7. Check for debris in pump. If
debris is found, blow out with
compressed air.
8. Install insert and rotor.
9. Check gap on rotor. Adjust to
.003"/.004" (.076-.101 mm) if
needed (see Figure 16).
Note: Rotate rotor one full turn to
insure the gap is .003"/.004" (.076-
.101 mm) at tightest position. Adjust
if needed.
(Pump Rotor, continued)
10. Install blades, pump plate, air
filters, and filter end cover.
11. Replace fan guard and upper
shell.
12. Adjust pump pressure (see page
12).
Note: If rotor is still binding,
proceed as follows.
13. Perform steps 1 through 6 (see
page 13).
14. Place fine grade sandpaper (600
grit) on flat surface. Sand rotor
lightly in "figure 8" motion four
times (see Figure 17).
15. Reinstall insert and rotor.
16. Perform steps 10 through 12
above.

SPECIFICATIONS

14
Blade
Figure 16 - Gap Adjusting Screw Locations
Figure 17 - Sanding Rotor
Output Rating (Btu/Hr.)
Fuel
Fuel Tank Capacity (U.S. Gal./Liters)
Fuel Consumption (Gal. Per Hr./Liters Per Hr.) 1.1/4.16
Electric Requirements
Amperage (Normal Run)
Amperage (Start)
Hot Air Output (CFM/CMM)
Motor RPM
Gap Adjusting Screw
.003"/.004"
(.076-.101 mm) Gap
Measured With
Feeler Gauge
Rotor
Gap Adjusting Screw
Sandpaper
150,000
Use Only Kerosene or No. 1 Fuel Oil
13.5/51
220 volt/60 hertz
2
9
500/14.2
3450
103252
