Physical Characteristics

Base Units

Ports
24 10/100BASE-TX, with auto-negotiation
2 1000BASE-T/SFP combination ports
Network Interface
Ports 1-24: RJ-45 connector, auto MDI/X
10BASE-T: RJ-45 (100-ohm, UTP cable; Categories 3 or better)
100BASE-TX: RJ-45 (100-ohm, UTP cable; Category 5 or better)
Ports 25, 26: RJ-45 connector, auto MDI/X
1000BASE-T: RJ-45 (100-ohm, UTP cable; Category 5, 5e, or 6)
Buffer Architecture
8 Mbytes
Aggregate Bandwidth
8.8 Gbps
Switching Database
8K MAC address entries
Power over Ethernet
Maximum output power per port: 15.4 W
Output voltage: 44 - 57 VDC
Maximum output current per port: 350 mA
Power Supply
Internal, auto-ranging transformer: 100 to 240 VAC, 47 to 63 Hz
A
PPENDIX
S
PECIFICATIONS
C
C-1
