frequency according to the Recovery Dialog’s setting.
  • Page 33 5. Hardware Monitor Panel Click the Hardware Monitor button in Main Panel, the button will be highlighted and the Hardware Monitor panel will slide out to left as the following figure. In this panel, you can get the real-time status information of your system. The information will be refreshed every 1 second.
  • Page 34 Note: Because the overclock, overvoltage, and hardware monitor features are controlled by several separate chipset, [ WarpSpeeder™ ] divide these features to separate panels. If one chipset is not on board, the correlative button in Main panel will be disabled, but will not interfere other panels’ functions.
  • Page 35: Studiofun

    StudioFun! Introduction StudioFun! is a media-player based on optimized GNU/Linux distribution to bring a “Room Theater” experience into life. It plays DVD, VCD, MP3, Audio CD and other multimedia. Furthermore, Users can take snapshots of video and customize the saved images as screensavers or photo slideshows.
  • Page 36: Error Messages

    StudioFun! Install This option will do the basic installation of the distribution. The installation works on pre-installed windows or GNU/Linux distribution. On selecting the “StudioFun Install” option the installer boots and displays a dialog box indicating the space required and waits for a confirmation. Selecting “Ok” will continue the installation while selecting “Cancel”...
  • Page 37: Booting To Studiofun

    StudioFun! Recover Where there is a MBR (Master Boot record) corruption, the “StudioFun Recover” will automatically probe the hard disk master boot record and find out the installed operating system(s). Once success, it will re-install the boot loader with correct options in the MBR. Please be noted that the newly probed one will over write any custom boot loader option specified from other GNU/Linux installations.
  • Page 38: Media Control

    After executing the boot up, you will see the main Desktop screen. The following section is a complete description of the Desktop application. Desktop This is the main shell of the StudioFun! software. It illustrates two main categories, one is the main "Media Control"...
  • Page 39: Control Panel

    present in the DVD/CD-ROM drive when the Desktop is not launched. This control will glow whenever a DVD is detected in a DVD drive. The DVD will be auto-played only when it is put in to the drive when the Desktop (StudioFun! shell) is up and running, otherwise, the control will simply glow to inform the user about a DVD present in the DVD/CD-ROM.
  • Page 40: File Manager

    2. Screensaver Clicking this icon will invoke the screensaver application. Refer to section 5.3 Screensaver for more details. 3. Display Settings Clicking this icon will invoke the application for changing the screen resolutions. Refer to section 5.4, Display Settings for more details. 4.
  • Page 41: Software Details

    Software Details XINE XINE is a multimedia player. It plays back Audio CD, DVD, and VCD. It also decodes multimedia files like AVI, MOV, WMV, and MP3 from local disk drives. It interprets most of the common multimedia formats. • Features of Xine Skinnable GUI Navigation controls (seeking, pause, fast, slow, next chapter, etc)
  • Page 42 MPEG-Audio (.mp2, .mp3) WAV (.wav) Video CODEC MPEG 1/2 MPEG 4 (aka OpenDivX) MS MPEG 4 Chapter 5: Software Details 10 Windows Media Video 7 m. Motion JPEG • Remote Control Support. Infrared interface User-friendly • Usage of StudioFun! with CelomaChrome skin Select VCD button to play a VCD disc Select DVD button to play a DVD disc Select CDDA button to play a Audio CD...
  • Page 43: Select Region

    m. Select “menu” button to use menu while playing DVD n. Select “control” button to adjust brightness / color o. Select “setup” button to modify the settings of the player p. Select ”f.scr” button to show the video output of the player in full screen mode q.
  • Page 44: Screensaver

    Screensaver Screensaver The xscreensaver daemon waits until the keyboard and mouse have been idle for a period, and then runs a graphics demo chosen at random. The demo is terminated as soon as there is any mouse or keyboard activity. The xscreensaver-demo program is the graphical user interface to xscreensaver.
  • Page 45: Display Settings

    2. Only one Screen Saver: When user chooses this option, screensaver displays only one graphics demo. 3. Blank Screen Only: When user chooses this option, screensaver only blanks the screen instead of displaying the graphics demo. 4. Disable Screen Saver: When user chooses this option, screensaver is disabled. •...
  • Page 46: File Manager

    three resolutions. • 640x480 • 800x600 • 1024x768 The current resolution of the Display will be selected by default. It requires restart of the StudioFun! to reflect the changes made. File Manager Overview File manger is a utility to copy files from deferent devices to hard disk and vice versa. User can copy files from devices such as, floppy, CD-Rom and Flashdisk to hard disk and also from hard disk to floppy and Flashdisk.
  • Page 48: Trouble Shooting

    Trouble Shooting PROBABLE SOLUTION No power to the system at all Power light don’t * Make sure power cable is securely plugged in illuminate, fan inside power supply does not turn * Replace cable on. Indicator light on keyboard does not turn on * Contact technical support PROBABLE SOLUTION...
  • Page 49: Problemlösung

    Problemlösung MÖGLICHE URSACHE LÖSUNG Das System hat keine Spannungsversorgung. * Versichern Sie sich, dass das Stromkabel richtig Die Stromanzeige leuchtet nicht, der Lüfter im angebracht ist Inneren Stromversorgung wird nicht * Ersetzen Sie das Stromkabel eingeschaltet. Tastaturleuchten sind nicht an. * Wenden Sie sich an Ihre Kundendienststelle MÖGLICHE URSACHE LÖSUNG...
  • Page 50 06/20/2003...
