SMC Networks EliteConnect SMCE21011 Specifications

SMCE21011
EliteConnect
Wireless Enterprise Access Point
Product Overview
The EliteConnect™ Wireless Enterprise Access Point (SMCE21011) is based on IEEE
802.11n and offers data rates of up to 300Mbps either in the 2.4GHz or 5GHz frequency
band. The dual-band, single radio Wireless Access Point uses MIMO technology to provide
robust and high performance data transmission and increase wireless coverage for
enterprise networks. Supporting up to eight Virtual Access Point (VAP) interfaces, the
SMCE21011 allows traffic to be separated for different user groups within the same access
point service area. Each VAP can be configured with its own Service Set Identification
(SSID), security settings, VLAN assignments, and other parameters.
It comes with three detachable dual-band antennas to provide optimal wireless coverage and
support for IEEE802.3af Power over Ethernet (PoE) to allow Wi-Fi deployment where power
outlets are not available. SMCE21011 provides enterprise level security features such as
personal and enterprise versions of WPA/WPA2 (IEEE 802.11i), RADIUS Authentication,
Access Control list (ACL), Wireless LAN segmentation and Disable SSID Broadcast. For
simplified network management, multiple management options are available, including Web
(HTTP), Secure HTTP (HTTPS), Secure Sockets Layer (SSL), Secure Shell (SSH), and
Telnet.

Key Features and Benefits

Wireless IEEE 802.11n Technology
Compliant with IEEE 802.11n and MIMO (Multi Input Multi
Output) wireless technology.
Power over Ethernet
Support for IEEE 802.3af Power over Ethernet (PoE) allows
Wi-Fi deployment where power outlets are not available.
Advanced Traffic Management
Supporting up to eight Virtual Access Point (VAP) interfaces,
with support for up to 64 wireless clients each.

Application Diagram

Enhanced Security
Offers the latest in wireless security technologies by supporting
both personal and enterprise versions of WPA/WPA2 (IEEE
802.11i), RADIUS Authentication, Access Control list (ACL),
Wireless LAN segmentation and Disable SSID Broadcast.
Full Management Capabilities
Supports Simple Network Management Protocol (SNMP v3),
Web (HTTP), Secure HTTP (HTTPS), Secure Sockets Later
(SSL), Secure Shell (SSH), and Telnet.
