Audio Input
Audio Output
A/D Performance
D/A Performance
A/A Performance
Digital Audio Interface
Connectors: 1/4 inch T/R/S phone jacks (2), XLR 3-wire balanced (2)
Impedance: +4dB/BAL switch position: 100k
-10dB/UNBAL switch position: 50k
Levels: +4dB/BAL switch position: -2dBu min for full scale, +20dBu max
-10dB/UNBAL switch position: -14dBu min for full scale, +8dBu max
CMRR: +4dB/BAL switch position: 40dB minimum, 10Hz to 20kHz
Connectors: 1/4 inch T/R/S phone jacks (2); XLR 3-wire balanced (2)
Impedance: 600 , unbalanced
Levels: +18 dBu max, full scale
Frequency
Response: 20Hz to 20kHz,±1dB
Crosstalk: -60dB max
S/N Ratio: 90dB min, 20kHz bandwidth
THD: 0.01% max, 20Hz to 20kHz
Dynamic
Range: 90dB min, 20kHz bandwidth
Delay: 55.5 samples (1.25ms @ 44.1kHz)
Frequency
Response: 20Hz to 20kHz, ±1dB
Crosstalk: -60dB max
S/N Ratio: 95dB min, 20kHz bandwidth
THD: 0.01% max, 20Hz to 20kHz
Dynamic
Range: 95dB min, 20kHz bandwidth
Delay: 25 samples (0.57ms @ 44.1 kHz)
Frequency
Response: 20Hz to 20kHz, ±1dB
Crosstalk: -60dB max
S/N Ratio: 95dB typical, A-weighted
THD: 0.01% max, 20Hz to 20kHz
Dynamic
Range: 95dB typical, A-weighted
Connectors: Coaxial, RCA type
Format: conforms to S/PDIF CP-340 Type II
Sample Rate: 44.1kHz
