- Page 1 User manual RTD315 AUX IN It is important to read this instruction book prior to using your new product for the first time.
-
Page 2: Fcc Information
FCC Information Ventilation This device complies with Part 15 of the FCC Rules. Operation is subject to the following You must adequately ventilate the product. two conditions: (1) This device may not Make sure there is adequate space around cause harmful interference, and (2) this the unit to provide proper air flow for device must accept any interference ventilation. -
Page 3: Important Information
Important Information For your safety Service information The AC power plug is This product should be serviced only by polarized (one blade is those specially trained in appropriate wider than the other) servicing techniques. For instructions on how and only fits into AC to obtain service, refer to the warranty power outlets one way. - Page 4 Important Information Important battery information CAUTION controls or adjustments or performance new and old batteries. Do not use rechargeable batteries. of procedures other than those specified herein may result in observe the polarities indicated inside the battery compartment. Replace only with open covers and do not repair yourself.
-
Page 5: Important Safety Instructions
Important Safety Instructions Please read and save for • Unplug this apparatus during lightning future reference storms or when unused for long periods of time. Some of the following information may not • Refer all servicing to qualified service apply to your particular product; however, as personnel. -
Page 6: Table Of Contents
Table of Contents Connections and Setup USB Device ........Connecting to your TV (VIDEO). -
Page 7: Connections And Setup
Connections and Setup Accessories provided Left and right Remote control and Left and right Center speaker Subwoofer Surround 2 AAA batteries front speakers Speakers One external AM Composite One Pig-Tail loop antenna Video Cable antenna wire Things to consider before •... -
Page 8: Connecting To Your Tv (Video)
Connections and Setup Connecting the antennas Method 2 Component video jacks (Pr, Pb, Y) • The component video jacks are color-coded green, blue and red. FM 75 Ω • Additional component video cables (not supplied) are required to provide best picture Whit e quality. -
Page 9: En Connecting To Your Tv (Via Hdmi Input)
Connecting to your TV (via HDMI Using AUX IN 2 jacks input) Connect the AUX IN 2 jacks on the front panel of the unit to the AUX OUT (AUDIO OUT) jacks on HDMI stands for High Definition Multimedia VCR, TV, Set Top Box or other component. Interface. -
Page 10: Connecting The Speakers
Connecting the speakers Speaker wires are color-coded to match the terminals. Connect the speaker wire from the back of each speaker to the corresponding color terminal at the back of the unit. Press down the tab to open the terminal and insert the wire. Release the tab to lock wire in the terminal. Front Speakers Center Speaker Right... -
Page 11: Positioning Speakers
Connections and Setup Positioning speakers Front speaker placement For best results, follow the speaker placement below. Alignment Align the center speaker evenly with (A) or slightly behind (B) (the left and right speakers), but not ahead of them. Courtesy Dolby Laboratories 1. -
Page 12: Better Surround Placement
No adjacent walls Better surround placement Surround speakers can go on stands facing each other to approximate sidewall mounting Location (A), or to the sides or rear of the viewing area, If possible, place surround speakers to either aimed upwards; they can go right on the side of the listening area, not behind it. -
Page 13: Overview Of Controls
Overview of Controls Front panel controls Opens and closes Starts/pause Adjusts the Switches the Stops disc the disc tray. volume. unit on and off. playing a disc. playback. AUX IN Selects the input sources. AUX IN jacks - Connects USB Toggles between Press repeatedly to select: connects audio... -
Page 14: Mode
AUDIO – Accesses the audio function (p.12). ANGLE – Accesses the camera angle function for DVD disc (p.13). ZOOM – Accesses the Zoom function (p.10, 15). SUBTITLE – Selects the subtitle languages or turns subtitle off (if available) (p.12). HDMI – Changes video output signals (480p, 720p, 1080i or 1080p) (p.14). -
Page 15: On Screen Menus
Overview of Controls Using remote control to navigate Note: through the on-screen menus Insert 2 "AAA"("UM-4"/"R03") batteries to the remote control prior to and OK on the remote control to navigate use. through the on-screen displays (the DVD player’s menu, the Info Display that appears during playback, or a disc’s menu). -
Page 16: Basic Playback Operations
Basic playback operations Zoom 1. While a disc is playing, press ZOOM until Playback you reach the zoom size you want. The Switch the unit and the TV set on. ZOOM button toggles through 2x, 3x, 4x 1. After loading a disc, playback starts and then zooms out to 1/2x, 1/3x and 1/4x, automatically, or the disc menu appears. -
Page 17: The Info Menu
Playing Discs - Basic Functions Notes: minutes without any user interaction, a • When you press STOP, the unit stores the screen saver is activated. At the end of point where playback was interrupted. If 30 minutes without any user interaction, you press PLAY again, playback resumes the unit switches off automatically. -
