1-2 Technical Information
HARDWARE OVERVIEW—FRONT
Take a moment to become familiar with the location and function of controls located on the
front of the system.

Liquid Crystal Display (LCD)

The LCD operates with the Chips & Technologies 65550 VGA controller. The controller
supports XGA, uses a 64-bit accelerator with a Peripheral Component Interconnect (PCI)
interface. The LCD also supports VESA timing.
The NEC Versa 6200MX LCD features the following:
T
13.3-inch Extended Graphics Array (XGA) TFT high resolution active matrix
XGA color display
T
0.264 mm dot pitch
T
18-bit digital interface
T
1024 x 768 resolution
T
256,000 colors.
Additional LCD panel features:
T
Power LED that indicates the current power status. This LED is visible with the
LCD panel opened or closed.
T
Slide switch that adjusts screen brightness.
Table 1-1 Model Configurations
FEATURE NEC Versa 6200MX
CPU Intel Pentium® with
MMX technology
P55CLM/166 MHz
On-Board DRAM 32-MB
Video Memory 2-MB
Hard Disk Drive 2.1 GB
CD-ROM Reader 10X CD ROM Reader
Color LCD 13.3" Extended
Graphics Array
(XGA),TFT Color
Display
