VTech 3111-2 Quick Start Manual

Quick start guide

for model DS3111-2
Telephone base installation
We recommend that you install the telephone base away from any electronic
equipment and appliances such as personal computers, computer routers,
television sets, microwave ovens or refrigerators. Avoid excessive heat,
cold, dust or moisture. When a location is selected, install the telephone
base and the charger as shown below. Make sure that the electrical outlet
is not controlled by a wall switch.
Telephone
Power adapter
wall jack
Electrical outlet
not controlled
by a wall switch
Telephone
line cord
EQUIPMENT
TELEPHONE
ONLY SOURCE POWER 2 CLASS
300mA 6V DC
PHONE. THIS USING WHEN ENSURED BE NOT MAY COMMUNICATIONS
OF PRIVACY OPERATION. UNDESIRED CAUSE MAY THAT INTERFERENCE INCLUDING
RECEIVED, INTERFERENCE ANY ACCEPT MUST DEVICE THIS 2) AND INTERFERENCE;
HARMFUL CAUSE NOT MAY DEVICE THIS 1) CONDITIONS: TWO FOLLOWING THE
TO SUBJECT IS OPERATION RULES. FCC THE OF 15 PART WITH COMPLIES DEVICE THIS
EW780-5656-00 ID: FCC HAC
RJ11C/RJ11W JACK: USOC
0.1B EQUIVALENCE: RINGER
US:EW7W401B80-565600 NO.: REGISTRATION
68 PART CFR 47 WITH COMPLIES
CHINA IN MANUFACTURED

Handset battery installation

Install the handset battery by following these steps:
1. Align the two holes of the battery plug with the socket pins in the handset
battery compartment, matching the red and black wires to the color-
coded label.
2. Place the battery in the compartment with the wires in the lower right
corner.
3. Position the battery compartment cover and slide it towards the unit
until it clicks into place.
For optimal performance, we recommend that you charge the handset for
16 hours. You can keep the battery charged by returning the handset to the
telephone base after each use. When the battery power is fully depleted,
a full recharge takes about 16 hours.
QSG DS3111-2 071207.indd 1
NOTE:
You must program your voicemail buttons before you can access all of
the functions available with your voicemail.
Voicemail setup
This feature allows you to use the VOICEMAIL, PLAY, SKIP and ERASE
buttons to access your voicemail (a subscription service available from
Charger adapter
your local telephone company for a fee). Before completing these steps, be
sure to have your access number and password to access your voicemail
available. You will also need the key sequence to play, skip and delete your
messages. Contact your local telephone company for more information
about voicemail service.
To program the ACCESS NUMBER button:
1. Press MENU/SELECT from the idle mode.
2. Press or to select VOICEMAIL SETUP, then press
MENU/SELECT.
3. Press or to select ACCESS NUMBER, then press
MENU/SELECT.
4. Use the dial pad to enter the access number. Press MUTE/REMOVE
to delete characters if necessary.
5. Press MENU/SELECT. You'll hear a confirmation tone.
To program the PASSWORD, PLAY, SKIP and ERASE buttons, follow
the above steps.
To program a pause:
1. Press MENU/SELECT from the idle mode.
2. Press or to select VOICEMAIL SETUP then press MENU/SELECT
twice.
3. The blinking cursor should be at the end of your access number. Press
and hold the REDIAL/PAUSE button until a P appears.
4. Press MENU/SELECT. You'll hear a confirmation tone.
To reset all codes:
1. Press MENU/SELECT from the idle mode.
2. Press or to select VOICEMAIL SETUP then press MENU/SELECT.
3. Press or to select RESET ALL CODES, then press
MENU/SELECT.
4. The screen displays RESET CODES?
5. Press MENU/SELECT. You'll hear a confirmation tone.
Make, receive and end calls
Make a call
• Press /FLASH or to ensure there is a dial tone, then dial the
telephone number.
-OR-
1. Dial the number (press MUTE/REMOVE to make corrections;
press and hold REDIAL/PAUSE to insert a dialing pause).
2. Press /FLASH or to use the speakerphone.
Receive a call
• Press /FLASH, or any dialing keys (0-9,
incoming call.
End a call
• Press OFF/CLEAR or put the handset back in the telephone base
or charger.
NOTES:
1. Use only the power adapters and batteries supplied with your VTech
telephone.
2. For complete feature instructions, please refer to your user's manual.
IMPORTANT!
If your product is not working properly:
• Refer to the Troubleshooting section of the user's manual.
• Visit our website at www.vtechphones.com.
In Canada, go to www.vtechcanada.com.
• Call our customer service at 1 (800) 595-9511.
In Canada, call 1 (800) 267-7377.
#
or ) to answer an
*
96-006499-030-100
issue 2
