ScanSoft OMNIPAGE DIRECT 2 FOR WINDOWS Installation Manual page 24

Partial Page
Zoom in
Zoom out
Draw zones
Order zones
Erase zones
22 Commands and Settings
If you highlight Partial Page, the zone window will appear after the scan.
Start
recognition
Stop recognition
and return to your
application
The Partial Page Tools
These tools let you select and order zones and zoom the view in or out. The
buttons on the button bar let you start and cancel the recognition process
and adjust settings in the Options dialog box.
Zoom in/out
If you want a close-up view of an area, click the Zoom in tool and then click
on the area of the page you want enlarged. Click the Zoom out tool and then
click on the area to zoom to a wider view.
The levels of zoom are Fit in Window, 25%, 50%, and 100%. The 100% view
gives you a pixel-for-pixel view of the scanned image. If you want to zoom
all the way in or out, hold down the CTRL key when you click on a zone
with a zoom tool.
Draw zones
Click this tool and then enclose each area you want recognized with a
selection box by holding the mouse button down and dragging the mouse.
Zones will be recognized in the order you select them unless you use the
Order zones tool (the # symbol).
A number appears in each zone indicating the order in which the zone will
be recognized. You may draw up to 99 separate zones.
Once you have drawn a zone, you can adjust its size. First, click on the
zone to select it. Handles will appear on the edge of the selection box. Then
move the mouse pointer to a handle, hold the mouse button down, and
Open the Stop recogni-
Options dia- tion and return
log box
to this window
Rotate image
°
90°, 180 , or
°
270
