Summary of Contents for DigiTech HYPER PHASE
-
Page 2: Declaration Of Conformity
European Contact: Your local DigiTech Sales and Service Office or not operate normally, or has been dropped. 11.WARNING:To reduce the risk of fire or electric... - Page 3 6.The consumer forfeits the benefits of this warranty if the product's main assembly is opened and tam- pered with by anyone other than a certified DigiTech technician or, if the product is used with AC volt- ages outside of the range suggested by the manufacturer.
- Page 4 Controls the depth of the phase shift effect. Turn this knob clockwise to increase the depth, and counter-clockwise to decrease the depth. 3. AC Adapter Jack Connect a DigiTech PS200R (9VDC output) power supply to this jack. Use the proper supply for your area’s Mains line voltage. 4. Regen Knob Controls the amount of regeneration (feedback) in the phaser effect.
- Page 5 2 3 4...
- Page 6 5.Type Knob Selects 1 of the 7 different phaser effect types. 1-STAGE A - A 4 stage phase shifter. 2-STAGE B - An 8 stage phase shifter. 3-STAGE C - A 12 stage phase shifter. 4-RISE / FALL - Creates a constant rising phaser sound when the REGEN knob is set between the minimum and 12 o’clock positions, REGEN...
-
Page 7: Indicator Led
6. Input Jack Connect your instrument to this jack. Connecting a guitar cable to this jack supplies battery power even though the Indicator LED may not be lit. To prolong battery life, disconnect all cables from the pedal when not in use. - Page 8 11. Out 2 Jack Connect this output to a second amplifier or mixer channel for stereo phasing. Stereo is the best way to get the most effective stereo phaser experience from the Hyper Phase pedal. Connections The Hyper Phase has a single input and a pair of outputs. Out 1 is used if the Hyper Phase is being connected to only one amplifier or mixer channel panned center.
-
Page 10: Battery Replacement
Battery Replacement 1. Using the tip of a 1/4” guitar cable, push one of the release pins in on either side of the pedal, and remove the pedal from the pedal chassis. 2. Remove the battery from the battery compartment and disconnect the battery cable. - Page 11 Pedal Pedal Switch 9V DC Battery Pedal Release Battery Compartment Pedal Release Spring Pedal Chassis...
-
Page 12: Specifications
• Jacks - Input, Out 1 (Mono), Out 2 FAX (801) 566-7005 • Input Impedance - 1 MOhms DigiTech and X-Series are trademarks • Output Impedance - 100 Ohms of the Harman Music Group Inc. • Power Supply - 9V Alkaline Dry Battery •...