Page 18: Title/Chapter (Dvd)/Track
Title/chapter (DVD)/track This option is only available if the disc offers dialog languages or audio formats. When (audio CD ) you change the dialog language using the To directly access a title, chapter (DVD) or a Info menu, it only changes the dialog track (audio CD), press INFO, press OK. -
Page 19: Camera Angle (Dvd)
The Info Menu Camera angle (DVD) Creating a Program List for Program Play Mode (Audio Some discs offer different camera angles for specific scenes. CDs and DVD discs) 1. To change the camera angle, press the ANGLE button on the remote or press the To use program play mode, you must first INFO button twice and select the Camera create a program list. -
Page 20: Creating A Program List For Play Mode Bookmark/Sleep/Introscan(Cd)
Creating a program List for Note: This function is only program play mode (mp3 CDs) available with discs whose elapsed time or remaining time appears in To use program play mode with an mp3 disc, the Info menu. you must first create a program list. You can program up to 16 songs. -
Page 21: Mp3/Wma Files And Jpeg Files
Mp3/WMA Files and jpeg Files During the slide show you can use the Playing mp3/WMA files or left/right button to rotate the picture, the displaying jpeg files up arrow button to rotate the image vertically, the down arrow button to Mp3/WMA is an audio file format which rotate the image horizontally. -
Page 22: Radio
Radio Manual preset The unit has a built-in tuner that allows for FM radio function. The AM loop antenna 1. Tune to a radio station (see “Manual allows for AM radio function. tuning” for details). 2. Press MEMORY. While the Program Preset number is still flashing, input your desired Manual tuning preset number using the numeric buttons... -
Page 23: Usb Device
USB Device An overview USB device playback features This unit supports MSC devices. You can 1. Press USB to select USB mode. connect your own USB storage devices, then 2. Playback starts automatically. Press PAUSE you can start playback. to pause playback and press PLAY again to resume. -
Page 24: Cd Ripping
CD Ripping An overview To stop ripping during the process, highlight STOP button and press OK. CD ripping allows you to rip tracks on CD to USB device. This unit supports Mass Storage When ripping has finished, press REC to quit Class (MSC) devices. -
Page 25: The Setup Menu
The Setup Menu There are four options in the main setup menu: General Setup, Display Setup, Speaker General Setup Setup and Language Setup. Password Lock Rating Unlock Press SETUP to bring up the main menu. Slide Time Select one of the menu icons across the top of the screen using the left/right arrow buttons. -
Page 26: Rating
Language Setup Rating Explanations • The disc publisher is responsible for coding With this menu, you can set the language for scenes according to the rating limits. Below unit menus, dialog, subtitles and the disc is an explanation of Ratings. menus. -
Page 27: Subtitles
Audio Setup Subtitles Select the subtitle language using up/down You can adapt your unit to other equipment arrow buttons and press OK. and access specific functions with the Audio Setup menu. To change the language of the subtitles 1. Select the Audio Setup icon in the main during playback, press INFO twice for DVD menu using the left/right and use the left/right arrow buttons to... -
Page 28: Test Tone
Video Test Tone Progressive Function provides high quality This function is used to test the speaker pictures with less flickering. Turn setting and change the speaker level. A short Progressive Scan if you used the Component noise comes successively from Video jacks of the unit to connect a TV or each speaker. -
Page 29: Additional Information
Additional Information Troubleshooting No surround sound. • Check the speaker configuration in the The unit does not switch on. Setup menu (See Positioning speaker on • Make sure it is plugged in. pages 4-5 or Audio Setup on page 19). •... -
Page 30: Precautions
Precautions Handling and caring for discs • Handle your discs with care. Hold the disc with your fingers at the edges or through • If your unit has been stored in a cool place the hole. for any length of time, during a journey •... -
Page 31: Compatible Formats
Additional Information However, depending on the condition of the Compatible Formats CD-writer, computer and the disc used, you may find that not all discs will play. When In order to ensure playback, discs must playing a CD-R disc, it is normal for the unit conform with DVD or CD to take up to 20 seconds to recognize the standards. -
Page 32: Sound Enhancement Systems
• Do not record copyright-protected mp3 Sound Enhancement Systems files. “Securized” files are encrypted and code protected to prevent illegal copying. This receiver is equipped with several built-in sound enhancement systems. jpeg files CD-R and CD-RW with jpeg files. Certain Manufactured under license from Dolby Laboratories. -
Page 33: Technical Specifications
Additional Information Technical Specifications: AM Tuner Section: Frequency Response: 2kHz +/-3dB, 400Hz ref. Amplifier Section: Usable Sensitivity: 3000uV/m @ S/N 20dB RMS Output Power: Dolby Digital Mode with Signal to Noise: 38dB 10% Total Harmonic Distortion IF Rejection: 35dB Rear Channels: 32Watts channel (1KHz, 4Ohm) FM Tuner Section: Front and Center Channel: 32 Watts... -
Page 34: Limited Warranty
