Intel I7-900 DESKTOP PROCESSOR - DATASHEET VOLUME 1 Datasheet page 42

Table 4-1. Land Listing by Land Name
(Sheet 11 of 29)
Land
Land Name
No.
QPI_DTX_DP[1] AF39
QPI_DTX_DP[10] AF43
QPI_DTX_DP[11] AE42
QPI_DTX_DP[12] AD42
QPI_DTX_DP[13] AC43
QPI_DTX_DP[14] AD40
QPI_DTX_DP[15] AC41
QPI_DTX_DP[16] AC39
QPI_DTX_DP[17] AB39
QPI_DTX_DP[18] AD38
QPI_DTX_DP[19] AE40
QPI_DTX_DP[2] AK37
QPI_DTX_DP[3] AJ38
QPI_DTX_DP[4] AH40
QPI_DTX_DP[5] AK40
QPI_DTX_DP[6] AH41
QPI_DTX_DP[7] AK42
QPI_DTX_DP[8] AJ43
QPI_DTX_DP[9] AG40
RESET# AL39
RSVD D35
RSVD D34
RSVD C36
RSVD A36
RSVD F32
RSVD C33
RSVD C37
RSVD A37
RSVD B34
RSVD C34
RSVD G34
RSVD G33
RSVD D36
RSVD F36
RSVD E33
RSVD G36
RSVD E37
RSVD F37
RSVD E34
RSVD G35
RSVD G30
RSVD G29
RSVD H32
RSVD F33
RSVD E29
RSVD E30
RSVD J31
RSVD J30
42
Buffer
Direction
Type
QPI O
QPI O
QPI O
QPI O
QPI O
QPI O
QPI O
QPI O
QPI O
QPI O
QPI O
QPI O
QPI O
QPI O
QPI O
QPI O
QPI O
QPI O
QPI O
Asynch I
Table 4-1. Land Listing by Land Name
(Sheet 12 of 29)
Land
Land Name
No.
RSVD F31
RSVD F30
RSVD AB5
RSVD C13
RSVD B9
RSVD C11
RSVD B8
RSVD M43
RSVD G43
RSVD C39
RSVD D4
RSVD J1
RSVD P1
RSVD V3
RSVD B35
RSVD V42
RSVD N42
RSVD H42
RSVD D39
RSVD D5
RSVD J2
RSVD P2
RSVD V2
RSVD B36
RSVD V43
RSVD B20
RSVD D25
RSVD B28
RSVD A27
RSVD E15
RSVD E13
RSVD C14
RSVD E12
RSVD P37
RSVD E35
RSVD K37
RSVD K33
RSVD F7
RSVD J7
RSVD M4
RSVD Y5
RSVD AA41
RSVD P36
RSVD L37
RSVD K34
RSVD F8
RSVD H7
RSVD M5
Land Listing
Buffer
Direction
Type
Datasheet
