Direct Channel Selection; Manually Setting Channels Into Memory; Preset Channel Scan; Switching Displays When Using The Sirius Satellite Radio - Eclipse CD5000 - - Radio Owner's Manual

How to operate the tuner with an optional SIRIUS satellite radio tuner connected (U.S.A. only)

Direct channel selection

The channel can be selected by inputting the
channel directly.
Press and hold the [SEL] button for
1
more than two seconds.
The mode will change to direct
channel selection mode.
Press the buttons [1], [2] and [3] to
2
select the channel number to be
input.
[1] button .......... Hundreds
[2] button .......... Tens
[3] button .......... Units
Each time the buttons are pressed, the
numerals change in the following
order.
0 ➔ 1 ➔ 2 ➔ 3 ➔ 4 ➔ 5 ➔ 6 ➔ 7 ➔ 8
➔ 9
Pressing the [6] button clears the
numeral at the previous digit.
3
Press the button [5].
Starts reception.
Manually setting channels into
memory
This section covers the setting of channels in
memory under the numbered buttons.
Turn the [SEL] button to the right
1
or left to tune to the channel to be
entered in memory.
Select any button, from [1] to [6],
2
and press it for more than two
seconds.
The channel to which you have tuned
is now memorized and set in the
selected button.
procedure to set the channels to which
you have manually tuned in addition in
memory, in turn, for the buttons [1] to
[6]. These buttons are called the
preset buttons.
If the vehicle's battery is disconnected (for
repairs to the vehicle or for removing the main
unit), all the channels in memory will be lost. In
such a case, set the channels in memory
again.

Preset channel scan

This function enables reception of all the
channels in the preset buttons for five seconds
each.
1
2
Switching displays when using
the SIRIUS satellite radio
1
• The maximum number of characters that
can be displayed for each item is as follows:
Repeat the
Title: 38 characters
Artist: 38 characters
Channel: 20 characters
Category: 16 characters
• If there is no name, NO_ DATA will appear.
ATTENTION
Press the [SEL] button for less
than two seconds.
[P SCAN] will appear on the display,
and the channels stored under the
preset buttons [1] to [6] will be played
for five seconds each.
To stop the preset scan mode at a
desired channel, press the [SEL]
button again.
The main unit will stay tuned to the
desired channel.
Press the [ILUM] button for more
than one second.
Each time the button is pressed the
display item changes in the following
order:
channel name ➔ category name ➔
title ➔ artist ➔ SIRIUS unit ID.
ATTENTION
XVIII
85
