Chapter 3 Installing the Cisco uBR7200 Series Router
Figure 3-4
See the
mounting information.
Figure 3-5

Cable-Management Bracket Requirements

There are two cable-management bracket configurations available for rack-mounting the
Cisco uBR7200 series router. In the first configuration, for a 4-post rack, the rack-mount brackets are
installed at the rear of the chassis and the cable-management bracket is installed at the right front of the
chassis. (See
in the rack.
If you rack-mount a Cisco uBR7246 or Cisco uBR7246VXR router from the front, you cannot install a
Note
cable-management bracket.
OL-5421-03
Installing the Chassis in a 4-Post Rack-Chassis Protruding Front Installation
Rack-mount bracket
"Installing Rack-Mount Brackets in the Middle of the Chassis" section on page 3-10
Installing the Chassis in a Telco-Type Rack
Rack-mount
bracket
Figure 3-6 on page 3-6.) You must install both sets of brackets before you install the chassis
Cisco uBR7200 Series Universal Broadband Router Hardware Installation Guide
Cisco uBR7200 Series Chassis Rack-Mounting Options
for bracket
3-5
