Bionaire PERMAtech BAP1415-CN Instruction Leaflet

BAP141505EFM1-07.qxd:BAP141505EFM1.qxd 4/29/08 8:58 PM Page 1
AIR CLEANER SAFETY
PERMAtech ™
PLEASE READ AND SAVE
air cleaner
THESE IMPORTANT SAFETY
INSTRUCTIONS
BAP1415-CN
MODEL
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions
should always be followed to reduce the risk of fire, electric
shock, and injury to persons, including the following:
• Read all instructions before using the appliance.
• To avoid fire or shock hazard, plug the appliance directly
into a 120V AC electrical outlet.
• If the filter is covered by a bag when shipped: Remove
plastic bag before use.
• Keep the cord out of heavy traffic areas. To avoid fire
hazard, NEVER put the cord under rugs, near heat
registers, radiators, stoves, or heaters.
• To protect against electrical hazards, DO NOT immerse
in water or other liquids. Do not use near water.
• Close supervision is necessary when any appliance is
used by or near children, or disabled persons.
• Always unplug the air cleaner before moving it, opening
the grill, changing the filters, cleaning, or whenever the
air cleaner is not in use. Be sure to pull by the plug and
not the cord.
• NEVER drop or insert any object into any openings.
• DO NOT operate any appliance with a damaged cord or
plug, if motor fan fails to rotate, after the appliance
malfunctions, or if it has been dropped or damaged in any
manner. Return appliance to manufacturer for
examination, electrical or mechanical adjustment, or repair.
• Use appliance only for intended household use as
described in this manual. Any other use not
recommended by the manufacturer may cause fire,
electric shock, or injury to persons. The use of
attachments not recommended or sold by JCS/THG,
LLC may cause hazards.
• DO NOT use outdoors.
• NEVER block the air openings, grills/outlets or place on
Read instructions
a soft surface such as a bed or sofa, as this could
before operating.
cause the unit to tip over, blocking the Air Intake
Retain for future reference.
Opening/Grill.
Instruction Leaflet
• Keep unit away from heated surfaces and open flames.
☎ • DO NOT attempt to repair or adjust any electrical or
mechanical functions on this unit. Doing so will void
INFO-LINE
your warranty. The inside of the unit contains no user
If after having read this leaflet, you have any
serviceable parts except the filter. All servicing should
questions or comments on air cleaners,
be performed by qualified personnel only.
call 1-800-253-2764 in North America.
TROUBLESHOOTING AIR CLEANER SERVICE INSTRUCTIONS
1. DO NOT attempt to repair or adjust any electrical or
Problem Solution
mechanical functions on this unit. Doing so will void the
Unit will not operate • Check to make sure the unit is
warranty. The inside of the unit contains no user
plugged in.
serviceable parts. All servicing should be performed by
qualified personnel only.
• Check to make sure the unit is on
by pressing the power button.
2. If you need to exchange the unit, please return it in its
original carton, with a sales receipt, to the store where
Decreased airflow • If the Filter Service Indicator is red,
you purchased it. If you are returning the unit more than
the PERMAtech ™ filter should be
30 days after the date of purchase, please see the
cleaned.
enclosed warranty.
• Check the filter to make sure
3. Should your Air Cleaner require service, please call
it is in good condition.
1-800-253-2764 in North America for further assistance.
• Check to ensure nothing is blocking A return authorization will be given when you call.
air inlet and filtered air outlet.
4. If you have any other questions or comments, feel
Noise • Make sure filter bag are free to write to us:
removed if present.
Bionaire
JCS/THG, LLG
Figure 2
Figure 1
Consumer Service Department
13120 Jurupa Avenue
Fontana, CA 92337
Visit our website at www.bionaire.com
Figure 3
D E
Figure 4 C
B
F
A
G
A. POWER INDICATOR
B. SPEED CONTROL
C. FILTER SERVICE LIGHT
H
D. IONIZER CONTROL
E. IONIZER INDICATOR J
LIGHT
F. INLET GRILL
G. WASHABLE FOAM
FILTER
H. PERMATECH™ FILTER
I
I. FILTERED AIR OUTLET
B
J. SPEED SETTING BUT-
TONS (3)
• WARNING : To reduce the risk of fire or electric shock,
DO NOT use this air cleaner with any solid-state speed
control device.
• DO NOT place anything on top of unit.
PLEASE READ AND SAVE
THESE IMPORTANT SAFETY
INSTRUCTIONS
CONSUMER SAFETY INFORMATION
This appliance has a POLARIZED AC
PLUG (one blade is wider than the other).
To reduce the risk of electric shock, this
plug is intended to fit in a polarized outlet
only one way. If the plug does not fit fully
in the outlet, reverse the plug. If it still does
not fit, contact a qualified electrician to
install the proper outlet.
DO NOT DEFEAT THE SAFETY PURPOSE OF THIS
POLARIZED PLUG IN ANY WAY.
