MPX 1 User Guide
Internal Audio Data Paths
Control Interface
General
Electrical Approvals
11-2
Conversion: 18 bit A/D, 20-bit D/A
DSP: 32 bits
S/PDIF I/O: 24 bits
MIDI: 7-pin DIN connector for MIDI IN/powered bidirectional remote
5-pin DIN connectors for MIDI THRU and OUT
Footswitch: 1/4 inch T/R/S phone jack for 3 independent footswitches
Foot pedal: 1/4 inch T/R/S phone jack (10k
Remote
Power In: 2.5mm barrel for 9VAC remote power
Dimensions: 19.0"W x 1.75"H x 9.0"D (483 x 45 x 289mm)
19 inch rack mount standard, 1U high
Weight: Net: 6lbs 2oz (2.8kg)
Shipping: 9lbs 3oz (4.2kg)
Power
Requirements: 100-240VAC, 50-60Hz, 25W, 3-pin IEC power connector
Environment: Operating temperature: 32˚ to 104˚F (0˚ to 40˚C)
Storage temperature: -22˚ to 160˚F (-30˚ to 70˚C)
Humidity: maximum 95% without condensation
Safety
Compliance: UL1419 and CSA 22.2 No. 1-94 (UL and C-UL marks)
EN60065 (TUV-GS and CE marking per Directive 73/23/EEC)
EMC
Compliance: FCC Class B
EN55022 Class B and EN50082-1
(CE marking per Directive 89/336/EEC)
Specifications subject to change without notice.
min, 100k max impedance)
