- Page 1 THE WHISTLER GROUP, INC. CORPORATE HEADQUARTERS 13016 N. Walton Blvd. Bentonville, AR 72712 TEL (479) 273-6012 FX (479) 273-2927 www.whistlergroup.com CUSTOMER RETURN CENTER 1201 N. Dixieland Rd. Rogers, AR 72756 Consumer Relations Tel (800) 531-0004 Email: info@whistlergroup.com P/N 202882, © WHISTLER 2003...
- Page 2 Installation Instructions 3300A/3400 Laser/Radar Detectors www.whistlergroup.com...
-
Page 3: Tools Required
TOOLS REQUIRES Tools Required For Installation • Phillips or Blade Screwdriver • 3/8" Open End Wrench • Electric Drill • Drill Bit: 13/64", 5/16”. 7/64”, 9/64”, and 13/64” • Other Tools May Be Required Based On Your Vehicle Type Or Requirements For Customized Installation Dimensions: •... -
Page 4: Table Of Contents
TABLE OF CONTENTS Topic Page Tools Required Whistler 3300A/3400 Components Mounting Brackets Mounting Fasteners 5 - 6 Installation of Radar Antenna 7 - 11 Installation of Temperature Probe Installation of LRM-5 12 - 13 Istallation of Control Panel 14 - 16... -
Page 5: Whistler 3300A/3400 Components
WHISTLER 3300A/3400 COMPONENTS Radar Antenna Temperature Probe The waterproof radar antenna with Temperature Probe is mounted at the front of your vehicle, usually behind the grill. Control Panel And Power Cable The compact control panel is mounted on the dash in a location convenient for viewing. -
Page 6: Mounting Brackets
MOUNTING BRACKETS INTRODUCTION Antenna Mounting Brackets And 45º Reflector Large L Bracket (1) Small L Brackets (2) 45º Reflector (For use when mounting antenna in vertical position. Control Panel Mount Brackets Hanging Bracket Thru Dash Bracket... -
Page 7: Mounting Fasteners
MOUNTING FASTENERS Bolt Bolt #10-32 x 1/2" #10-32 x 1-1/4" Lock Flat #10-32 Washer Washer Sheet metal Sheet metal Screw Screw #4 x 5/8" #6 x 3/4" Hook and Loop Fastener Mountable Cable Tie 4" Cable Tie Interface Cable... -
Page 8: Mounting Fasteners 5
MOUNTING FASTENERS Reference Description/Use Bolt #10-32 x 1-1/4" • Fastens Large L or Small L Bracket to vehicle support. Bolt #10-32 x 1/2" • Fastens Small L to Large L Bracket (optional approach). Nut #10-32 • Use with #10-32 bolts. Lock Washer •... -
Page 9: Installation Of Radar Antenna
INSTALLATION OF RADAR ANTENNA General Information The radar antenna is waterproof and designed to be mounted at the front of your vehicle. In most vehicles the best mount- ing location is directly below or behind the bumper. Other locations which provide concealment and/or protection of the antenna such as on the rear deck (next to the third brake light) may be acceptable. - Page 10 INSTALLATION OF RADAR ANTENNA The layout of holes on the large L Bracket accommodates multiple antenna mounting positions. This arrangement provides flexibility for fastening the anten- na/bracket assembly to your vehicle in a manner that allows the antenna window (ANTENNA) to have a forward looking view of the road behind.
- Page 11 INSTALLATION OF RADAR ANTENNA Large L and Small L Brackets may be used in combination. The Small L Brackets are fastened to the Large L Bracket using the #10-32 x 1/2" bolts, #10-32 nuts and lock washers. To fasten the Large L or Small L Brackets to your vehicle, mark the supporting structure through the appropriate holes in the brackets, then drill the holes in the supporting structure with a 13/64"...
- Page 12 INSTALLATION OF RADAR ANTENNA Best mounting angle for optimum detection of all types of radar guns. Radar antenna mounted in horizontal position. Horizontal Mounting When mounting the antenna in a horizontal position (or on an angle between), remember to keep the ANTENNA window as close to perpendicular as possible to the road surface (ANTEN- NA window should not be angled up toward the sky or down toward the road surface).
-
Page 13: Installation Of Temperature Probe
INSTALLATION OF RADAR ANTENNA Mount the antenna to the vehicle such that the ANTENNA window is facing the road surface, sky, right or left of the vehicle, and the reflector has an unobstructed view of the road ahead. This side facing forward traffic Antenna window Signal... -
Page 14: Installation Of Lrm-5
INST ALLA TION OF LRM-5 Antenna Cable to Control Panel Once the antenna is installed (the 3400 model has a Quick Disconnect Interface Cable. Connect the cable from the radar antenna to this cable. Tie this cable in knot similar to using an electrical extension cord. - Page 15 INST ALLA TION OF LRM-5 Installing the LRM-5 Before using, attach the suction cup and rubber bumpers (2) to the metal bracket. If necessary, you may bend the metal bracket in order to position the LRM-5 correctly (3-lens array facing forward, single lens facing behind.) LRM-5 mounted with windshield bracket.
-
Page 16: Istallation Of Control Panel
INST ALLA TION OF CONTROL PANEL General Information The control panel may be mounted using the Under Dash Bracket or Hook & Loop fastener supplied. As an alternative, you may also use a Through Dash Bracket. When choosing a mounting location, consider your needs for ease of viewing the display, accessibility of controls (remember Mute Mode may be used frequently), and concealment. - Page 17 INST ALLA TION OF CONTROL PANEL Control Panel Mounted With Hook & Loop Fasteners Fasteners can be used to mount the top or bottom of the control panel to your vehicle. Before adhering the adhesive side of the fastener to a surface, clean that surface with isopropyl alcohol. Use of Hook &...
- Page 18 INST ALLA TION OF CONTROL PANEL Antenna Cable Connection The stereo connector (straight end) on the end of the antenna cable plugs into Radar 1 port (2) on the back of the control panel. LRM-5 Cable Connection After mounting the LRM-5, conceal the cable and plug the stereo jack connector (right angled end) into the port on the back of the control panel labeled LASER port (5).
-
Page 19: Optional Accessories
Added Protection From Behind For drivers interested in gaining increased detection range when radar is transmitted from behind, the Whistler 3300 can be upgraded with a second antenna. This antenna is mounted facing rearward and can be purchased from many Whistler retailers or directly from Whistler;... -
Page 20: Troubleshooting Guide
TROUBLESHOOTING PROBLEM: No display or audio. • Check fuse in power cable, replace if necessary. • Check fuse in fuse box, replace if necessary. • Make sure power cable is properly grounded. PROBLEM: Unit alarms when using vehicle equipment or electrical accessories (brakes, power mirrors/windows, directionals, horn, etc.) •... -
Page 21: Warranty
• Look for cuts in the cable If difficulties occur which cannot be solved by information in this Troubleshooting Guide, please call Whistler Customer Service at 1-800-531-0004 or visit our FAQ page at www.whistlergroup.com, before returning your unit for service. -
Page 22: Accessories
ACCESSORIES The following accessories can be ordered directly from Whistler by calling 1-800-531-0004 or visit our online store at www.whistlergroup.com Order Description Price Code 206880 Hardwire Kit (10' ) $ 9.95 (for wiring to fuse box) 202971 Voice Module $ 69.95...
