3.3 Wiring of Remote Control Panel (see Figure 3)
The Remote Control Panel is received with a 6-foot long, 20 AWG cable. The
cable will already be attached to the searchlight and should be connected to the
remote control panel connector to row.
Remote Control Panel
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10 10
11
11
12
12
3.4

Searchlight Unit

The Searchlight Unit can be mounted where desired, using appropriate length
3/8", stainless steel fasteners. Keep navigational aids / GPS antennas out of the
beam path of the light. It is recommended to mount antenna 10 feet behind the
light minimum.
searchlight, have been inserted in the searchlight base mounting holes to prevent
a galvanic reaction between the mounting hardware and the base of the
searchlight, and also that the mounting base gasket is securely in place before
bolting down. Silicone grease should be applied to the bottom of the gasket to
help in waterproofing the unit. When mounting, be sure that the unit is able to
rotate 360° without hitting any obstructions.
details. Mount unit so that the ID label on mounting base faces forward. This is
the home position when light is reset. (See instructions on controls) CAUTION:
The searchlight is not designed for inverted mounting.
CAUTION: Xenon-Arc lights emit electromagnet radiation, which may interfere
with some communication or navigation systems mounted on board.
Source DC 24V ± 10% 8.5A
Control Cable
AWG 20 0.5sq - 15c
FIGURE 3
Be sure the 4 nylon shoulder washers, supplied with the
5
Vinyl Castyre Cable
XENON SEARCHLIGHT
600V - VCT - 5.5sq - 2c
+ white
- black
red
1
2 white
black
3
4 brown
yellow
5
green
6
light green
7
pink
8
light blue
9
orange
10
gray
11
blue
12
Vinyl Castyre Cable
300V - VCTF - 0.5sq - 15c
Refer to Figure 4 for mounting
PP-307
+
-
1
2
3
4
5
6
7
8
9
10
11
12
CH1
Y1-03-0139 Rev. C
