each case, the program stores and restores volume contents only. The type or other
properties of the target volume will not be changed.
However, the partition resize is possible when you restore a dynamic volume to a basic disk
partition.
If Acronis True Image Server runs in rescue mode (for example, booted from Bootable
Rescue media), dynamic disks will not be accessible. Therefore, to be able to repair a system
partition, you must keep its image on a basic, network, or removable disk.

3.8 Backing up to tape drive

Acronis True Image Server supports SCSI tape drives. It can store backups on the tape and
restore data from the tape, store large backups to multiple tapes, and append
incremental/differential changes to a tape with the existing archives.
If a SCSI tape drive is connected to the server, the list of devices available for backup
storage will be extended with a name corresponding to the drive type.
Backup and restore on the tape proceed in the same way as with other devices, with the
following exceptions.
1. A full backup can be stored on an empty tape only. If you use tape that already contains
data, its contents will be overwritten.
2. In case you want to keep more than one archive on the tape, for example, back up two
disks separately, choose
an initial backup for the second disk. In other situations, incremental backup is used for
appending changes to the previously created archive.
3. You do not have to provide filenames for backups.
You might experience short pauses that are required to rewind the tape.
Low-quality or old tape, as well as dirt on the magnetic head, might lead to pauses that can
last up to several minutes.

3.9 Viewing disk and partition information

You can change the way of data representation in all schemes you see in various wizards.
To the right are three icons: Arrange Icons by, Choose Details and i (Display the
properties of the selected item), the last duplicated in the context menu invoked by
right-clicking objects.
To sort messages by a particular column, click the header (another click will switch the
messages to the opposite order) or Arrange Icons by button and select the column.
To select columns to view, right-click the headers line or left-click the Choose Details
button. Then flag the columns you want to display.
If you click the i (Display the properties of the selected item) button, you will see the
selected partition or disk properties window.
This window contains two panels. The left panel contains the properties tree and the right
describes the selected property in detail. The disk information includes its physical
parameters (connection type, device type, size, etc.); partition information includes both
physical (sectors, location, etc.), and logical (file system, free space, assigned letter, etc.)
parameters.
20
incremental
backup mode instead of a
full
backup when you create
