Foreword
Congratulations and thank you for purchasing the ACR RCL-600A Remote Control
Searchlight. The combination of superior design, high quality raw materials and quality
controlled manufacturing produces a product that will perform for years to come. The
test facility at ACR can reproduce some of the harshest environmental conditions known
to man. This assures that the products we design and manufacture can stand up to the
rigors found in a marine environment. With proper care and maintenance, your SSAS
will be in service for years to come.
ACR is proud to be certified to the ISO 9001:2000, the International Standard for
Quality.
This manual provides installation, operation and maintenance instructions for the RCL-
600A Remote Control Searchlight, hereinafter referred to as the beacon. This manual
also describes the characteristics and details of the beacon system. The FCC
authorizes the use of 406 MHz radio beacon by any ship that is also equipped with a
VHF Ship Station. This will make the 406 MHz radio beacon available for use on most
U.S. ships and boats.
1.0 GENERAL ............................................................................................................... 2
2.0 RCL-600A SPECIFICATIONS ................................................................................. 2
3.0 INSTALLATION AND OPERATION INSTRUCTIONS ............................................ 3
3.1 WIRING OF UNIT .............................................................................................. 3
3.2 REMOTE CONTROL PANEL (MASTER) ......................................................... 4
3.3 WIRING OF REMOTE CONTROL PANEL ....................................................... 5
3.4 SEARCHLIGHT UNIT........................................................................................ 5
3.6 INSTRUCTIONS ON CONTROLS..................................................................... 8

TABLE OF CONTENTS

1
Y1-03-0139 Rev. C