CORD AND PLUG INSTALLATION SAFETY
INSTRUCTIONS
The length of cord used on this appliance was selected to
reduce the hazards of becoming tangled in, or tripping over
a longer cord. If a longer cord is necessary, an approved
extension cord may be used. The electrical rating of the
extension cord must be equal to or greater than the rating
of the air cleaner. Care must be taken to arrange the
extension cord so that it will not drape over the countertop
or tabletop where it can be pulled on by children or
accidentally tripped over.
Thank you for choosing a Bionaire
ensure the best performance from your air cleaner,
please read and save the following instructions.
TOW (2) YEAR LIMITED WARRANTY
SAVE THIS WARRANTY INFORMATION
A. This Warranty applies only to the original purchaser of
this product.
B. This Warranty applies ONLY to repair or replacement of
any supplied or manufactured parts of this product that,
upon inspection by JCS/THG, LLC authorized
personnel, is shown to have failed in normal use due to
defects in material or workmanship. JCS/THG, LLC will
determine whether to repair or replace the unit. This
Warranty does not apply to installation expenses.
C. Operating this unit under conditions other than those
recommended or at voltages other than the voltage
indicated on the unit, or attempting to service or modify
the unit, will render this WARRANTY VOID.
D. Unless otherwise proscribed by law, JCS/THG, LLC
shall not be liable for any personal injury, property or any
®
incidental or consequential damage of any kind resulting
from malfunctions, defects, misuse, improper installation
or alteration of this product.
E. All parts of this product excluding filters, which are
covered under separate warranty, are guaranteed for a
period of 2 years as follows:
1.Within the first 30 days from date of purchase, the
store from which you purchased your product should
replace this product if it is defective in material or
workmanship (provided the store has in-stock
replacement.) If you intend to assert any claim in
connection with the product, please follow the
instructions in paragraph F.
2.Within the first 24 months from date of purchase,
JCS/THG, LLC will repair or replace the product if it is
defective in material or workmanship, subject to the
conditions in paragraph G.
F. If you have any other problem or claim in connection
with this product, please write to our Consumer Service
Department.
G. IMPORTANT RETURN INSTRUCTIONS. Your Warranty
depends on your following these instructions if you are
returning the unit to JCS/THG, LLC:
1. Carefully pack the item in its original carton or other
suitable box to avoid damage in shipping.
2. Before packing your unit for return, be sure to
enclose:
a) Your name, full address with zip code and
telephone number
b) A dated sales receipt or PROOF OF PURCHASE,
c) Your $7.50 check for return shipping and handling,
and
IONIZER
Your Air Cleaner has an independently controlled ionizer,
which, when turned on, releases negative ions into
outgoing filtered air. Ions are tiny particles that carry a
positive or negative charge. These ions exist naturally
around us, in the air, water and ground. Both positive and
negative ions are colorless, odorless and completely
harmless.
Negative ions help the air purification process by attaching
themselves to very small airborne particles in the room.
These particles take on a negative charge and may join
with positively charged particles such as dust, pollen,
smoke and pet dander to form larger particles that are then
more readily captured by the filter system, or they may be
attracted to positively charged surfaces like walls or floors.
You may also note after extended use, that dust may have
collected around the grills or front panel. This is from the
ionization affect caused by the negative ions exiting from
the air outlet. This is additional evidence of the air cleaning
effectiveness of negative ions. The dust can be easily
removed with a clean, damp cloth or soft brush.
NOTE: It is important to clean the PERMAtech ™ filter at
the recommended intervals. Using the ionizer in conjunction
with dirty filters may result in dirty particles exiting the air
cleaner and being attracted to walls, carpets, furniture or
other household objects. These dirty particles may prove very
difficult to remove.
If the filters are enclosed in
plastic bags please ensure
that the bags are removed
prior to operation.
® air cleaner. To
OPERATING INSTRUCTIONS
1. Carefully unpack your Air Cleaner. Select a firm level
place where there are no obstructions to the air inlet or
filtered air outlet. A good location in a room is
approximately 1 foot away from the wall, in a central
location of your home.
DO NOT POINT AIR OUTLET TOWARDS WALL.
2. Plug into a 120V AC electrical outlet.
3. Press the power button ( ). The unit will turn onto
high and the power light will illuminate letting you know
the power is on.
4. You can then select the desired speed setting. This air
cleaner has three speed settings. You can select from
HIGH ( ), MEDIUM ( ), or LOW ( ) by pushing the
desired operating speed button on the control panel or
the remote control.
5. To release negative ions into the filtered air, press the
ionizer button ( ) to ON and the light will illuminate.
d) The model number of the unit and the problem
you are having. (Enclose in an envelope and tape
directly to the unit before the box is sealed.)
3. JCS/THG, LLC recommends you ship the package
U.P.S. ground service for tracking purposes.
