Table 3-1 IDE Device Primary/Secondary Master/Slave
Configuration
1 device (hard disk)
2 devices (hard disk,
CD-ROM)
2 devices ( hard disk,
tape backup unit)
2 devices ( hard disk,
Zip drive)
3 devices (hard disk,
CD-ROM, Zip drive)
3 devices (hard disk,
CD-ROM, tape backup unit)
3 devices (hard disk,
hard disk, CD-ROM)
3 devices (hard disk,
hard disk, tape backup unit)
3 devices (hard disk,
hard disk, Zip drive)
4 devices (hard disk,
CD-ROM, Zip drive, tape
backup unit)
4 devices (hard disk,
hard disk, CD-ROM, tape
backup unit)
4 devices (hard disk, hard disk,
CD-ROM, Zip drive)
4 devices (hard disk, hard disk,
Zip drive, tape backup unit)
Configurations
Primary
Connector
Master - hard disk
Slave - none
Master - hard disk
Slave - none
Master - hard disk
Slave - none
Master - hard disk
Slave - none
Master - hard disk
Slave - none
Master - hard disk
Slave - none
Master - hard disk
Slave - hard disk
Master - hard disk
Slave - hard disk
Master - hard disk
Slave - hard disk
Master - hard disk
Slave - Zip drive
Master - hard disk
Slave - hard disk
Master - hard disk
Slave - hard disk
Master - hard disk
Slave - hard disk
Option Installation
Secondary Connector
Master - none
Slave - none
Master - CD-ROM
Slave - none
Master - tape backup
Slave - none
Master - Zip drive
Slave - none
Master - CD-ROM
Slave - Zip drive
Master - CD-ROM
Slave - tape backup
Master - CD-ROM
Slave - none
Master - tape backup
Slave - none
Master - Zip drive
Slave - none
Master - CD-ROM
Slave - tape backup
Master - CD-ROM
Slave - tape backup
Master - CD-ROM
Slave - Zip drive
Master - Zip drive
Slave - tape backup
3-21
