ZyXEL Communications Prestige 650H Series Brochure

ADSL
Router with 4-port
Switch /Wireless LAN
Models: Prestige 650H ADSL Router with 4-port Switch over POTS
Prestige 650H ADSL Router with 4-port Switch over ISDN
Prestige 650HW ADSL Router with 4-port Switch/Wireless LAN over POTS
Prestige 650HW ADSL Router with 4-port Switch/Wireless LAN over ISDN
The new ZyXEL Prestige 650H/650HW series is an ideal solution for SOHO users who require super-fast Internet access, or LAN-to-
LAN connections over existing copper wires. The Prestige 650H/650HW series, an ADSL-based router with an integrated 4-port
10/100 Mbps switch, provides maximum speeds of up to 8Mbps for up to 4 computers without the extra cost of a hub or switch.
The optional wireless LAN is ideal for SOHO or SMB customers. It brings you the high-speed Internet experience wirelessly to make
your network more flexible and efficient.
B e n e f i t s
Built-in PPPoE Solution
Incorporating ZyXEL's first-in-the-world PPPoE
implementation, the Prestige 650H/650HW series enables
service providers and users to make use of existing
PPP/PAP/CHAP based authentication and accounting
infrastructure. Users don't need to pay extra for PPPoE
software to enjoy the benefits of PPPoE.
An Instant LAN with an Integrated 10/100Mbps Switch
The combination of a switch and router makes the Prestige
650H/650HW series more efficient and less expensive than
having to purchase separate boxes. The built-in switch
provides each connection a dedicated 10/100 Mbps
bandwidth that greatly increases the throughput for
bandwidth-sensitive applications as opposed to having to
use a hub where the bandwidth would be inefficiently
shared by all of the stations. The industry-standard HP
Auto MDI/MDIX feature enables the on-chip transceivers to
automatically and transparently detect and correct
incorrectly wired cables. This makes installation,
debugging, and maintenance of the network substantially
simpler and less expensive for the end users.
A p p l i c a t i o n A p p l i c a t i o n
Internet
ISP
D i a g r a m D i a g r a m
Local Loop
DSLAM
Central Office
Desktop with ZyAIR200
POTS Splitter
Prestige 650HW
Wall Jack
Notebook with
ZyAIR 100 or ZyAIR 200
Powerful Multi-to-Multi NAT and Routing Features for Internet
Access Sharing
The multimedia-aware NAT (Network Address Translation)
feature not only allows an unlimited number of users to access
the Internet with a single ISP account, but it also supports
multimedia applications such as NetMeeting, CUSeeMe, IRC,
RealPlayer and ICQ. With PPP routing and robust security
features, the Prestige 650H/650HW series connects your
computers to the Internet while protecting your local network.
Ease of Use and Management
The Web-based Graphical User Interface (GUI) allows easy
installation of the Prestige 650H/650HW series and effortless
management, either locally or remotely. With the built-in DHCP
server, which automatically assigns and configures IP
parameters to the computers on your LAN, Internet connections
become truly plug-and-play.
Optional Wireless LAN Solution (Prestige 650HW only)
The optional wireless LAN solution offers quick and easy access
to a traditional wired Ethernet LAN in the office or home. The
wireless LAN is also an extension of existing Ethernet LANs,
which extends your network connection and provides the
ultimate advantage of mobility.
Home/Office
Home/Office
POTS Splitter
Wall Jack
Prestige 650H