4. All shipping charges must be prepaid by you.
5. Mark the outside of your package:
Bionaire ®
JCS/THG, LLC
13120 Jurupa Avenue
Fontana, CA 92337
SHIPPING AND HANDLING CHARGES: $7.50 (USD)
This Warranty gives you specific legal rights, and you may
have other rights which vary from state to state. The
provisions of this Warranty are in addition to, and not a
modification of, or subtraction from, the statutory
warranties and other rights and remedies contained in any
applicable legislation. To the extent that any provision of
this Warranty is inconsistent with any applicable law, such
provision shall be deemed voided or amended, as
necessary, to comply with such law.
©2006 JCS/THG, LLC
Bionaire ® , the Bionaire logo ® and PERMAtech TM are trademarks of
JCS/THG, LLC.
Printed In China
6. For optimum air filtration, it is recommended to operate 4.Remove and examine the foam pre-filter. If it has collected
the air cleaner continuously. Its rugged motor has been a noticeable amount of dust or lint, remove it from the inlet
designed to give many years of use. of the grill and wash it in warm soapy water. Rinse and
drip dry the pre-filter thoroughly before replacing it into the
For continuous use, it's recommended to operate the air
inlet of the grill.
cleaner at the MEDIUM setting. For quieter operation or
use in a bedroom, select the LOW setting. When high 5.With the rear inlet grill removed, check the condition of
levels of air particulates are present, select the HIGH your PERMAtech
setting to quickly circulate and filter the room air. by gripping on both sides and pulling forward.
REMOTE CONTROL 6.To clean the PERMAtech
with your vacuum cleaner. Run the attachment along the
Your remote control requires (2) AAA batteries (included) for
inlet and outlet side of the filter trying to clean between
operation. To install the batteries, simply depress and slide
the pleated filter layers. (Figure 1)
the back of the remote control with your thumb on the
DO NOT USE WATER OR ANY OTHER HOUSEHOLD
arrow indentation. Insert batteries according to the diagram
CLEANERS OR DETERGENTS TO CLEAN THE
shown inside and replace cover.
PERMAtech
• Do NOT mix old and new batteries.
Note: Vacuuming will restore performance of the
• DO NOT mix alkaline, standard (carbon-zinc) or
PERMAtech
rechargeable (nickel-cadmium) batteries.
stained. This is normal and does not affect
1. Set air cleaner on a dry, level surface.
performance in any way.
2. Plug cord into any standard 120V AC outlet.
7.This model utilizes a hang tab and filter clips to insure
that the filter is properly in place. Before replacing the
3. To turn the air cleaner on, press the power button ( )
PERMAtech
and then select the desired operating speed by
securely in place. The clip can only be attached to the
pressing any speed button on the remote control or on
the control panel. tabs on the filter one way. The filter clip should easily slide
onto the filter hang tab with only a small amount of
4. The speed is adjustable by pressing either the Speed
pressure. DO NOT use force while attaching the clip to
Button on the remote control or on the control panel.
the filter. (Figure 2).
5. To turn the unit off, press the power button ( ) on
8.Align the clip on the top of the PERMAtech
either the remote control or on the control panel.
the rails on the inside of the purifier unit. Gently slide
the filter onto the rail (Figure 3). NOTE: The side with
CLEANING/MAINTENANCE INSTRUCTIONS
the soft gasket should face inward.
Turn off and unplug the unit before cleaning.
9.Replace air inlet grill back onto unit securely.
1. The outside of the air cleaner can be cleaned with a
10. The filter service indicator must be reset once the
soft, damp cloth.
PERMAtech™ filter has been cleaned. Reset indicator
2. The rear air inlet grill can be removed and washed in
by holding the power button depressed (
warm soapy water (not dishwasher safe). Dry before
seconds.
replacing in the unit.
Filter Life – The filter has been designed to never need
3. The front air outlet grill can be cleaned of dust with a
replacement, however, it does need servicing. We
small soft brush or cloth. recommend that under normal conditions of
continuous use, the filter should be cleaned at least
WARNING: Do not allow moisture to come in contact with
every 3 months to help maintain optimal performance.
the main housing of the air cleaner.
Should the filter become damaged during cleaning
PERMATECH™ FILTER CLEANING INSTRUCTIONS
replacements are available by calling 1-800-253-2764.
1. Filter Service Indicator ( ) – Your air cleaner has an
indicator light that illuminates when it is time to clean
Air Cleaner
the PERMAtech filters.
™ Model #
2. Every few weeks, check the condition of the filter.
BAP1415-CN
3. Turn off and unplug unit. Remove the air inlet grill by
pulling the air inlet grill towards you by grasping the finger
tab on the top of the unit.
™ filter. If the filter are dirty, remove it
™ filter use a brush attachment
™ FILTER.
TM filter however, the filter may appear
™ filter make sure that the hang tab is
™ filter with
) for 2
Filter Quantity Filter # Filter
Needed Description
PERMAtech™
7400000000203
1
Filter
